Post your sample source code here and get featured on our blogs!

Question

You can post your interesting sample source code (and an optional screenshot of the program) here.  If it is interesting enough we'll feature you and your source code on our blogs (http://blogs.msdn.com/smallbasic).  Here's something to get started.

GraphicsWindow.Show()

pic = Flickr.GetRandomPicture("lightning")

gw = GraphicsWindow.Width

gh = GraphicsWindow.Height

GraphicsWindow.DrawResizedImage(pic, 0, 0, gw, gh)

distance = 50

Turtle.Speed = 9

For sides = 3 To 20

DrawPolygon()

EndFor

Sub DrawPolygon

angle = 360 / sides

For i = 1 To sides

GraphicsWindow.PenColor = GraphicsWindow.GetRandomColor()

Turtle.Move(distance)

Turtle.Turn(angle)

EndFor

EndSub

Answer 1

A Blackboard application that allows you to draw on a window

GraphicsWindow.BackgroundColor = "Black"
GraphicsWindow.PenColor = "White"
GraphicsWindow.MouseDown = OnMouseDown
GraphicsWindow.MouseMove = OnMouseMove

Sub OnMouseDown
  prevX = GraphicsWindow.MouseX
  prevY = GraphicsWindow.MouseY
EndSub

Sub OnMouseMove
  x = GraphicsWindow.MouseX
  y = GraphicsWindow.MouseY
  If (Mouse.IsLeftButtonDown) then
    GraphicsWindow.DrawLine(prevX, prevY, x, y)
  endif
  prevX = x
  prevY = y
EndSub

Answer 2

Here's a program to create a collage of World Series photos from Flickr

tag = "World Series"

For i = 1 To 10

x = Math.GetRandomNumber(250)

y = Math.GetRandomNumber(250)

picName = Flickr.GetRandomPicture(tag)

GraphicsWindow.DrawResizedImage(picName, x, y, 200, 200)

EndFor

I wanted to actually scale the images instead of a fixed height and width but unfortunately the call the ImageList.GetWidthOfImage() keeps crashing (GetHeightOfImage works
fine). Anybody have any clues?

tag = "World Series"

pic = "MyPic"

For i = 1 To 10

x = Math.GetRandomNumber(300)

y = Math.GetRandomNumber(300)

picName = pic + i

ImageList.LoadImage(picName, Flickr.GetRandomPicture(tag))

height = ImageList.GetHeightOfImage(picName)

'This line crashes every time for me (running Vista 32bit).

'width = ImageList.GetWidthOfImage(picName)

GraphicsWindow.DrawResizedImage(picName, x, y, 300, height / 3)

EndFor

Thanks!

---

Program Manager, Visual Studio Community http://msdn.com/vbasic http://msdn.com/vsto http://blogs.msdn.com/bethmassi

Answer 3

GraphicsWindow.BackgroundColor = "Black"

GraphicsWindow.PenColor = "White"

GraphicsWindow.MouseDown = OnMouseDown

GraphicsWindow.MouseMove = OnMouseMove

Sub OnMouseDown

prevX = GraphicsWindow.MouseX

prevY = GraphicsWindow.MouseY

EndSub

Sub OnMouseMove

x = GraphicsWindow.MouseX

y = GraphicsWindow.MouseY

If (Mouse.IsLeftButtonDown) then

GraphicsWindow.DrawLine(prevX, prevY, x, y)

endif

prevX = x

prevY = y

EndSub

When copy-pasting your Blackboard sample to SmallBasic it came as a new line. This should fix it (I copied from the SmallBasic editor to IE8 browser). BTW, the "line numbers" feature of the code block on this forum isn't good, since you can't copy-paste the source (you get the line numbers in the selection). It should use a table instead with the lines at the left column and the code at the right column so that you don't select and copy the line numbers and ruin the sample

Answer 4

Here's the classic Logo "Squiral". However having "Sub" without params isn't very useful for learning programming, plus it's counter-intuitive, since you allow one to call methods WITH parameters, but their own Subroutines can't have parameters. Isn't that unfair?

GraphicsWindow.Show()

Turtle.Speed = 5

angle = 91

Squiral()

Sub Squiral

side = 0

For i = 1 to 180

Turtle.Move(side)

Turtle.Turn(angle)

side = side + 1

EndFor

EndSub

(screenshot - added by Vijaye Raji)

---

Microsoft MVP J# 2004-2007, Borland Spirit of Delphi 2001

Answer 5

I've created a cute little stock price simulator using the empirical distribution of (assumed normally distrubuted) stock price returns back to 1801.

Ten x pixels are 1 year.

GraphicsWindow.Show()

pic = Flickr.GetRandomPicture("stock price")
gw = GraphicsWindow.Width
gh = GraphicsWindow.Height
GraphicsWindow.DrawResizedImage(pic, 0, 0, gw/2, gh/2)


distance = 10
numyears = 80
numstocks = 100
pixelstep = 10
Price = 10
oldprice = price
mu = 0.1
sigma = 0.18
Sub Normal
part0=math.GetRandomNumber(10000)/10000
part1 = 2*Math.Pi*Math.GetRandomNumber(10000)/10000
part2 = Math.Cos(part1)
part3 = -2*Math.NaturalLog(Math.GetRandomNumber(10000)/10000)
nrml = mu + sigma*Math.SquareRoot(part3)*part2
EndSub
Sub stockprice
    For i = pixelstep To numyears*pixelstep Step pixelstep
    Normal()
    Price= Price*(1+nrml)
    GraphicsWindow.DrawLine(i-pixelstep, gh-oldprice, i, gh-Price)
    oldprice = Price
  EndFor
EndSub
Sub stocks
For j = 1 To numstocks
GraphicsWindow.PenColor = GraphicsWindow.GetRandomColor()
Price = 10
oldprice = Price
stockprice()
EndFor
EndSub
stocks()

Answer 6

I wrote a small app (cmd line only) that converts C to F and F to C. I added a little menu with input error handling for fun. :)

Goto mainLabel

mainLabel:

TextWindow.WriteLine("Ready to calculate? Enter your selection: ")

TextWindow.WriteLine("")

TextWindow.WriteLine("1. Convert C to F")

TextWindow.WriteLine("2. Convert F to C")

TextWindow.WriteLine("3. Exit")

For i = 1 To 3

TextWindow.Write(".")

Program.Delay(500)

EndFor

input = TextWindow.ReadNumber()

If (input = 1) Then

Goto ctofLabel

EndIf

If (input = 2) Then

Goto ftocLabel

EndIf

If (input = 3) Then

Goto exitLabel

Else

TextWindow.WriteLine("INVALID ENTRY!")

Goto mainLabel

EndIf

ctofLabel:

TextWindow.WriteLine("Enter degrees Celcius: ")

cel = TextWindow.ReadNumber()

fahr = (cel * 1.8) + 32

TextWindow.WriteLine(cel + " degrees C = " + fahr + " degrees F")

Goto mainLabel

ftocLabel:

TextWindow.WriteLine("Enter degrees Fahrenheit: ")

fahr = TextWindow.ReadNumber()

cel = 5/9*(fahr-32)

TextWindow.WriteLine(fahr + " degrees F = " + cel + " degrees C")

Goto mainLabel

exitLabel:

Program.End()

Answer 7

' --------------------------------------------------------------------------------

' Filename: gol.sb

' Author: Christian Jacob <[e-mail]>

' --------------------------------------------------------------------------------

' Width of the life grid

maxX = 100

' Height of the life grid

maxY = 100

' Size of the life pixels

lifeSize = 5

max = maxX * maxY

currentPos = 0

neighbourPos = 0

start = 0

initialize = 1

GraphicsWindow.BackgroundColor = "SteelBlue"

GraphicsWindow.BrushColor = "Black"

GraphicsWindow.Title = "Game of Life"

GraphicsWindow.Width = maxX * lifeSize + 100

GraphicsWindow.Height = maxY * lifeSize

GraphicsWindow.MouseDown = OnMouseDown

GraphicsWindow.Show()

RunLoop:

If (quit = 1 ) Then

Goto End

EndIf

If (initialize = 1) Then

Initialize()

EndIf

If (start = 0 ) Then

Goto RunLoop

EndIf

GraphicsWindow.Clear()

DrawUI()

DrawSimulation()

CalculateNextGeneration()

Goto RunLoop

End:

Program.End()

Sub Initialize

GraphicsWindow.Clear()

' Initialize life grid

For y = 0 To maxY - 1

For x = 0 To maxX - 1

currentPos = y * maxX + x

Array.SetValue ("lifegrid", currentPos, 0)

Array.SetValue ("lifegridcopy", currentPos, 0)

EndFor

EndFor

' Initialize  f-Pentomino

Array.SetValue ("lifegridcopy", 50*maxX+50, 1)

Array.SetValue ("lifegridcopy", 51*maxX+50, 1)

Array.SetValue ("lifegridcopy", 52*maxX+50, 1)

Array.SetValue ("lifegridcopy", 51*maxX+49, 1)

Array.SetValue ("lifegridcopy", 50*maxX+51, 1)

DrawUI()

DrawSimulation()

initialize = 0

EndSub

Sub DrawSimulation

For y = 0 To maxY - 1

For x = 0 To maxX - 1

currentPos = y * maxX + x

life = Array.GetValue ("lifegridcopy", currentPos)

Array.SetValue ("lifegrid", currentPos, life)

if (life = 1) Then

GraphicsWindow.FillRectangle (x*lifeSize, y*lifeSize, lifeSize-1, lifeSize-1)

EndIf

EndFor

EndFor

EndSub

Sub CalculateNextGeneration

For y = 0 To maxY-1

For x = 0 To maxX - 1

currentPos = y * maxX + x

GetNeighbourCount()

life = Array.GetValue("lifegrid", currentPos)

If( life = 0 And neighbourCount = 3 ) Then

' Get alife

Array.SetValue ("lifegridcopy", currentPos, 1)

EndIf

If ( life = 1 ) Then

if(  neighbourCount = 2 Or neighbourCount = 3 ) Then

' Stay alive

Array.SetValue ("lifegridcopy", currentPos, 1)

Else

' Die

Array.SetValue ("lifegridcopy", currentPos, 0)

EndIf

EndIf

EndFor

EndFor

EndSub

Sub DrawUI

GraphicsWindow.DrawLine( maxX*lifeSize, 0, maxX*lifeSize, maxY*lifeSize)

' Start button

GraphicsWindow.DrawRectangle( maxX * lifeSize + 5, 5, 90, 30 )

GraphicsWindow.DrawText( maxX * lifeSize + 10, 12, "Start" )

' Stop button

GraphicsWindow.DrawRectangle( maxX * lifeSize + 5, 35, 90, 30 )

GraphicsWindow.DrawText( maxX * lifeSize + 10, 42, "Stop" )

' Init button

GraphicsWindow.DrawRectangle( maxX * lifeSize + 5, 70, 90, 30 )

GraphicsWindow.DrawText( maxX * lifeSize + 10, 77, "Init" )

' Quit button

GraphicsWindow.DrawRectangle( maxX * lifeSize + 5, 105, 90, 30 )

GraphicsWindow.DrawText( maxX * lifeSize + 10, 107, "Quit" )

EndSub

Sub OnMouseDown

x = GraphicsWindow.MouseX

y = GraphicsWindow.MouseY

' Draw or remove life pixel

If( x > 0 And x < maxX * lifeSize And y > 0 And y < maxX * lifeSize ) Then

lifeY = Math.Round(y / lifeSize)

lifeX = Math.Round(x / lifeSize)

newLife = ( lifeY * maxX ) + lifeX

life = Array.GetValue ("lifegridcopy", newLife)

If( life = 1 ) Then

Array.SetValue ("lifegridcopy", newLife, 0)

GraphicsWindow.BrushColor = "SteelBlue"

GraphicsWindow.FillRectangle (lifeX*lifeSize, lifeY*lifeSize, lifeSize-1, lifeSize-1)

Else

Array.SetValue ("lifegridcopy", newLife, 1)

GraphicsWindow.BrushColor = "Black"

GraphicsWindow.FillRectangle (lifeX*lifeSize, lifeY*lifeSize, lifeSize-1, lifeSize-1)

EndIf

GraphicsWindow.BrushColor = "Black"

EndIf

' Start button

If ( x > maxX * lifeSize + 5 And x < maxX * lifeSize + 95 And y > 5 And y < 30 ) Then

start = 1

EndIf

' Stop button

If ( x > maxX * lifeSize + 5 And x < maxX * lifeSize + 95 And y > 35 And y < 65 ) Then

start = 0

EndIf

' Init button

If ( x > maxX * lifeSize + 5 And x < maxX * lifeSize + 95 And y > 70 And y < 100 ) Then

initialize = 1

EndIf

' Quit button

If ( x > maxX * lifeSize + 5 And x < maxX * lifeSize + 95 And y > 105 And y < 135 ) Then

quit = 1

EndIf

EndSub

Sub GetNeighbourCount

neighbourCount = 0

' Left

neighbourPos = currentPos - 1

GetNeighbour()

' Right

neighbourPos = currentPos + 1

GetNeighbour()

' Above

neighbourPos = currentPos - maxX

GetNeighbour()

' Beneath

neighbourPos = currentPos + maxX

GetNeighbour()

' Above left

neighbourPos = currentPos - maxX - 1

GetNeighbour()

' Above right

neighbourPos = currentPos - maxX + 1

GetNeighbour()

' Beneath left

neighbourPos = currentPos + maxX - 1

GetNeighbour()

' Beneath right

neighbourPos = currentPos + maxX + 1

GetNeighbour()

EndSub

Sub GetNeighbour

If (neighbourPos >= 0 And neighbourPos < max-1) Then

If( Array.GetValue("lifegrid", neighbourPos) = 1 ) Then

neighbourCount = neighbourCount + 1

EndIf

EndIf

EndSub

This code might not meet best performance strategies, but it works and gives a simple introduction of how to get something like Conway's Game of Life working with Small Basic.

When started, it is initialized with a pattern that sort of explodes at first. When clicking "Start", the simulation starts, "Stop" stops the simulation, "Init" resets the view and with "Quit" you end the program. Also, you can click on the grid to add life pixel or remove them.

I believe this is a good learning example for the intermediate programmer. If I included this code within a tutorial, manual or any other type of documentation, I would encourage the reader to try extend the program by adding a generation-counter to the screen, mabye add code for handling the borders correctly and the advanced programmer add the possibility of choosing preset pattern to start the simulation with.

Have fun!

Answer 8

Hi,
I wrote a library to work with MySQL databases in Small Basic.

DataBase.Connect("localhost", "root", "", "test")

' Execute a query and store the results in a datatable

DataBase.QueryAndFill("SELECT * FROM testtable")

' Go through the results of the latest query

For i=0 To DataBase.NumberOfRows - 1

TextWindow.WriteLine(DataBase.GetResults(i, 1))

EndFor

' Show a form with a datagrid component which contains the results of the latest query

DataBase.ShowGridWindow()

'  Execute a query without storing the results

DataBase.Query("UPDATE testtable SET title='hi' WHERE id=2")

Download: smalldatabase.zip

Answer 9

Here is a sample to draw Koch Square graphics. Currently the iteration times is 5, which might be very slow, you can change it to 4 or 3.

Here is a screenshot

' file: koch_square.sb

' Mr.Turtle will draw a Koch Square for us

' l-system rules:

'   variables : F

'   constants : + -

'   start : F

'   rules : F = F + F - F - F + F

' set some default values

angle = 90

length = 3

iteration = 5

' set the graphic panel color

GraphicsWindow.BackgroundColor = "Black"

GraphicsWindow.PenColor = "LightGreen"

'  move Mr.Turtle to the left-down corner for start

Turtle.Speed = 9

Turtle.Turn(-90)

Turtle.PenUp()

Turtle.Move(300)

Turtle.Turn(-90)

Turtle.Move(200)

Turtle.Turn(-90)

Turtle.PenDown()

' let's do it!

DrawStart()

' draw one rule

' if iteration is 0, stop further recursion

' otherwise, do recursion

Sub DrawRule

iteration = iteration - 1

If (iteration = 0) Then

Turtle.Move(length)

Turtle.Turn(-angle)

Turtle.Move(length)

Turtle.Turn(angle)

Turtle.Move(length)

Turtle.Turn(angle)

Turtle.Move(length)

Turtle.Turn(-angle)

Turtle.Move(length)

Else

DrawRule()

Turtle.Turn(-angle)

DrawRule()

Turtle.Turn(angle)

DrawRule()

Turtle.Turn(angle)

DrawRule()

Turtle.Turn(-angle)

DrawRule()

EndIf

iteration = iteration + 1

EndSub

' draw the start shape

Sub DrawStart

DrawRule()

EndSub

Answer 10

Another sample to draw Koch Curve.  You can ajust the times of iteration, 4 might be slow.

Here is a screenshot

file: koch_curve.sb

' Mr.Turtle will draw a Koch Square for us

' l-system rules:

'   variables : F

'   angle : 60

'   constants : + -

'   start : F - - F - - F

'   rules : F = F + F - - F + F

' set some default values

angle = 60

length = 5

iteration = 4

' set the graphic panel color

GraphicsWindow.BackgroundColor = "Black"

GraphicsWindow.PenColor = "LightGreen"

'  move Mr.Turtle to the left-down corner for start

Turtle.Speed = 9

Turtle.PenUp()

Turtle.Turn(90)

Turtle.Move(150)

Turtle.Turn(90)

Turtle.Move(150)

Turtle.Turn(90)

Turtle.PenDown()

' let's do it!

DrawStart()

' hide Mr.Turtle

Turtle.Hide()

' draw one rule

' if iteration is 0, stop further recursion

' otherwise, do recursion

Sub DrawRule

iteration = iteration - 1

If (iteration = 0) Then

Turtle.Move(length)

Turtle.Turn(-angle)

Turtle.Move(length)

Turtle.Turn(angle)

Turtle.Turn(angle)

Turtle.Move(length)

Turtle.Turn(-angle)

Turtle.Move(length)

Else

DrawRule()

Turtle.Turn(-angle)

DrawRule()

Turtle.Turn(angle)

Turtle.Turn(angle)

DrawRule()

Turtle.Turn(-angle)

DrawRule()

EndIf

iteration = iteration + 1

EndSub

' draw the start shape

Sub DrawStart

DrawRule()

Turtle.Turn(angle)

Turtle.Turn(angle)

DrawRule()

Turtle.Turn(angle)

Turtle.Turn(angle)

DrawRule()

EndSub

Answer 11

Here's a point-and-shoot game. It's a remake of the same thing I wrote using LOGO eons ago!

'Point-and-shoot

'(C)1989 McLeod/IdeaFix. http://www.zxprojects.com

'Target size

TargetSize=30

winner=0

wanttoplay=1

'A vector-screen style window

GraphicsWindow.BackgroundColor="Black"

GraphicsWindow.PenColor="Green"

GraphicsWindow.Clear()

Game()

Sub Game

While (wanttoplay=1)

GetRnd()

DrawTarget()

Turtle.PenUp()

'Game loop

While (winner=0)

Shoot()

EndWhile

winner=0

TextWindow.Write("Another game? (y/n) ")

answ = TextWindow.Read()

If (Text.StartsWith(Text.ConvertToLowerCase(answ),"n")) Then

wanttoplay=0

Else

GraphicsWindow.Clear()

Turtle.PenDown()

GraphicsWindow.PenColor="Green"

EndIf

EndWhile

EndSub

Sub Shoot

TextWindow.Write("Angle? ")

ang=TextWindow.ReadNumber()

TextWindow.Write("Distance? ")

dist=TextWindow.ReadNumber()

Turtle.Turn(ang)

Turtle.Move(dist)

Turtle.Turn(-ang)

xs=dist*Math.Cos(Math.GetRadians(ang))

ys=dist*Math.Sin(Math.GetRadians(ang))

If (xs>=xmin And xs<=xmax And ys>=ymin And ys<=ymax) Then

Sound.PlayChimes()

Turtle.Speed=100

Turtle.Move(-15)

Turtle.PenDown()

'The boom! visual effect

For n=1 To 36

GraphicsWindow.PenColor=GraphicsWindow.GetRandomColor()

Turtle.Move(30)

Turtle.Turn(150)

EndFor

Turtle.PenUp()

Turtle.Move(15)

Turtle.Turn(ang)

Turtle.Move(-dist)

Turtle.Turn(-ang)

Turtle.Hide()

TextWindow.WriteLine("Target cleared!! You WIN")

winner=1

Else

TextWindow.Write("Target failed!! Try again (press RETURN)")

TextWindow.Read()

Turtle.Speed=100

Turtle.Turn(ang)

Turtle.Move(-dist)

Turtle.Turn(-ang)

Turtle.Speed=7

winner=0

EndIf

EndSub

Sub GetRnd

'These variables should store the current Height and Width of GraphicsWindow, but it seems not to work

he=480

wi=640

If (he < wi) Then

distance=40+Math.GetRandomNumber(he/2-TargetSize-40)

Else

distance=40+Math.GetRandomNumber(wi/2-TargetSize-40)

EndIf

angle=Math.GetRandomNumber(360)

xmin=distance*Math.Cos(Math.GetRadians(angle))

ymin=distance*Math.Sin(Math.GetRadians(angle))

xmax=xmin+TargetSize

ymax=ymin+TargetSize

EndSub

Sub DrawTarget

Turtle.Speed=100

Turtle.PenUp()

Turtle.Turn(angle)

Turtle.Move(distance)

Turtle.Turn(-angle)

Turtle.PenDown()

For n=1 To 4

Turtle.Move(TargetSize)

Turtle.TurnRight()

EndFor

Turtle.PenUp()

Turtle.Turn(angle)

Turtle.Move(-distance)

Turtle.Turn(-angle)

Turtle.PenDown()

Turtle.Speed=7

EndSub

Answer 12

I love every single one of these samples!!  Amazing work - it's really hard for us to pick the one to feature in our blogs.  Because of that we're going to make this a weekly feature - keep your samples coming!

Answer 13

mcleod_ideafix's point and shoot game is now the featured sample of the week in our Small Basic blogs (http://blogs.msdn.com/smallbasic/default.aspx)

Answer 14

This (ported from a Modellus sample) should draw a flower (using angular coordinates in calculations and converting to cartesian to draw). Didn't try it though cause of the issue with SmallBasic in non-English locales, so please update if not showing ok and drop-in a screenshot too if you like the output :-)

init()

For i=1 To 100

oldx=x

oldy=y

solve()

animate()

t=t+dt

EndFor

Sub init

GraphicsWindow.Show()

t=0

dt=0.1

x=0

y=0

ofsx=GraphicsWindow.Width/2

ofsy=GraphicsWindow.Height/2

EndSub

Sub solve

theta=10*t

r=10*Math.cos(60*t)+20

x=r*Math.cos(theta)

y=r*Math.sin(theta)

EndSub

Sub animate

GraphicsWindow.AddLine(ofsx+oldx,ofsy+oldy,ofsx+x,ofsy+y)

EndSub

---

Microsoft MVP J# 2004-2007, Borland Spirit of Delphi 2001

Answer 15

Thanks to George, i used your code layout on the squarial code for this fun trick i made.
I imagine it'll make every geometric shape imaginable if it the golden ratio wasnt truncated to 10 decimal places or so.

GraphicsWindow.Show()

Turtle.Speed = 10

angle = (1+ Math.SquareRoot(5))/2

golden()

Sub golden

side = 0

For i = 1 to 360

Turtle.Move(side)

Turtle.Turn(angle)

side = side + 1

angle = angle + 1

EndFor

EndSub

Also, doing things proper, here is a graph of the golden ratio:

GraphicsWindow.Show()

Turtle.Speed = 10

angle = 30

golden()

Sub golden

side = (1+ Math.SquareRoot(5))/2

For i = 1 to 360

Turtle.Move(side)

Turtle.Turn(angle)

side = side + i

EndFor

EndSub

Answer 16

GraphicsWindow.Show()

Turtle.Speed = 10

angle = 80

golden()

Sub golden

side = (1+ Math.SquareRoot(5))/2

For i = 1 to 180

Turtle.Move(side)

Turtle.Turn(angle)

side = side + 1

EndFor

EndSub

Nice, ported it to Scratch to see it though (waiting for the next SmallBasic that will run ok at my system's locale). Try the above variation for a knitted-like star pattern :-). Also at your first fun-sample try using 180 instead of 360. In Scratch it shows like a 3D sphere with blasts/rays arround it (could imagine it as a star or exploding planet)

---

Microsoft MVP J# 2004-2007, Borland Spirit of Delphi 2001

Answer 17

I was a little bored. It's obvious what this is :) Maybe I'll get up the gumption one day to write something useful.

GraphicsWindow.Show()

Turtle.Speed = 10

side = 800

fib()

x = 1

y = 1

Sub fib

For x = 1 to 300

z = x + y

x = y

y = z

Turtle.Move(z + 1)

Turtle.Turn(side)

EndFor

EndSub

Answer 18

 Made a star field.   Frustarted I can't specify RGB color.  Tried Graphics.DrawPixel() with clearing sreen, but it flickered like crazy.  Instead I make rectangle objects, and move those.  I simulate darker colors in the back by using some flags in the array so I can alternate the color from dim to white.

Initialize()

Main()

Sub Initialize

GraphicsWindow.Title = "Super Star Field!"

GraphicsWindow.Width = 640

GraphicsWindow.Height = 480

GraphicsWindow.BackgroundColor = "black"

GraphicsWindow.PenWidth = 0

GraphicsWindow.Show()

num_stars = 200

For index = 0 To num_stars

NewStar()

EndFor

EndSub

Sub NewStar

Array.SetValue("star_x", index, Math.GetRandomNumber(100) - 50)

Array.SetValue("star_y", index, Math.GetRandomNumber(100) - 50)

' Pick a random z depth

z = (Math.GetRandomNumber(50) / 100) + 0.50

Array.SetValue("star_z", index, z)

' Start with a dark color and save our shape

GraphicsWindow.BrushColor = "DimGray"

Array.SetValue("star_shape", index, GraphicsWindow.AddRectangle(2, 2))

Array.SetValue("star_color", index, 0)

EndSub

Sub Update

For index = 0 To num_stars

z = Array.GetValue("star_z", index)

x = (Array.GetValue("star_x", index) / z) + 320

y = (Array.GetValue("star_y", index) / z) + 240

shape = Array.GetValue("star_shape", index)

' Next z position

z = z - 0.02

If(x < 0 Or x > 639 Or y < 0 Or y > 479 Or z <= 0) Then

GraphicsWindow.RemoveShape(shape)

NewStar()

Else

' Check if we should make the star brighter

If(z < 0.4) Then

If(Array.GetValue("star_color", index) = 0) Then

GraphicsWindow.BrushColor = "White"

GraphicsWindow.RemoveShape(shape)

shape = GraphicsWindow.AddRectangle(2, 2)

Array.SetValue("star_shape", index, shape)

Array.SetValue("star_color", index, 1)

EndIf

EndIf

GraphicsWindow.MoveShape(shape, x, y)

Array.SetValue("star_z", index, z)

EndIf

EndFor

EndSub

Sub Main

' Run forever

While(1 = 1)

Update()

EndWhile

EndSub

Picture doesn't do this justice, as the real thing is like flying through space :-)

Answer 19

Very nice, Jeff.  You can use RGB colors:

GraphicsWindow.BrushColor = "#EEFFBB"

GetPixel and SetPixel are raster operations and are inherently very inefficient.  Adding and moving shapes (like you have done) is the best way to achieve good performance in these kind of animations.

Answer 20

I had a delay in the main loop, then found out on a 3.2ghz Core 2 Duo, running as fast as the program can, it runs at a "good" speed.

This is kinda crappy though if you think about it, moving as fast as it can 200 stars at a time, it just runs "okay" on a 3.2ghz processor... :P   I guess the idea of Basic though isn't speed.

I wrote this same little program in Quick Basic back in 1993? on a 486 DX2-66, using an SVGA Library for speed and to wait on VSync, it was liquid smooth on that 66mhz processor, so on a 3.2ghz processor, i'd expect the program to run TOO FAST without a delay in there.

Does Small Basic convert to .NET byte code?  Are there future optimizations that could be done or am I just asking too much.  I know again SmallBasic's task isn't necessarily for "game" or graphics development.

Answer 21

desktop.SetWallPaper(Flickr.GetRandomPicture("puppies"))

Program.End()

Short, sweet, and useful.  Interesting language you got there.

Answer 22

Version 2 - I like this better - helps me find a picture I like interactively..

While(word <> "quit")

TextWindow.Show()

word = TextWindow.Read()

If( word <> "quit" )Then

Desktop.SetWallPaper(Flickr.GetRandomPicture(word))

TextWindow.Hide()

Program.Delay(1000)

TextWindow.Show()

Else

TextWindow.Hide()

EndIf

EndWhile

Program.End()

Answer 23

Another turtle space filling curve, looks like I'm not the only one to write one :).. This one draws a hilbert curve.

TextWindow.WriteLine("Order:")

n=TextWindow.ReadNumber()

n=n+1

right()

Sub left

i=i+1

If (i<n) Then

Turtle.TurnRight()

right()

Turtle.Move(10)

Turtle.TurnLeft()

left()

Turtle.Move(10)

left()

Turtle.TurnLeft()

Turtle.Move(10)

right()

Turtle.TurnRight()

EndIf

i=i-1

EndSub

Sub right

i=i+1

If (i<n) Then

Turtle.TurnLeft()

left()

Turtle.Move(10)

Turtle.TurnRight()

right()

Turtle.Move(10)

right()

Turtle.TurnRight()

Turtle.Move(10)

left()

Turtle.TurnLeft()

EndIf

i=i-1

EndSub

Answer 24

I was just messing around with loops and the turtle, and decided I should make something fun. This will take any number x, draw a polygon with x number sides, and off of each side will be a perfect star.

GraphicsWindow.Height = 800

GraphicsWindow.Width = 800

Turtle.Speed = 10

x = 75

Star:

While( s < 5 )

GraphicsWindow.PenColor = GraphicsWindow.GetRandomColor()

Turtle.Move(40)

Turtle.Turn(144)

s = s + 1

While(r < (x - 1) )

If(s = 5) Then

Turtle.Move(-75)

Turtle.Turn(360/x)

Turtle.Move(100)

s = 0

r = r + 1

Else

Goto Star

EndIf

EndWhile

EndWhile

Answer 25

Beth Massi said: I wanted to actually scale the images instead of a fixed height and width but unfortunately the call the ImageList.GetWidthOfImage() keeps crashing (GetHeightOfImage works
fine). Anybody have any clues?

No clues, but I can confirm ImageList.GetWidthOfImage() crashes on WinXP too.

---

Andrew Burton - http://profnano.org

Answer 26

Draws A fractual branch of a tree.



n=7

angle=45

x=0

y=0

GraphicsWindow.Title="Fractal Plant"

GraphicsWindow.PenWidth=0.5

GraphicsWindow.PenColor = "White"

GraphicsWindow.Width=700

GraphicsWindow.Height=500

GraphicsWindow.BackgroundColor="Black"

GraphicsWindow.Show()

X()

Sub X

i=i+1

If (i<n) Then

F()

angle=angle-25

Store()

Store()

X()

Get()

angle=angle+25

X()

Get()

angle=angle+25

F()

Store()

angle=angle+25

F()

X()

Get()

angle=angle-25

X()

EndIf

i=i-1

EndSub

Sub Store

Stack.PushValue("tree",x)

Stack.PushValue("tree",y)

Stack.PushValue("tree",angle)

EndSub

Sub Get

angle=Stack.PopValue("tree")

y=Stack.PopValue("tree")

x=Stack.PopValue("tree")

EndSub

Sub F

i=i+1

If (i<n) Then

x2=x+(Math.Sin(angle))*4

y2=y+(Math.Cos(angle))*4

GraphicsWindow.AddLine(x,y,x2,y2)

x=x2

y=y2

F()

F()

EndIf

i=i-1

EndSub

Answer 27

Regarding the start field program, obviously the issue is the repaint caused by SetPixel which also causes the flashing (the flashing is probably cause that repaint also erases the background first and then redraws? [this is classic issue - in Windows you'd disable the background repaint of that window control]).

Apart from setting flags to the window handle to not repaint its background (or overriding the respective method of the control used in your .NET app) one also needs some method to batch graphics commands. From my experience the best is a command-block (internally implemented with try/finally), doing:

StartGraphics
 ...commands...
EndGraphics

this has to be in the language syntax (better for naive users) if the language doesn't support lambda lists to make the above some BatchUpdate(graphics-commands-as-a-lambda-list) call

cause also call those StartRefresh/EndRefresh, StartUpdate/EndUpdate or whatever sounds explanatory enough for the end user

---

Microsoft MVP J# 2004-2007, Borland Spirit of Delphi 2001

Answer 28

Regarding getWidthOfImage (why not getImageWidth?), maybe the image hasn't yet loaded? (they should wait for it to load or have an option if you want to wait or not). Can try polling the image in a loop (do a small sleep at each loop) till it gets a width or if you can't try/catch errors in SmallBasic (don't remember), just wait for some long enough (?) period first and then try to call the method

---

Microsoft MVP J# 2004-2007, Borland Spirit of Delphi 2001

Answer 29

This seems a fun language to play around with. :-) I'm a big fan of spinning 3D cubes. I'm sure there's a nicer way of implementing this - it is a bit flickery, so consider yourself warned.

GraphicsWindow.Title = "Spinning Cube"

GraphicsWindow.Show()

Time = 0

MainLoop:

RotationX = Time / 30

RotationY = Time / 40

Scale = Math.Min(GraphicsWindow.Width, GraphicsWindow.Height) * (1.2 + Math.Sin(Time / 50)) * 0.5

Time = Time + 1

GraphicsWindow.Clear()

GraphicsWindow.PenWidth = Scale / 200

For x = -1 To 1 Step 2

For y = -1 To 1 Step 2

z = -1

TransformPoint()

StartX = TransformedX

StartY = TransformedY

z = 1

TransformPoint()

GraphicsWindow.AddLine(StartX, StartY, TransformedX, TransformedY)

EndFor

EndFor

For x = -1 To 1 Step 2

For z = -1 To 1 Step 2

y = -1

TransformPoint()

StartX = TransformedX

StartY = TransformedY

y = 1

TransformPoint()

GraphicsWindow.AddLine(StartX, StartY, TransformedX, TransformedY)

EndFor

EndFor

For z = -1 To 1 Step 2

For y = -1 To 1 Step 2

x = -1

TransformPoint()

StartX = TransformedX

StartY = TransformedY

x = 1

TransformPoint()

GraphicsWindow.AddLine(StartX, StartY, TransformedX, TransformedY)

EndFor

EndFor

Program.Delay(10)

Goto MainLoop

'  Inputs: x, y, z, RotationX, RotationY, Scale. Outputs: TransformedX, TransformedY.

Sub TransformPoint

TransformedX = y * Math.Cos(RotationX) - x * Math.Sin(RotationX)

TransformedY = -x * Math.Cos(RotationX) * Math.Sin(RotationY) - y * Math.Sin(RotationX) * Math.Sin(RotationY) - z * Math.Cos(RotationY)

TransformedZ = 3 - x * Math.Cos(RotationX) * Math.Cos(RotationY) - y * Math.Sin(RotationX) * Math.Cos(RotationY) + z * Math.Sin(RotationY)

TransformedX = TransformedX * Scale / TransformedZ + GraphicsWindow.Width / 2

TransformedY = TransformedY * Scale / TransformedZ + GraphicsWindow.Height / 2

EndSub

Answer 30

I've been enjoying working in SmallBasic; it takes me back to when I had a ZX81. I took the paddle game sample and made it work, increase in difficulty and allow the player more control of the angle and speed of the "ball"; next to add breakout style blocks to destroy.
B0ff1n

paddle = GraphicsWindow.AddRectangle(120, 12)

ball = GraphicsWindow.AddEllipse(16, 16)

speed=9

GraphicsWindow.FontSize = 16

GraphicsWindow.MouseMove = OnMouseMove

lives = 3

score = 0

gw = Math.Floor( GraphicsWindow.Width - 8 )

gh = Math.Floor( GraphicsWindow.Height - 20 )

While (lives>0)

x = Math.GetRandomNumber(gw)

y = 36

deltaX = 1

deltaY = 2

GraphicsWindow.MoveShape(ball, (x-8), y)

PrintScore()

'    Sound.PlayChimeAndWait()

For i=1 To 20

GraphicsWindow.BrushColor = GraphicsWindow.GetRandomColor()

GraphicsWindow.DrawText(300, 150, "Get Ready!")

Program.Delay(50)

EndFor

GraphicsWindow.BrushColor = "White"

GraphicsWindow.FillRectangle(10, 100, 630, 200)

While (y < (gh+2))

x = x + deltaX

y = y + deltaY

If (x >= gw Or x <= 8) Then

deltaX = -deltaX

EndIf

If (y <= 36) Then

deltaY = -deltaY

EndIf

GraphicsWindow.MoveShape(ball, (x-8), y)

padX = GraphicsWindow.GetLeftOfShape(paddle)

'TextWindow.WriteLine("X:"+x+" Y:"+y+" padX:"+padX+" gh:"+gh)

If (y >= gh) Then

'TextWindow.WriteLine("Testing for collision")

If (x >= padX And x <= padX + 120) Then

'TextWindow.WriteLine("Hit!")

Sound.PlayClick()

score = score + 10

PrintScore()

deltaY = -deltaY

'did the user hit the ball with the very edge of the paddle?

If (x<=padx+40 Or x>=padx+80) then

If (x<=padx+20 And deltaX>0) then

'*user hit the ball with the "corner" of the paddle; reverse the x-direction too

deltaX = -deltaX

EndIf

If (x>=padx+100 And deltaX<0) then

'*user hit the ball with the "corner" of the paddle; reverse the x-direction too

deltaX = -deltaX

EndIf

If (Math.Abs( deltaX )<2) Then

deltaX = deltaX*2

EndIf

Else

If (Math.Abs(deltaX)>1) Then

deltaX = deltaX/2

EndIf

EndIf

If (Math.Remainder(score,50)=0) Then

speed=speed-1

If (speed<1) Then

speed=1

EndIf

EndIf

'Else

'TextWindow.WriteLine("Missed!")

EndIf

EndIf

'      GraphicsWindow.MoveShape(ball, (x-8), y)

Program.Delay(speed)

EndWhile

lives = lives - 1

EndWhile

GraphicsWindow.ShowMessage("You scored : " + score+ " points", "Paddle - Game Over")

Program.End()

Sub OnMouseMove

paddleX = GraphicsWindow.MouseX

GraphicsWindow.MoveShape(paddle, paddleX - 60, GraphicsWindow.Height - 12)

EndSub

Sub PrintScore

' Clear the score first and then draw the real score text

GraphicsWindow.BrushColor = "White"

GraphicsWindow.FillRectangle(10, 10, 630, 20)

GraphicsWindow.BrushColor = "Black"

GraphicsWindow.DrawText(10, 10, "Score: " + score)

GraphicsWindow.DrawText(300, 10, "Lives: " + lives)

GraphicsWindow.DrawText(540, 10, "Speed: " +speed)

EndSub

The reason why the original sample didn't work for me was that the graphicswindow.height was returning 480.1 and was comparing the y-ordinate to be exactly that; hence my use of math.floor and some >'s rather than ='s.
Great stuff though; now why can't Visual Studio be this good?

Answer 31

Inside the Small Basic Samples folder there's a Fractal example; the fractal is a Sierpinski Triangle. Having written Sierpinski Triangles in other BASIC dialects such as Basic4GL & Brutus2D, I thought I'd write a new version in Small Basic.

' Sierpinski Triangle written in Small Basic

GraphicsWindow.BackgroundColor = "Black"

width = 640

height = 480

x1 = (width / 2)

x2 = (width / 2)

y1 = 0

y2 = 0

maxPoints = 100000

For i = 0 To maxPoints

direct = Math.GetRandomNumber(3)

If (direct = 0) Then

x1 = (x2 + width / 2) / 2

y1 = (y2 + 0) / 2

EndIf

If (direct = 1) Then

x1 = (x2 + 0) / 2

y1 = (y2 + height) / 2

EndIf

If (direct = 2) Then

x1 = (x2 + width) / 2

y1 = (y2 + height) / 2

Endif

GraphicsWindow.SetPixel(x1, y1, "White")

x2 = x1

y2 = y1

EndFor

Answer 32

1	'This is a simple pong game.
2	'Player 1 is on the left, moves with the mouse
3	'Player 2 is on the right, moves with the arrow key
4	'Stop by pressing esc
5
6
7	'const
8	BALLSIZE = 15
9	PADDLEWIDTH = 10
10	PADDLEHEIGHT = 100
11	SPEED = 3
12	PlAYERDISTANCE = 20
13	PLAYERSPEED = 50
14
15	continue = 1
16	wanttoplay = 1
17
18	player1Score = 0
19	player2Score = 0
20
21
22	Start()
23	Program.Delay(2000)
24	Program.End()
25
26
27	Sub Start
28	init()
29	program.delay(1000)
30	GraphicsWindow.MouseMove = OnMouseMove
31	GraphicsWindow.KeyDown = OnKeyPressed
32	GraphicsWindow.KeyUp = OnKeyReleased
33	While(wanttoplay = 1)
34	Moveball()
35	endwhile
36	EndSub
37
38	Sub init
39
40	GraphicsWindow.Title = "Dan's pong"
41	GraphicsWindow.BackgroundColor= "black"
42	GraphicsWindow.Width = 800
43	GraphicsWindow.Height = 600
44	GraphicsWindow.Clear()
45
46	'setup background
47	GraphicsWindow.BrushColor = "LightGoldenrodYellow"
48	GraphicsWindow.FillRectangle(0,500,800,100)
49
50	'initialize players
51	GraphicsWindow.BrushColor = "red"
52	GraphicsWindow.PenColor = "red"
53	player1 = GraphicsWindow.AddRectangle(PADDLEWIDTH,PADDLEHEIGHT)
54
55
56	GraphicsWindow.BrushColor = "blue"
57	GraphicsWindow.PenColor = "blue"
58	player2 = GraphicsWindow.AddRectangle(PADDLEWIDTH,PADDLEHEIGHT)
59
60
61	'initialize ball
62	GraphicsWindow.BrushColor = "SpringGreen"
63	GraphicsWindow.PenColor = "SpringGreen"
64	ball = GraphicsWindow.AddEllipse(BALLSIZE,BALLSIZE)
65
66	'randomize ball start direction
67	temp = Math.GetRandomNumber(10)
68	If (temp < 5) Then
69	deltaY = 1
70	Else
71	deltaY = -1
72	endif
73
74	temp = Math.GetRandomNumber(10)
75	If (temp < 5) Then
76	deltaX = 1
77	Else
78	deltaX = -1
79	endif
80
81
82
83	'position players and ball
84	GraphicsWindow.MoveShape(player1,0,200)
85	GraphicsWindow.MoveShape(player2,800 - PADDLEWIDTH,200)
86	GraphicsWindow.MoveShape(ball,(800-BALLSIZE)/2,143)
87
88	'draw scoring board
89	GraphicsWindow.FontSize = 40
90	GraphicsWindow.BrushColor = "black"
91	GraphicsWindow.DrawText(360,520,player1Score +" - " + player2Score)
92
93	EndSub
94
95
96	Sub OnMouseMove
97	paddleY = GraphicsWindow.MouseY
98	If (paddleY < 50)then
99	GraphicsWindow.MoveShape(player1, GraphicsWindow.Width - 800,0)
100	Else
101	If (paddleY > 450) then
102	GraphicsWindow.MoveShape(player1, GraphicsWindow.Width - 800,400)
103	else
104	GraphicsWindow.MoveShape(player1, GraphicsWindow.Width - 800,paddleY-PADDLEHEIGHT/2)
105	EndIf
106	Endif
107	EndSub
108
109
110	Sub OnKeyPressed
111	key = GraphicsWindow.LastKey
112
113	If (key = "Up" Or key = "Down") Then
114	player2move()
115	else
116	command()
117	EndIf
118
119	EndSub
120
121
122	'reset player2 speed
123	Sub OnKeyReleased
124	PlAYERDISTANCE = 20
125	EndSub
126
127	Sub player2move
128	curpos = GraphicsWindow.GetTopOfShape(player2)
129	newpos = curpos
130	If (key = "Up") Then
131	newpos = curpos - PLAYERDISTANCE
132	If (newpos < 0) Then
133	newpos = 0
134	EndIf
135	EndIf
136	If (key = "Down") Then
137	newpos = curpos + PLAYERDISTANCE
138	If (newpos > 500 - PADDLEHEIGHT) Then
139	newpos = 500 - PADDLEHEIGHT
140	EndIf
141	EndIf
142	GraphicsWindow.AnimateShape(player2,800-PADDLEWIDTH,newpos,PLAYERSPEED)
143
144	'the longer you hold the key, the faster the paddle moves
145	PlAYERDISTANCE = PlAYERDISTANCE*1.1
146	EndSub
147
148
149
150	'stop the game
151	Sub command
152	If (key = "Escape") Then
153	wanttoplay = 0
154	EndIf
155
156	EndSub
157
158
159
160	Sub Moveball
161	x = GraphicsWindow.GetLeftOfShape(ball)
162	y = GraphicsWindow.GetTopOfShape(ball)
163	x = x + deltaX
164	y = y + deltaY
165
166	If (y < 0 Or y > 500 - BALLSIZE) Then
167	deltaY = -deltaY
168	Sound.PlayClick()
169	endif
170
171	If (x < PADDLEWIDTH Or x > 800 - PADDLEWIDTH - BALLSIZE) Then
172	deltaX = -deltaX
173	Sound.PlayClick()
174	endif
175
176	GraphicsWindow.MoveShape(ball,x,y)
177	Program.Delay(SPEED)
178	checkforgoal()
179	endsub
180
181
182	Sub checkforgoal
183	player1pos = GraphicsWindow.GetTopOfShape(player1)
184	player2pos = GraphicsWindow.GetTopOfShape(player2)
185	ballXpos = GraphicsWindow.GetLeftOfShape(ball)
186	ballYpos = GraphicsWindow.GetTopOfShape(ball)
187
188
189	If (ballXpos < 0 + PADDLEWIDTH) Then
190	If (ballYpos < player1pos Or ballYpos > player1pos + PADDLEHEIGHT) Then
191	player2Score = player2Score + 1
192	sound.PlayBellRingAndWait()
193	init()
194	endif
195	EndIf
196
197
198	If (ballXpos > 800 - PADDLEWIDTH - ballsize) Then
199	If (ballYpos < player2pos Or ballYpos > player2pos + PADDLEHEIGHT) Then
200	player1Score = player1Score + 1
201	sound.PlayBellRingAndWait()
202	init()
203	endif
204	EndIf
205
206	endsub
207
208

Answer 33

 Jeff Sidlosky's Star field simulation is the featured sample of this week.

Answer 34

GraphicsWindow.BackgroundColor = "000000"

GraphicsWindow.PenColor = "#00CC44"

vDistance = 100

pixelsPerUnit = 70

centerX = GraphicsWindow.Width / 2

centerY = GraphicsWindow.Height / 2

oldX = centerX

oldY = centerY + vDistance

Turtle.Show()

Turtle.Speed = 7

Turtle.PenUp()

Turtle.Move(-vDistance)

Turtle.PenDown()

Turtle.TurnLeft()

Turtle.Speed = 10

For fi = 0 To 360

radianFi = Math.GetRadians(fi)

ro =   (1 + Math.Sin(radianFi)) * (1 + 0.9 * Math.Cos(8 *  radianFi)) * (1 + 0.1 * Math.Cos(24 *  radianFi))

dx = ro * Math.Cos(radianFi) * pixelsPerUnit

dy = ro * Math.Sin(radianFi) * pixelsPerUnit

newDistance = Math.SquareRoot(dx * dx + dy * dy)

newX = centerX - dx

newY = centerY - dy + vDistance

GraphicsWindow.DrawLine(oldX, oldY, newX, newY)

oldX = newX

oldY = newY

If (newDistance >= 10) Then

Turtle.Turn(fi)

Turtle.Move(newDistance)

Turtle.Turn(180)

Turtle.Move(newDistance)

Turtle.Turn(180-fi)

EndIf

EndFor

Turtle.TurnRight()

Turtle.Speed = 5

Turtle.Move(-vDistance / 2)

Turtle.PenUp()

Answer 35

I would like to submit my 4 state button :D.

http://smallbasic.com/drop/buttonclick.zip

Thanks,
 Pacolaco

Answer 36

 There is a simple game, I know about few bugs (enemy balls get stuck, sometimes it starts with bad resolution - I don't know why), but it should works. If you wish, you can rewrite OnKeyDown to better movements.

PLAYERSIZE = 16

TARGESIZE = 10

ENEMYSIZE = 20

alive = "true"

score = 0

numberOfBalls = 0

bonus = 1000

currentX = 0

currentY = 0

newX = 0

newY = 0

targetBallX = 0

targetBallY = 0

Init()

Start()

Program.Delay(2000)

Program.End()

Sub Init

GraphicsWindow.Height = 400

GraphicsWindow.Width = 400

GraphicsWindow.BackgroundColor = "Gainsboro"

GraphicsWindow.KeyDown = OnKeyDown

EndSub

Sub Start

GraphicsWindow.BrushColor = "Red"

playerBall = GraphicsWindow.AddEllipse(PLAYERSIZE, PLAYERSIZE)

GraphicsWindow.MoveShape(playerBall, currentX, currentY)

GraphicsWindow.BrushColor = "Gold"

targetBall = GraphicsWindow.AddEllipse(TARGESIZE, TARGESIZE)

MoveTargetBall()

AddNewEnemy()

Playing()

GraphicsWindow.Clear()

Program.Delay(3000)

Program.End()

EndSub

Sub Playing

While (alive = "true")

Program.Delay(10)

currentX = currentX + newX

currentY = currentY + newY

If (currentX < 0) Then

currentX = 0

EndIf

If (currentX > GraphicsWindow.Width - PLAYERSIZE) Then

currentX = GraphicsWindow.Width - PLAYERSIZE

EndIf

If (currentY < 0) Then

currentY = 0

EndIf

If (currentY > GraphicsWindow.Height - PLAYERSIZE) Then

currentY = GraphicsWindow.Height - PLAYERSIZE

EndIf

GraphicsWindow.MoveShape(playerBall, currentX, currentY)

For i = 0 To numberOfBalls - 1

moveX = 0

moveY = 0

If (Array.GetValue("axis", i) = 1) Then

moveX = Array.GetValue("speed", i)

Else

moveY = Array.GetValue("speed", i)

EndIf

x = Array.GetValue("x", i) + moveX

y = Array.GetValue("y", i) + moveY

If (x < 0 Or x > GraphicsWindow.Width - ENEMYSIZE) Then

Array.SetValue("speed", i, -Array.GetValue("speed", i))

EndIf

If (y < 0 Or y > GraphicsWindow.Height - ENEMYSIZE) Then

Array.SetValue("speed", i, -Array.GetValue("speed", i))

EndIf

Array.SetValue("x", i, x)

Array.SetValue("y", i, y)

GraphicsWindow.MoveShape(Array.GetValue("balls", i), x, y)

If (Math.Abs((currentX + (PLAYERSIZE / 2)) - (x + (ENEMYSIZE / 2))) < ((PLAYERSIZE + ENEMYSIZE) / 2) And Math.Abs((currentY + (PLAYERSIZE / 2)) - (y + (ENEMYSIZE / 2))) < ((PLAYERSIZE + ENEMYSIZE) / 2)) Then

alive = "false"

EndIf

EndFor

If (Math.Abs((currentX + (PLAYERSIZE / 2)) - (targetBallX + (TARGESIZE / 2))) < ((PLAYERSIZE + TARGESIZE) / 2) And Math.Abs((currentY + (PLAYERSIZE / 2)) - (targetBallY + (TARGESIZE / 2))) < ((PLAYERSIZE + TARGESIZE) / 2)) Then

score = score + 2000 + numberOfBalls * 100

If (bonus > 0) Then

score = score + bonus

EndIf

bonus = 1000

MoveTargetBall()

AddNewEnemy()

EndIf

bonus = bonus - 1

GraphicsWindow.Title = "Score: " + score

EndWhile

EndSub

Sub AddNewEnemy

GraphicsWindow.BrushColor = "SteelBlue"

ball = GraphicsWindow.AddEllipse(ENEMYSIZE, ENEMYSIZE)

Array.SetValue("balls", numberOfBalls, ball)

Array.SetValue("axis", numberOfBalls, Math.GetRandomNumber(2) + 1)

Array.SetValue("x", numberOfBalls, GraphicsWindow.Height - Math.GetRandomNumber(GraphicsWindow.Height - ENEMYSIZE))

Array.SetValue("y", numberOfBalls, GraphicsWindow.Width - Math.GetRandomNumber(GraphicsWindow.Width - ENEMYSIZE))

Array.SetValue("speed", numberOfBalls, Math.GetRandomNumber(4) + 1)

GraphicsWindow.MoveShape(ball, Array.GetValue("x", numberOfBalls), Array.GetValue("y", numberOfBalls))

numberOfBalls = numberOfBalls + 1

axis = -axis

EndSub

Sub MoveTargetBall

targetBallX = GraphicsWindow.Height - Math.GetRandomNumber(GraphicsWindow.Height - TARGESIZE)

targetBallY = GraphicsWindow.Width - Math.GetRandomNumber(GraphicsWindow.Width - TARGESIZE)

GraphicsWindow.MoveShape(targetBall, targetBallX, targetBallY)

EndSub

Sub OnKeyDown

key = GraphicsWindow.LastKey

If (key = "Down") Then

If (newY = 0) Then

newY = 1

Else

newY = 0

EndIf

EndIf

If (key = "Up") Then

If (newY = 0) Then

newY = -1

Else

newY = 0

EndIf

EndIf

If (key = "Left") Then

If (newX = 0) Then

newX = -1

Else

newX = 0

EndIf

EndIf

If (key = "Right") Then

If (newX = 0) Then

newX = 1

Else

newX = 0

EndIf

EndIf

EndSub

Answer 37

Here's a screenshot for Nidzo's game.  It was a blast!

Answer 38

Please when you post samples deselect the "line numbers" option. It's not well implemented in the forums and one copy-pastes the numbers too with the code (should have a real HTML table ther instead, probably they use a CSS layout or something). Bad for beginners that want to try some sample

---

Microsoft MVP J# 2004-2007, Borland Spirit of Delphi 2001

Answer 39

Well this is my 1st "app" made in SB. It's a console slot machine (?) It's not really hard to code at all, and SB makes it easier. It still needs some work on it to make it smaller. It's in spanish, sorry =/

'Tragamonedas de consola por Rodrigo Bellusci 2008

'Hecho en Microsoft SmallBasic©

dinero = 500

TextWindow.WriteLine("Introduzca su nombre:")

name = TextWindow.Read()

TextWindow.WriteLine("Bien Sr/a." + name + ". Su cantidad de dinero es:$" + dinero)

apuestaStart:

TextWindow.Write("¿Cuánto quiere apostar?:")

apuesta = TextWindow.Read()

If (apuesta > dinero) Then

TextWindow.WriteLine("No puedes apostar más de lo que tienes.")

Goto apuestaStart

EndIf

TextWindow.WriteLine("Apuesta hecha")

nro1 = Math.GetRandomNumber(2)

nro2 = Math.GetRandomNumber(1)

TextWindow.Write("| ")

TextWindow.Write(nro1)

TextWindow.Write(" |")

TextWindow.Write(" ")

TextWindow.Write("| ")

TextWindow.Write(nro2)

TextWindow.Write(" |")

TextWindow.Write(" ")

If (nro1 = nro2) Then

dinerodinero = dinero - apuesta + (apuesta * 2)

TextWindow.Write("Ha ganado, su dinero es:$")

TextWindow.Write(dinero)

TextWindow.WriteLine(" ")

Else

dinerodinero = dinero - apuesta

TextWindow.Write("Ha perdido. Su dinero es:$")

TextWindow.Write(dinero)

TextWindow.WriteLine(" ")

EndIf

If (dinero = 0) Then

TextWindow.WriteLine("Gracias por jugar.")

Goto goodbye

EndIf

TextWindow.WriteLine("Quiere jugar otra vez?:")

replay = TextWindow.Read()

If (replay = "Si") Then

Goto apuestaStart

EndIf

goodbye:

TextWindow.WriteLine("Vuelva pronto.")

Pic

P.S: My english isn't so good, sorry. I'm from Argentina

Answer 40

This is fun! Thanks!

This program performs two sorts on colored cubes in a window - a bubble sort and a selection sort.

'Globals

xlimit = 10

ylimit = 10

cs = 64

cellcnt = xlimit * ylimit

GraphicsWindow.BackgroundColor = "Khaki"

GraphicsWindow.Title = "bsort"

GraphicsWindow.Width = (xlimit * cs)

GraphicsWindow.Height = (ylimit * cs)

GraphicsWindow.Show()

InitParr()

GraphicsWindow.Title = "bsort, click in window to start bubble sort"

Pause()

BubbleSort()

wtitle = GraphicsWindow.Title

GraphicsWindow.Title = GraphicsWindow.Title + " ; click in window to start selection sort"

Pause()

SelectionSort()

wtitle = GraphicsWindow.Title

GraphicsWindow.Title = GraphicsWindow.Title + " ; click in window to exit"

Pause()

Program.End()

Sub BubbleSort

DrawSarr()

stopSort = 0

GraphicsWindow.Title = "bubble+shaker sort, " + cellcnt + " cells, sorting ... press any key to stop"

GraphicsWindow.KeyDown = onKey

base = 1

slimit = cellcnt - 1

swap = 1

While (swap > 0)

swap = 0

For ai = base To slimit

If (stopSort = 1) Then

Goto stopBubble

EndIf

bubbleCmpSwp()

EndFor

' plus shaker, turn turtles to rabits

If (swap = 0) Then

Goto stopBubble

EndIf

' For i = (slimit - 1) To 1 Step -1 -- bug, for won't count down

ai = slimit - 1

While (ai >= base)

If (stopSort = 1) Then

Goto stopBubble

EndIf

bubbleCmpSwp()

ai = ai - 1

EndWhile

base = base + 1

slimit = slimit - 1

EndWhile

stopBubble:

GraphicsWindow.Title = "bubble sort, " + cellcnt + " cells, " + cmpCnt + " cmp " + swpCnt + " swp"

EndSub

Sub SelectionSort

DrawSarr()

stopSort = 0

GraphicsWindow.Title = "selection sort, " + cellcnt + " cells, sorting ... press any key to stop"

GraphicsWindow.KeyDown = onKey

For ai = 1 To cellcnt - 1

a = Array.GetValue("sarr",ai)

minbi = ai

For i = (ai + 1) To cellcnt

If (stopSort = 1) Then

Goto stopSelection

EndIf

b = Array.GetValue("sarr",i)

cmpCnt = cmpCnt + 1

If (b < a) Then

minbi = i

a = b

EndIf

EndFor

If (ai <> minbi) Then

bi = minbi

SwapAB()

EndIf

EndFor

stopSelection:

GraphicsWindow.Title = "selection sort, " + cellcnt + " cells, " + cmpCnt + " cmp " + swpCnt + " swp"

EndSub

Sub Pause

wait = 1

GraphicsWindow.MouseDown = Unwait

While (wait = 1)

Program.Delay(250)

EndWhile

EndSub

Sub Unwait

wait = 0

EndSub

sub onKey

stopSort = 1

EndSub

sub getXY

lindex = index - 1

x = Math.Remainder(lindex,xlimit) * cs

y = Math.Floor((lindex/xlimit)) * cs

EndSub

Sub bubbleCmpSwp

a = Array.GetValue("sarr",ai)

b = Array.GetValue("sarr",(ai+1))

cmpCnt = cmpCnt + 1

If (b < a) Then

bi = ai + 1

SwapAB()

swap = 1

EndIf

EndSub

Sub SwapAB

'ai, bi are indexes into sarr

la = array.GetValue("sarr",ai)

lb = array.GetValue("sarr",bi)

index = ai

getXY()

GraphicsWindow.BrushColor = Array.GetValue("carr",lb)

GraphicsWindow.FillRectangle(x,y,cs,cs)

index = bi

getXY()

GraphicsWindow.BrushColor = Array.GetValue("carr",la)

GraphicsWindow.FillRectangle(x,y,cs,cs)

Array.SetValue("sarr",ai,lb)

Array.SetValue("sarr",bi,la)

swpCnt = swpCnt + 1

EndSub

Sub DrawSarr

GraphicsWindow.Title = "bsort, initializing sort table"

For index = 1 To cellcnt

a = Array.GetValue("parr",index)

Array.SetValue("sarr",index,a)

getXY()

GraphicsWindow.BrushColor = Array.GetValue("carr",a)

GraphicsWindow.FillRectangle(x,y,cs,cs)

EndFor

cmpCnt = 0

swpCnt = 0

EndSub

Sub InitParr

' Global array of sortable colors

Array.SetValue("carr",1,"White")

Array.SetValue("carr",2,"Blue")

Array.SetValue("carr",3,"Cyan")

Array.SetValue("carr",4,"Gray")

Array.SetValue("carr",5,"Green")

Array.SetValue("carr",6,"Magenta")

Array.SetValue("carr",7,"Red")

Array.SetValue("carr",8,"Yellow")

Array.SetValue("carr",9,"Black")

Array.SetValue("carr",10,"DarkBlue")

Array.SetValue("carr",11,"CadetBlue")

Array.SetValue("carr",12,"DimGray")

Array.SetValue("carr",13,"DarkGreen")

Array.SetValue("carr",14,"DarkMagenta")

Array.SetValue("carr",15,"DarkRed")

Array.SetValue("carr",16,"DarkOrange")

' build array to sort

For i = 1 To cellcnt

cell = Math.GetRandomNumber(16) + 1

Array.SetValue("parr",i,cell)

EndFor

EndSub

Sub DumpSarr

j = 0

For i = 1 To cellcnt

j = j +1

TextWindow.Write(Array.GetValue("sarr",i) + " ")

If ( j = 25 ) Then

TextWindow.WriteLine(" ")

j = 0

EndIf

EndFor

EndSub

Answer 41

Very slow...

' Draws the mandelbrot & julia set on the graphics window

' See http://en.wikipedia.org/wiki/Mandelbrot_set#For_programmers and

' http://en.wikipedia.org/wiki/Julia_set

'

' Author: Matthias Loeu

' Date: 24 November 2008

GraphicsWindow.Show()

' Size of the window (make it >= resolution)

GraphicsWindow.Width = 800

GraphicsWindow.Height = 800

' Resolution of the rendering, higher = better & slower

resolutionx = 300

resolutiony = 300

' The section of the complex plane we are interested in (x + y*i)

minx = -1.5

miny = -1.3

maxx = 1.5

maxy = 1.3

' The complex parameter (for the julia set)

cx = -0.4

cy = 0.6

' Draw the mandelbrot (1) or julia (0)

draw_mandelbrot = 0

' Max number of iterations, higher = more accurate & slower

max_iter = 500

If (minx > maxx) Then

t = minx

minx = maxx

maxx = t

EndIf

If (miny > maxy) Then

t = miny

miny = maxy

maxy = t

EndIf

'TextWindow.WriteLine("min (" + minx + ", " + miny + ")")

'TextWindow.WriteLine("max (" + maxx + ", " + maxy + ")")

' Step size, in the complex plane

stepx = (maxx - minx)/resolutionx

stepy = (maxy - miny)/resolutiony

' Size of a "pixel"

sizex = GraphicsWindow.Width / resolutionx

sizey = GraphicsWindow.Height / resolutiony

' The colors

Array.SetValue("color", 0, "white")

Array.SetValue("color", 1, "lavender")

Array.SetValue("color", 2, "thistle")

Array.SetValue("color", 3, "plum")

Array.SetValue("color", 4, "violet")

Array.SetValue("color", 5, "orchid")

Array.SetValue("color", 6, "fuchsia")

Array.SetValue("color", 7, "mediumorchid")

Array.SetValue("color", 8, "mediumpurple")

Array.SetValue("color", 9, "blueviolet")

Array.SetValue("color", 10, "darkviolet")

Array.SetValue("color", 11, "darkorchid")

Array.SetValue("color", 12, "purple")

Array.SetValue("color", 13, "indigo")

count_colors = 13

' The actual computations

start = Clock.Hour*3600 + 60*Clock.Minute + Clock.Second

' loop trough every "pixel"

For i=1 To resolutionx

For j=1 To resolutiony

' point in the complex plane

x = minx + i * stepx

y = miny + j * stepy

iter = 0

If (draw_mandelbrot = 1) Then

cx = x

cy = y

EndIf

' iterate...

While (x * x + y * y <= 4 And iter < max_iter)

' compute z = z^2 + c

t = x * x - y * y + cx

y = 2 * x * y + cy

x = t

iter = iter + 1

EndWhile

GraphicsWindow.BrushColor = Array.GetValue("color", Math.Floor(count_colors * iter / max_iter))

' Draw a "pixel"

GraphicsWindow.FillRectangle((i-1)*sizex, (j-1)*sizey, sizex, sizey)

EndFor

'TextWindow.Write(i + " ")

EndFor

' Running this program during midnight is bad...

end = 3600*Clock.Hour + 60*Clock.Minute + Clock.Second

GraphicsWindow.BrushColor = "black"

GraphicsWindow.DrawText(0, 0, "Finished in " + (end-start) + " seconds")

Image Image 2

Answer 42

The following is code to search a specific text file for specific text and return the entire line it appears in.

filepath = "C:\testfilepath.txt"

searchtext = "text to find"

line = 1

While (File.ReadLine(filepath, line) <> "")

filetext = File.ReadLine(filepath, line)

If (Text.IsSubText(filetext,searchtext)) Then

TextWindow.WriteLine(filetext)

EndIf

line = line + 1

EndWhile

Answer 43

OK, I finally put one together that I can post.
It's super simple but it's pretty.  :-)

Randomize a color.
Then just draw line from top-left to bottom-right of graphic screen, increase the X at top and decrease bottom X by an random number.
When X reaches top-right and bottom-left, choose another random color and start increaseing the right-hand Y and decreasing the left-hand Y by a different random number.
Start over again.

It would have taken less time if I would have left it at that, but noooo.  I had to add instructions and the ability to Exit out.
...and while I was reading keyboard commands, why not add the ability to slow down the spin of the spoke?

I call it Random Spoke.

*Problem Corrected - small problem with program locking-up.  Random step was finding a number between 0 and 99.  When the step was zero, the program would lock-up.  So added 1 to each of the two "S =" lines.*

'Setup graphics window.

GraphicsWindow.Height=600

GraphicsWindow.Width=600  GraphicsWindow.Height=600

GraphicsWindow.Show()

'Show instructions

GraphicsWindow.Title="Random Spoke instructions"

GraphicsWindow.BrushColor = "Black"

GraphicsWindow.DrawText(10,20,"Simple instructions...")

GraphicsWindow.DrawText(30,40,"Down arrow to decrease speed.")

GraphicsWindow.DrawText(30,60,"Up arrow to increase speed.")

GraphicsWindow.DrawText(30,75,"(Spoke starts at fastest speed.)")

GraphicsWindow.DrawText(30,95,"Escape to end program.")

GraphicsWindow.DrawText(10,120,"Press Space Bar to start.")

While (GraphicsWindow.LastKey <> "Space")

EndWhile

'Init

GraphicsWindow.BackgroundColor=0

GraphicsWindow.Title="What does up, must come down.  Spinning wheel, got to go round..."

'Run game until

While (EndProgram<>"yes")

Start()

EndWhile

Program.End()

Sub Start

' spoke turn left/right

GraphicsWindow.PenColor = GraphicsWindow.GetRandomColor()

S = Math.GetRandomNumber(100) + 1

For X = 0 To 600 Step S

GraphicsWindow.DrawLine(X,0,600-X,600)

Program.Delay(delay)

'   check keypress

If (GraphicsWindow.LastKey = "Escape") Then

EndProgram = "yes"

EndIf

If (GraphicsWindow.LastKey = "Down") Then

delay = delay + 1

EndIf

If (GraphicsWindow.LastKey = "Up") Then

delay = delay - 1

If (delay < 0) Then

delay = 0

EndIf

EndIf

EndFor

' spoke turn up/down

GraphicsWindow.PenColor = GraphicsWindow.GetRandomColor()

S = Math.GetRandomNumber(100) + 1

For Y = 0 To 600 Step S

GraphicsWindow.DrawLine(600,Y,0,600-y)

Program.Delay(delay)

'   check keypress

If (GraphicsWindow.LastKey = "Escape") Then

EndProgram = "yes"

EndIf

If (GraphicsWindow.LastKey = "Down") Then

delay = delay + 1

EndIf

If (GraphicsWindow.LastKey = "Up") Then

delay = delay - 1

If (delay < 0) Then

delay = 0

EndIf

EndIf

EndFor

EndSub

Answer 44

Nice DRC. Although the program quickly freezes on my PC.

Answer 45

I didn't have a problem on my work PC, but on my home PC (which is much faster) the graphics window keeps the correct width but the height is almost double the size and, like you Dink, it locks up after just a few passes.

I know it is not a simple mistake, like the program is running but the lines are not drawing, because the Esc key doesn't work.
I'm going to post this as new thread and see if anyone has any ideas.

Answer 46

index = 0
NeedToDraw = 1
GraphicsWindow.KeyDown = OnKeyDown
InitMatrix()
Play()

Sub InitMatrix
    GraphicsWindow.BackgroundColor = "#000000"
    Array.SetValue("color", 00, "#003300")
    Array.SetValue("color", 01, "#004400")
    Array.SetValue("color", 02, "#005500")
    Array.SetValue("color", 03, "#006600")
    Array.SetValue("color", 04, "#007700")
    Array.SetValue("color", 05, "#008800")
    Array.SetValue("color", 06, "#009900")
    Array.SetValue("color", 17, "#00AA00")
    Array.SetValue("color", 18, "#00BB00")
    Array.SetValue("color", 19, "#00CC00")
    Array.SetValue("color", 10, "#00DD00")
    Array.SetValue("color", 11, "#00EE00")
    Array.SetValue("color", 12, "#00FF00")
    For x = 0 To GraphicsWindow.Width Step 13
        index = index + 1
        Array.SetValue("x", index, x)
        Array.SetValue("y", index, Math.GetRandomNumber(GraphicsWindow.Height))
        Array.SetValue("dy", index, 5 + Math.GetRandomNumber(7))

        Array.SetValue("colors", index, Array.GetValue("color", Math.GetRandomNumber(13)))
        If(Math.GetRandomNumber(2) = 0) Then
            Array.SetValue("ch", index, "0")
        Else
            Array.SetValue("ch", index, "1")
        EndIf
    EndFor
EndSub

Sub DrawMatrix
    For i = 0 To index
        x = Array.GetValue("x", i)
        y = Array.GetValue("y", i)
        GraphicsWindow.BrushColor = GraphicsWindow.BackgroundColor
        GraphicsWindow.FillRectangle(x, y, 20, 20)
        y = y + Array.GetValue("dy", i)
        GraphicsWindow.BrushColor = Array.GetValue("colors", i)
        GraphicsWindow.DrawText(x, y, Array.GetValue("ch", i))
        If(y > GraphicsWindow.Height) Then
            y = -20
            Array.SetValue("colors", i, Array.GetValue("color", Math.GetRandomNumber(13)))
        EndIf
        Array.SetValue("y", i, y)
    EndFor
EndSub

Sub Play
    While(NeedToDraw = 1)
        DrawMatrix()
    EndWhile
    Program.End()
EndSub

Sub OnKeyDown
    key = GraphicsWindow.LastKey
    If(key = "Escape") Then
        NeedToDraw = 0
    EndIf
EndSub

Answer 47

Can you please post the code without the line numbering so we can copy and paste it and run the code.

Answer 48

I developed an example program that converts decimal numbers into their hexadecimal equivalent.
It initially sounded like a rather simple endeavor, a little text manipulation, and a bit of recursion using the stack to pass values to subroutines.
Two things to keep in mind:
Firstly, all variables seem to be global, when recursing, push everything you may need onto the stack as it will most
likely get trashed.
Secondly, sometimes text will get treated as a number and concatenating two such strings results in them getting added rather than appended.

The first one is the most important to remember in general, but the second one chewed up the most of my time to find out.
The Text.Append that is planned for Xmas release will be gladly welcomed :)

I am aware that the recursion is totally unnecessary and extremely inefficient but thought it a good way to demonstrate the concept.
I'll re-write this to do away with the recursion and use something simpler to demo that, maybe Newton's square root approximation or factorials.

'Demonstration code to convert decimal numbers in hexadecimal

'By tekgno , Wednesday 3 December 2008

'This example demonstrates recursion and some text manipulation

'Initialise our array of decimal to hex characters

Array.SetValue("dec2hex",0,"0")

Array.SetValue("dec2hex",1,"1")

Array.SetValue("dec2hex",2,"2")

Array.SetValue("dec2hex",3,"3")

Array.SetValue("dec2hex",4,"4")

Array.SetValue("dec2hex",5,"5")

Array.SetValue("dec2hex",6,"6")

Array.SetValue("dec2hex",7,"7")

Array.SetValue("dec2hex",8,"8")

Array.SetValue("dec2hex",9,"9")

Array.SetValue("dec2hex",10,"A")

Array.SetValue("dec2hex",11,"B")

Array.SetValue("dec2hex",12,"C")

Array.SetValue("dec2hex",13,"D")

Array.SetValue("dec2hex",14,"E")

Array.SetValue("dec2hex",15,"F")

TextWindow.Show()

'Loop through a range of numbers to demonstrate

For i = 1 To 255

'In order to pass values to our subroutine, we use the stack

'Push on here

Stack.PushValue("hex",i)

'Call the sub

toHex()

'Pop our answer off the top of the stack

txt = Stack.PopValue("hex")

TextWindow.WriteLine(i+"     "+txt)

endfor

Sub toHex

'Get the value passed to the sub

h = Stack.PopValue("hex")

t = ""

'If 'h' is greater than 15, then we cannot use our lookup table

If (h > 15) Then

'Push everything we need onto the stack

'We need to do this otherwise everything seems to get trashed

Stack.PushValue("hex",h)

'Take the modulus of the value we wish to convert, we convert this with our lookup table

r = Math.Remainder(h,16)

Stack.PushValue("hex",r)

'Divide the value by 16 and recurse to convert it

j = (h - r) / 16

Stack.PushValue("hex",j)

toHex()

'Retrieve the answer and all our other variables

t = Stack.PopValue("hex")

r = Stack.PopValue("hex")

h = Stack.PopValue("hex")

EndIf

'If h < 16 we can use our lookup table

If (h < 16) Then

r = h

EndIf

'We convert for a single character

c = Array.GetValue("dec2hex",r)

'Append our converted character to the rest of the string if applicable

'The extra space and the line to remove it again are needed as

'       smallbasic will treat the text as numbers if it can

'       Christmas release will allow us to use Text.Append and clean this up

t = " " + t  + c

t = Text.GetSubText(t,1,text.GetLength(t)-1)

'Finally Push our answer onto the stack

Stack.PushValue("hex",t)

EndSub

Answer 49

OK, this version lacks recursion, but still uses the stack to pass values to/from the sub.

'Demonstration code to convert decimal numbers in hexadecimal

' Version 2.0

'By tekgno , Wednesday 3 December 2008

'Demonstrates use of the stack to pass values to/from a sub

'Initialise our array of decimal to hex characters

Array.SetValue("dec2hex",0,"0")

Array.SetValue("dec2hex",1,"1")

Array.SetValue("dec2hex",2,"2")

Array.SetValue("dec2hex",3,"3")

Array.SetValue("dec2hex",4,"4")

Array.SetValue("dec2hex",5,"5")

Array.SetValue("dec2hex",6,"6")

Array.SetValue("dec2hex",7,"7")

Array.SetValue("dec2hex",8,"8")

Array.SetValue("dec2hex",9,"9")

Array.SetValue("dec2hex",10,"A")

Array.SetValue("dec2hex",11,"B")

Array.SetValue("dec2hex",12,"C")

Array.SetValue("dec2hex",13,"D")

Array.SetValue("dec2hex",14,"E")

Array.SetValue("dec2hex",15,"F")

TextWindow.Show()

'Loop through a range of numbers to demonstrate

For i = 1 To 255

'In order to pass values to our subroutine, we use the stack

'Push on here

Stack.PushValue("hex",i)

'Call the sub

toHex()

'Pop our answer off the top of the stack

txt = Stack.PopValue("hex")

TextWindow.WriteLine(i+"     "+txt)

endfor

Sub toHex

'Get the value passed to the sub

h = Stack.PopValue("hex")

t = ""

While (h > 0)

'Take the modulus of the value we wish to convert, we convert this with our lookup table

r = Math.Remainder(h,16)

'The extra space and the line to remove it again are needed as

'       smallbasic will treat the text as numbers if it can

'       Christmas release will allow us to use Text.Append and clean this up

t = " " + Array.GetValue("dec2hex",r) + t

t = Text.GetSubText(t,1,text.GetLength(t)-1)

'Divide the value by 16

h = (h - r) / 16

EndWhile

'Finally Push our answer onto the stack

Stack.PushValue("hex",t)

EndSub

Answer 50

Here is a much easier to understand recursion demo for calculating factorials:

'Factorials!

'By Tekgno, Wednesday 3 December 2008

'A demo in recursion

TextWindow.Show()

'Show the factorials for all numbers up to 27, any higher and it crashes :(

For i = 0 To 27

'Use the push/pop for value passing

Stack.PushValue("fact",i )

factorial()

a = Stack.PopValue("fact")

TextWindow.WriteLine(i+":    "+a)

EndFor

Sub factorial

'Grab the number we wish to find the factorial for from the stack

f = Stack.PopValue("fact")

r = 1

'Since n! = n * (n-1)!

'If n > 1 then we find what (n-1)! is

If (f > 1) Then

Stack.PushValue("fact",f)

Stack.PushValue("fact",f-1)

factorial()

r = Stack.PopValue("fact")

f = Stack.PopValue("fact")

EndIf

'At this point, r will either still be initialised at 1, or will contain (n-1)!

r = f * r

'The factorial for 0 is 1

If (f = 0) Then

r = 1

EndIf

'The factorial for negative numbers is undefined

If (f < 0) Then

r = "Undefined"

EndIf

Stack.PushValue("fact",r)

EndSub

Answer 51

Really nice, Tekgno.  I really like the recursion demonstration with factorials!

Answer 52

Since there's a Stack object, how come SmallBasic doesn't support function parameters? Wouldn't be hard to generate code internally to push all params to stack and then at the function pop them at the reverse order into local variables

---

Microsoft MVP J# 2004-2007, Borland Spirit of Delphi 2001

Answer 53

could also try porting some of the demos from the other SmallBASIC (see screenshots at http://smallbasic.sourceforge.net/?q=node/835)

---

Microsoft MVP J# 2004-2007, Borland Spirit of Delphi 2001

Answer 54

The reason we don't have function parameters is because there isn't a notion of scopes in Small Basic (just like QBasic).  In order for function parameters to work, they should be made applicable only inside of sub body, which contradicts the "all variables are global" principle.

Answer 55

The problem with the lack of scope is that you can't expect schools to use this for teaching programming, except for very young kids (primary school maybe, although many would use visual programming [see Scratch or Boku for example] at that age). You shouldn't use GWBasic/QBasic as example in my opinion, should use QuickBasic/TurboBasic/PowerBasic instead as example in my opinion.

Also, as I've written elsewhere on the forum, it's contradictory/inconsistent that object (library) methods that you provide take params whereas the end-user's own methods (for "libraries" the end-user [educator or child] wants to make in SmallBasic code) don't take params. That way you have two classes of calls, with the user's defined stuff being inferior to the ones you've defined (or that others have defined as SmallBasic extensions in low-level C# etc. code)


For example Logo uses the concept of "local" and "global" with commands like "localmake" (for locals) and "make" (for globals). First-time users will use "make" and later on will get introduced to "localmake" (also it has say local "x command which is remembered and if followed by make "x 10 later on it does a localmake for "x)

---

Microsoft MVP J# 2004-2007, Borland Spirit of Delphi 2001

Answer 56

Still working on the 3D maze thing but wanted to complete something (getting a bit of coder's block) to get my mind off it.

 I call this one Random Bouncing Points.

Enter the number of points, from 2 to 20.

Those points bounce around the screen in random directions and in random increments, drawing a line from point 1 to point 2 to point 3... depending on number of points entered, and then from last point to first point.
The color of lines are random and change to a random color every time any point bounces off a wall.

While points are bouncing, you can press keys to do the following:

End Program  = Escape key

Increase delay (up to 200 ms)
(slow down the time between points replotting) = Up arrow

Decrease delay (to zero)
(speeds up time between points replotting) = Down arrow

'Random Bouncing Points

'created for Microsoft Small Basic

'by David R. Crutchfield on 12/11/2008

correctkey = "False"

While (correctkey = "False")

TextWindow.Show()

TextWindow.WriteLine("Type number of points to bounce (from 2 to 20, or 0 to exit)")

TextWindow.Write("and press the Enter key: ")

numofpoints = TextWindow.ReadNumber()

If (numofpoints>1 And numofpoints<21) Then

correctkey = "True"

Else

If (numofpoints = 0) Then

correctkey = "True"

Program.End()

Else

TextWindow.WriteLine("")

TextWindow.WriteLine("Number can be no less than 2 and no larger than 20,")

TextWindow.WriteLine("or 0 (zero) to exit.")

TextWindow.WriteLine("")

Sound.PlayBellRingAndWait()

EndIf

EndIf

EndWhile

TextWindow.Hide()

'ranomize X, Y starting coordinates , direction, and point movement amount

For pointnum = 1 To numofpoints

Array.SetValue("X",pointnum,Math.GetRandomNumber(801))

Array.SetValue("Y",pointnum,Math.GetRandomNumber(800))

'   randomize X axis start direction

direction = Math.GetRandomNumber(2)

If (direction = 0) Then

Array.SetValue("directionX",pointnum,-1)

Else

Array.SetValue("directionX",pointnum,1)

EndIf

'   randomize Y axis start direction

direction = Math.GetRandomNumber(2)

If (direction = 0) Then

Array.SetValue("directionY",pointnum,-1)

Else

Array.SetValue("directionY",pointnum,1)

EndIf

'   randomize start move amount for X and Y axis

Array.SetValue("moveX",pointnum,Math.GetRandomNumber(50)+1)

Array.SetValue("moveY",pointnum,Math.GetRandomNumber(50)+1)

EndFor

'initialize graphics window

GraphicsWindow.Height = 800

GraphicsWindow.Width = 800

GraphicsWindow.BackgroundColor = "Black"

GraphicsWindow.Title = "Random Bouncing Points"

GraphicsWindow.Show()

GraphicsWindowGraphicsWindow.PenColor = GraphicsWindow.GetRandomColor()

GraphicsWindow.KeyDown = ReadKey

repeat = "True"

While (repeat)

Program.Delay(pause)

For pointnum = 1 To numofpoints

If (pointnum<numofpoints) Then

GraphicsWindow.DrawLine(Array.GetValue("X",pointnum), Array.GetValue("Y",pointnum), Array.GetValue("X",pointnum+1), Array.GetValue("Y",pointnum+1))

Else

GraphicsWindow.DrawLine(Array.GetValue("X",pointnum), Array.GetValue("Y",pointnum), Array.GetValue("X",1), Array.GetValue("Y",1))

EndIf

'   move X axis

newX = Array.GetValue("X",pointnum)+Array.GetValue("moveX",pointnum)*Array.GetValue("directionX",pointnum)

If (newX<0 Or newX>800) Then

If (newX>800) Then

newX = 800 - (newX - 800)

Array.SetValue("directionX",pointnum,-1)

Else

newX = newX * -1

Array.SetValue("directionX",pointnum,1)

EndIf

' randomize X axis move amount after hitting wall.

Array.SetValue("moveX",pointnum,Math.GetRandomNumber(50)+1)

'get random color when point hits wall

GraphicsWindow.GraphicsWindow.PenColor = GraphicsWindow.GetRandomColor()

EndIf

Array.SetValue("X",pointnum,newX)

' move Y axis

newY = Array.GetValue("Y",pointnum)+Array.GetValue("moveY",pointnum)*Array.GetValue("directionY",pointnum)

If (newY<0 Or newY>800) Then

If (newY>800) Then

newY = 800 - (newY - 800)

Array.SetValue("directionY",pointnum,-1)

Else

newYnewY = newY * -1

Array.SetValue("directionY",pointnum,1)

EndIf

' randomize Y axis move amount after hitting wall.

Array.SetValue("moveY",pointnum,Math.GetRandomNumber(50)+1)

'get randome color when point hits wall

GraphicsWindowGraphicsWindow.PenColor = GraphicsWindow.GetRandomColor()

EndIf

Array.SetValue("Y",pointnum,newY)

EndFor

EndWhile

Program.End()

Sub ReadKey

key = GraphicsWindow.LastKey

If (key = "Escape") Then

repeat = "False"

EndIf

If (key = "Up") Then

pausepause = pause + 1

If (pause > 200) Then

pause = 200

EndIf

EndIf

If (key = "Down") Then

pausepause = pause - 1

If (pause < 0) Then

pause = 0

EndIf

EndIf

GraphicsWindow.Title = "Random Bouncing Points   Delay = "+pause+" milliseconds"

EndSub

Lines of code = 103
Remark lines = 14
Blank lines = 23
Total lines = 140

Executable file size = 6 KB

By the way.
I sent the executable file to a friend in the office here.
He has the same office computer that I have, but when he runs it, it immediately crashes and wants to send a report to Microsoft.
If I want to share the programs I create do the recipients have to have something special to run the exe's?

Answer 57

Path_drc,
The code you provided seems to have some typos in it,
 GraphicsWindow GraphicsWindow.PenColor = GraphicsWindow.GetRandomColor()

To send to a friend you must include your .exe file and SmallBasicLibrary.dll, plus any other libraries(.dll) you used to create your program.  They must also have the .Net Framework Runtime installed on their computer

Answer 58

I don't know how that happened.  I copied straight from the editor after a few succesfull runs.

I'll correct it tomorrow.

THNX!

Answer 59

Love it, DRC.  Here's DRC's program with the typos fixed.

'Random Bouncing Points
'created for Microsoft Small Basic
'by David R. Crutchfield on 12/11/2008

correctkey = "False"
While (correctkey = "False")
    TextWindow.Show()
    TextWindow.WriteLine("Type number of points to bounce (from 2 to 20, or 0 to exit)")
    TextWindow.Write("and press the Enter key: ")
    numofpoints = TextWindow.ReadNumber()

    If (numofpoints>1 And numofpoints<21) Then
        correctkey = "True"
    Else
        If (numofpoints = 0) Then
            correctkey = "True"
            Program.End()
        Else
            TextWindow.WriteLine("")
            TextWindow.WriteLine("Number can be no less than 2 and no larger than 20,")
            TextWindow.WriteLine("or 0 (zero) to exit.")
            TextWindow.WriteLine("")
            Sound.PlayBellRingAndWait()
        EndIf

    EndIf
EndWhile

TextWindow.Hide()

'ranomize X, Y starting coordinates , direction, and point movement amount
For pointnum = 1 To numofpoints
    Array.SetValue("X",pointnum,Math.GetRandomNumber(801))
    Array.SetValue("Y",pointnum,Math.GetRandomNumber(800))

    '   randomize X axis start direction
    direction = Math.GetRandomNumber(2)
    If (direction = 0) Then
        Array.SetValue("directionX",pointnum,-1)
    Else
        Array.SetValue("directionX",pointnum,1)
    EndIf

    '   randomize Y axis start direction
    direction = Math.GetRandomNumber(2)
    If (direction = 0) Then
        Array.SetValue("directionY",pointnum,-1)
    Else
        Array.SetValue("directionY",pointnum,1)
    EndIf

    '   randomize start move amount for X and Y axis
    Array.SetValue("moveX",pointnum,Math.GetRandomNumber(50)+1)
    Array.SetValue("moveY",pointnum,Math.GetRandomNumber(50)+1)
EndFor

'initialize graphics window
GraphicsWindow.Height = 800
GraphicsWindow.Width = 800
GraphicsWindow.BackgroundColor = "Black"
GraphicsWindow.Title = "Random Bouncing Points"
GraphicsWindow.Show()
GraphicsWindow.PenColor = GraphicsWindow.GetRandomColor()

GraphicsWindow.KeyDown = ReadKey

repeat = "True"

While (repeat)
    Program.Delay(pause)
    For pointnum = 1 To numofpoints
        If (pointnum800) Then
            If (newY>800) Then
                newY = 800 - (newY - 800)
                Array.SetValue("directionY",pointnum,-1)
            Else
                newYnewY = newY * -1
                Array.SetValue("directionY",pointnum,1)
            EndIf

            ' randomize Y axis move amount after hitting wall.
            Array.SetValue("moveY",pointnum,Math.GetRandomNumber(50)+1)
            'get randome color when point hits wall
            GraphicsWindow.PenColor = GraphicsWindow.GetRandomColor()
        EndIf

        Array.SetValue("Y",pointnum,newY)

    EndFor
EndWhile

Program.End()


Sub ReadKey
    key = GraphicsWindow.LastKey
    If (key = "Escape") Then
        repeat = "False"
    EndIf
    If (key = "Up") Then
        pause = pause + 1
        If (pause > 200) Then
            pause = 200
        EndIf
    EndIf
    If (key = "Down") Then
        pause = pause - 1
        If (pause < 0) Then
            pause = 0
        EndIf
    EndIf
    GraphicsWindow.Title = "Random Bouncing Points   Delay = "+pause+" milliseconds"
EndSub

Answer 60

Thanks Vijaye, I didn't get back to make the corrections myself.
Lots of stuff going on with Christmas so close.

Christmas.... hmmmmm...
How about an unoffical Christmas tree contest?  :D

Maybe I could get my random color lines to bounce around in the shape of a tree?
Nah - too redundant.  lol

Answer 61

Although a Mandelbrot drawing program was already posted, I figured I'd submit mine as well. It makes use of the new GraphicsWindow.GetColorFromRGB method in Small Basic 0.2 (and let me discover a bug in that as well: it seems to have errors in calculating the colour components so that 255 is counted as 0 [probably through a rounding error that results in 256]).

' MANDELBROT.SB - Coded in 2008 by Steven Don - http://www.shdon.com

'

' This small demonstration draws a picture of the Mandelbrot set according to

' the Escape Time Algorithm. While an in-depth discussion of complex and

' imaginary functions is beyond the scope of a sample program (for more

' information, please refer to Wikipedia's article on the Mandelbrot set:

' http://en.wikipedia.org/wiki/Mandelbrot_set

'

' This program demonstrates the use of simple for-loops, arrays and building a

' picture by plotting individual pixels.

'How many times to apply the Mandelbrot polynomial. The higher this number, the more accurate (and slower) the results

max_iteration = 50

'Get the dimensions of the graphics viewport

width = GraphicsWindow.Width

height = GraphicsWindow.Height

'Dividing those dimensions gets the coordinates of the center of the viewport

half_width = width / 2

half_height = height / 2

'Set up a gradient of colours

For i = 0 To max_iteration

'How far into the loop are we?

fraction = i / max_iteration

'Calculate colour components based on that - play around with these to get different colour schemes

red = Math.Min (fraction * 8, 1)

green = Math.Max (0, Math.Min ((fraction * 4) - 0.5, 1))

blue = Math.Min (fraction, 1)

'Combine them into a colour - the components should actually be multiplied by 255 rather than 254, but there is a bug in Small Basic

rgb = GraphicsWindow.GetColorFromRGB (red * 254, green * 254, blue * 254)

'Store it for later reference

Array.SetValue ("colours", i, rgb)

EndFor

'Last colour (for points belonging to the actual Mandelbrot set) is black

Array.SetValue ("colours", max_iteration, "black")

'Open the graphics display

GraphicsWindow.Show ()

'Handle all pixels

For y_pixel = 0 To height

'Get fractional vertical coordinate

y_fractional = (y_pixel / half_height) - 1

For x_pixel = 0 To width

'Get fractional horizontal coordinate

x_fractional = (x_pixel / half_width) - 1.5

'These for the components (real and imaginary parts) of a complex number

real = x_fractional

imaginary = y_fractional

'Repeatedly apply the Mandelbrot polynomial, with a maximum of "max_iteration" steps

iteration = 0

While (real*real+imaginary*imaginary<=4 And iteration<max_iteration)

'Generate a new real component (square of real component is positive, square of imaginary component is negative so subtract it, add in the original real part)

real_new = real*real - imaginary*imaginary + x_fractional

'Generate a new imaginary component and use it

imaginary = 2*real*imaginary + y_fractional

'Use that new real component

real = real_new

'Count as another step

iteration = iteration + 1

EndWhile

'Draw the pixel based on the number of iterations

GraphicsWindow.SetPixel (x_pixel, y_pixel, Array.GetValue ("colours", iteration))

EndFor

EndFor

'By the time we get here, a long time may have passed - play a sound to let the user know it's done

Sound.PlayChime ()

I hope somebody finds it amusing. At the very least, it'll be a pretty picture.

Answer 62

Screenshot of the Mandelbrot program by Steven.  Using max_iteration = 500.

This one took about an hour to complete.

Answer 63

The Mandelbrot program is awesome Steven.

Answer 64

GraphicsWindow.Title = "David's Rose"

DrawRose()

Sub DrawRose

GraphicsWindow.BrushColor = "Black"

GraphicsWindow.FillRectangle(0, 0, GraphicsWindow.Width, GraphicsWindow.Height)

GraphicsWindow.PenWidth = 2

GraphicsWindow.PenColor = "Crimson"

Turtle.Speed = 9

Turtle.Show()

For sideLength = 1 To 250

Turtle.Move(sideLength)

Turtle.Turn(89)

EndFor

GraphicsWindow.PenColor = "DarkRed"

For sideLength = 0 To 249

Turtle.Move(250 - sideLength)

Turtle.Turn(89)

EndFor

Turtle.Hide()

EndSub

Here's a rose that my son drew for his mom.

Answer 65

Very pretty Kevin.  Here's the screenshot of David's Rose.

Answer 66

The rose program crashes my SB.

Answer 67

Neat code Steven, mandelbrot sets are usually the first thing I play with in a new language.  Something you may like to try to speed things up a bit is to precalculate the squares for real and imaginary to save calculating them twice each loop.  Another thing (which wont be much use if you decide to add a zoom feature) is to take advantage of the symmetry about the y-axis.

Answer 68

'Spiral

Radius = 200

RadiusStep = .2

Angle = 0

x1 = 320 + Math.Sin(Angle) * Radius

y1 = 220 + Math.Cos(Angle) * Radius

While Radius > 0

x = 320 + Math.Sin(Angle) * Radius

y = 220 + Math.Cos(Angle) * Radius

Angle = Angle + .1

GraphicsWindow.DrawLine(x,y,x1,y1)

x1 = x

y1 = y

Radius = Radius - RadiusStep

RadiusStep = RadiusStep - .0001

EndWhile

Answer 69

I probably wrote this the first time about 20 years ago.  It's simple enough where I remembered most it from memory.



x1 = Math.GetRandomNumber(640)

y2 = Math.GetRandomNumber(480)

h1 = 5

v1 = 5

x2 = Math.GetRandomNumber(640)

y2 = Math.GetRandomNumber(480)

h2 = 3

v2 = 3

GraphicsWindow.PenWidth = 2

start:

x1 = x1 + h1

y1 = y1 + v1

x2 = x2 + h2

y2 = y2 + v2

If x1 < 0 Or x1 > 640 Then

h1 = -h1

EndIf

If y1 < 0 Or y1 > 480 Then

v1 = -v1

EndIf

If x2 < 0 Or x2 > 640 Then

h2 = -h2

EndIf

If y2 < 0 Or y2 > 480 Then

v2 = -v2

EndIf

GraphicsWindow.PenColor = GraphicsWindow.GetColorFromRGB( Math.GetRandomNumber(255), Math.GetRandomNumber(255), Math.GetRandomNumber(255))

GraphicsWindow.DrawLine( x1, y1, y1, y2 )

Goto start

Answer 70

I wrote a simple Tetris program in Small Basic:

Code posted to the wiki: http://smallbasic.com/smallbasic.com/wiki/Sample%20Tetris.ashx

Answer 71

The Tetris game is awesome Kenny and is the best game I've seen made with SB so far.

Answer 72

Here's a calc.exe (based on my extension).

CurrentText = "0"

ClearBeforeType = "True"

GraphicsWindow.Hide()

GraphicsWindow.Title="Calculator made in Small Basic"

GraphicsWindow.Hide()

GraphicsWindow.Width=350

GraphicsWindow.Height=185

GraphicsWindow.CanResize="False"

GraphicsWindow.BackgroundColor = GraphicsWindow.GetColorFromRGB(240,240,240)

Shapes.LoadTheme("Vista")

GraphicsWindow.BrushColor="#f9f9f9"

GraphicsWindow.PenColor="#B2DFF8"

GraphicsWindow.PenWidth=1

' Fausse textbox

'Bordure

Rect1 = Shapes.AddRectangle(336, 25)

Shapes.Move(Rect1, 8, 10)

' Label

GraphicsWindow.BrushColor="Black"

ResultLabel = Shapes.AddLabel(335, 23, "0")

Shapes.Move(ResultLabel, 11, 11)

' Autre déco

GraphicsWindow.BrushColor="#E6F5FD"

GraphicsWindow.PenColor="#B2DFF8"

Rect1 = Shapes.AddRectangle(247, 145)

Shapes.Move(Rect1, 8, 34)

GraphicsWindow.BrushColor="White"

GraphicsWindow.PenColor="#B2DFF8"

Rect1 = Shapes.AddRectangle(90, 145)

Shapes.Move(Rect1, 8+246, 34)

' Bouttons :

' - Chiffres

For V = 0 To 9

CurrentCol = 2-Math.Remainder((9-V), 3)

CurrentRow = Math.Floor((9-V)/3)

CurrentWidth = 75

If V=0 Then

CurrentWidth = 321-(2*82)

CurrentCol = 0

EndIf

CurrentButton = Shapes.AddButton(CurrentWidth, 30, V)

Array.SetValue("Buttons", v, CurrentButton)

Shapes.Move(CurrentButton, 12+82*CurrentCol,40+35*CurrentRow)

Shapes.RegisterMouseUpEvent(CurrentButton, "AddToText")

EndFor

' - Point

CurrentButton = Shapes.AddButton(75, 30, ".")

Shapes.Move(CurrentButton, 11+82*2,40+35*3)

Shapes.RegisterMouseUpEvent(CurrentButton, "AddToText")

' - Parenthèses

CurrentButton = Shapes.AddButton(38, 30, "(")

Shapes.Move(CurrentButton, 12+82*3,40+35*0)

Shapes.RegisterMouseUpEvent(CurrentButton, "AddToText")

CurrentButton = Shapes.AddButton(38, 30, ")")

Shapes.Move(CurrentButton, 55+82*3,40+35*0)

Shapes.RegisterMouseUpEvent(CurrentButton, "AddToText")

' - Addition

CurrentButton = Shapes.AddButton(38, 30, "+")

Shapes.Move(CurrentButton, 12+82*3,40+35*1)

Shapes.RegisterMouseUpEvent(CurrentButton, "AddToText")

CurrentButton = Shapes.AddButton(38, 30, "-")

Shapes.Move(CurrentButton, 55+82*3,40+35*1)

Shapes.RegisterMouseUpEvent(CurrentButton, "AddToText")

' - Multiplication

CurrentButton = Shapes.AddButton(38, 30, "*")

Shapes.Move(CurrentButton, 12+82*3,40+35*2)

Shapes.RegisterMouseUpEvent(CurrentButton, "AddToText")

CurrentButton = Shapes.AddButton(38, 30, "/")

Shapes.Move(CurrentButton, 55+82*3,40+35*2)

Shapes.RegisterMouseUpEvent(CurrentButton, "AddToText")

' - Résultat

CurrentButton = Shapes.AddButton(38, 30, "=")

Shapes.Move(CurrentButton, 12+82*3,40+35*3)

Shapes.RegisterMouseUpEvent(CurrentButton, "GetResult")

CurrentButton = Shapes.AddButton(38, 30, "<==")

Shapes.Move(CurrentButton, 55+82*3,40+35*3)

Shapes.RegisterMouseUpEvent(CurrentButton, "RemoveToText")

' Show the window

GraphicsWindow.Show()

Sub AddToText

Src = Shapes.LastEventSource

Src = Shapes.GetText(Src)

If ClearBeforeType="True" Then

If Math.Floor(Src)=Src Then

CurrentText=""

EndIf

ClearBeforeType="False"

EndIf

CurrentText = Text.Append(CurrentText, Src)

Shapes.SetText(ResultLabel, CurrentText)

EndSub

Sub RemoveToText

If ClearBeforeType="True" Then

CurrentText=""

ClearBeforeType="False"

Shapes.SetText(ResultLabel, CurrentText)

Else

Len = Text.GetLength(CurrentText)

CurrentText = Text.GetSubText(CurrentText, 0, len-1)

Shapes.SetText(ResultLabel, CurrentText)

EndIf

EndSub

Sub GetResult

ClearBeforeType="True"

'SmallBasic.Eval("CurrentText = (" + CurrentText +")")

CurrentText = SmallBasic.MathEval(CurrentText)

Shapes.SetText(ResultLabel, CurrentText)

EndSub

---

Fremy VB & C#

Answer 73

Very nice, Francois.  Could you also provide a link to your extension from your post (you can edit your post to add that link).  That way people wouldn't have to go searching for it.

Answer 74

The calculator looks great Fremy.

Answer 75

Here's a print screen of a game I'm currently making in Small Basic.

I think the final release will come with a compass for more ease in the reading of the data written in the top-left.

I don't post the code at this time, because there isn't any IA at this time, so the only thing you can do is moving around the second boat and firing on it (but you'll not inflige damage to him). When the IA will be clear (it can take several time because I'm back to school), I'll edit this post to include the code and a fresh preview.

[EDIT: The fault of calculation are due to the fact I was using my fr-fr culture when I took the screenshot, so the calculation is wrong]

---

Fremy VB & C#

Answer 76

Awesome Tetris game Kenny!

Your remarks document the code in detail and the game itself plays great.

I found the random shapes to not be random enough at times.  Like 5 boxes in a row one time and then, as the shapes were reaching the top, I got 7 purple shapes (backwards L or 7 - depends on how you turn it :D) in a row.
...or does that happen a lot in the original Tetris games?

Besides that, and adding sound, this game is just about perfect.

A great add-on would be to keep high score in a text file.
...and even get a little more fancy by asking for a name to go with high score.

Thanks again Kenny.

Answer 77

<Echoy voice>Turtle in spaaaaaaaaaaaaace!</Echoy voice>

This proggie displays a filled circle that's supposed to be a planet, and then has the turtle going around in an orbit around the planet. If you move the mouse left and right over the graphics window, the turtle spins around itself so you can make it face any direction you want. The turtle even has an engine that thrusts him forward, in whatever direction he's facing, as long as you hold the left mouse button down.

Tips for playing:
To make the turtle fly further out from the planet, make him face the direction of flight, and give him a gentle push with the engine (short press on the left mouse button). Conversely, you can bring him back down by turning the tail end towards the direction of flight, and fire the engines again.
Be careful no to go too fast; if the turtle gets beyond what's known as escape velocity, he's going to fly away from the planet forever, never to return to the confines of your graphics window.

Tips for hacking/expanding on this program:
If the turtle is flying too slow or too fast for your taste on your machine, the trick is to change the numbers in VelX = 0.03 and Gravity = 0.001 at the beginning of the program. It takes a bit of tries (or nasty, hard-core math) to find the balance between plunging to the ground like a rock, and flying off the graphics window alltogether.

The whole idea in this program, is that "everything" (at least the position and speed) is split up into two parts; a horizontal ("left/right") part called the X co-ordinate, and a vertical ("up/down") part called the Y co-ordinate -- and then every change and every motion is done to both of these parts (notice how a lot of things in the code below come in pairs of "something-X" and "something-Y").

As you've probably found out after a bit of playing around with the turtle, you can't "crash" onto the planet's surface; you just "plunge into" inside the planet! The program already computes the distance to the center of the planet (it's in the variable called R), so if this R less than the radius of the planet (which is 100 pixels in my code), we've hit the ground. To make it possible to "crash", see if you can make it stop (and perhaps play a noise) when that happens.

Some "flight instruments" would be nice too; e.g. something to tell you how high up above the surface you are. You can work out your height above the now "crash-enabled" planetary surface, as Height = R - 100 (remember the 100 was the planet's radius, measured in pixels), and display it in a corner somewhere.
An by keeping a copy (called, say, OldHeight) of the previous value of Height, just before a new Height is calculated, you can then subtract the OldHeight from the NewHeight to work out how fast you're ascending or descending.
You can also work out your current speed like this: Speed = Math.SquareRoot(VelX * VelX + VelY * VelY)

VelX = 0.03 ' Set the initial velocity in x and y directions in

VelY = 0    ' VelX and VelY

Gravity = 0.001 ' Sets the strength of this planet's gravitational field

GraphicsWindow.BackgroundColor = "Black"  ' Black background

GraphicsWindow.BrushColor = "#2030FF"   ' Color for the planet

GraphicsWindow.Width = 600  ' Set the size of the

GraphicsWindow.Height = 600 ' graphics window

GraphicsWindow.FillEllipse(200,200,200,200) ' Draw the planet

PosX = 0    ' Set the space-faring turtle's initial position as

PosY = 130  ' a pair of x and y coordinates in PosX and PosY

Heading = 0 ' Set the turtle's initial "heading", or direction

Turtle.Show() ' Display the turtle "astronaut"

MainLoop: ' We keep going back to this label, as long as the "flight simulation" runs...

Heading = Mouse.MouseX  ' Use the left/right position of the mouse cursor to select heading

If Mouse.IsLeftButtonDown Then  ' If the left mouse button is pressed down, we fire the engine

VelX = VelX + 0.0001 * Math.Sin(Math.GetRadians(Heading)) ' Add a little forward thrust

VelY = VelY + 0.0001 * Math.Cos(Math.GetRadians(Heading)) ' in the direction the turtle faces

EndIf ' (Ends check on whether the mouse button was pressed in order to fire the engine)

R2 = PosX * PosX + PosY * PosY  ' Get the square of the distance to the planet's center

GForce = Gravity / R2 ' The force of gravity is inversely proportional to the square of the distance

R = Math.SquareRoot(R2) ' Takes the square root to get the distance "itself"

Ratio = GForce / R  ' Ratio between the force of gravity to excert, and the distance

VelX = VelX - Ratio * PosX  ' Now we can calculate the effect that the planet's gravity

VelY = VelY - Ratio * PosY  ' has on the current velocity, in the x and y directions

PosX = PosX + VelX  ' Update the current position by adding the speeds in VelX

PosY = PosY + VelY  ' and VelY, to the position coordinates in PosX and PosY

Turtle.X = 300 + PosX ' Place the turtle by converting the PosX and PosY coor-

Turtle.Y = 300 - PosY ' dinates to screen coordinates, centered on the planet

Turtle.Angle = Heading  ' Have the turtle face in the direction given in Heading

If GraphicsWindow.LastKey <> "Escape" Then  ' So long as the Escape key is *not* pressed

Goto MainLoop ' Go back and repeat the whole thing to keep the simulation going.

EndIf ' (Ends check on whether the Escape key was pressed or not)

---

38911 BASIC bytes free...

Answer 78

Kenny Kasajian's dancing lines reminds me of an old game; "Stix" or "Styx" or something like that: While a bunch of "sticks" danced around the screen just like in your program, the player moved something like the turtle in Small Basic around the screen, to "enclose" more and more screen area. If the dancing sticks hit the line as the player was "drawing" it, he/she lost a life. Cover 75(?) percent of the screen, and the game advances to the next level...

---

38911 BASIC bytes free...

Answer 79

 Whoops, hit wrong button to post my program.
...so I'll just copy and paste it over here.  :-)

Wow, where do I start?

I have been working on this little project for over a month now (don’t remember exactly when I started), and it has been fun and at times frustrating.

What I am presenting today is a 3D maze program, that  will eventually grow into a RPG in the flavor of the old Wizardy wireframe dungeons.  There are a few shortcomings in this maze;

1)      Doesn’t look for walls beyond a single wide hall (to exclude rooms too).  If you change the mapdata to reflect anything more than single wide corridors, nothing will be drawn.

2)      The maze data is setup in a way where every point of the graph is in the data:  the space you are standing in is x = 2, y = 2 the place for a wall to the east is 3, 2  - you never stand in 3, 2 (you can stand in 4, 2) because the odd numbers are wall place holders.  Not only is this slightly confusing to the casual observer, but makes the coding (to me anyway) much more complex to pull wall data.

3)      When you hit a wall, it plays a cool Windows XP Low Battery .wav file (C:\WINDOWS\Media\Windows XP Battery Low.wav) – problem is it only plays once per game.

4)      A few TODO’s left – to include asking for player’s name, and others shown in remarks within my code.

As I was fixing some small problems, I decided that I want to revamp the data.  The next prgrams's data will be a little more complex than what is in this program, but will make coding a little easier.

Something that amazed me was how I coded the entire maze program before running any part of it and only had a few syntax errors, and most of those were due to copying and pasting code that didn’t have enough paren’s in it.  I also surprised myself, when finding something that didn’t work right (like some of the walls didn’t draw correctly), by knowing exactly where to go and, in some cases, know exactly what I needed to change before I got there.

I am ready to take any suggestions and/or criticism, especially better ways to code.  Maybe I overlooked something or maybe there’s a better way, in Small Basic, to

perform the same tasks.

'3D Wireframe Maze 'by David R. Crutchfield (a.k.a. Pathdrc) 'ver: 1.0 'Date:1/19/2009 GraphicsWindow.BackgroundColor="Black"

GraphicsWindow.Height = 600

GraphicsWindow.Width = 800

GraphicsWindow.Show()

GraphicsWindow.KeyDown = ReadKey

'Information frame on left

GraphicsWindow.BrushColor = "Gainsboro"

GraphicsWindow.FillRectangle(0,0,200,600)

'text in Info Frame

GraphicsWindow.BrushColor = "Black"

GraphicsWindow.DrawText(48,1,"Adventurer's Name")

GraphicsWindow.DrawText(48,80,"Map Coordinates:")

GraphicsWindow.DrawText(5,220,"Forward = Up Arrow")

GraphicsWindow.DrawText(5,240,"Back = Down Arrow")

GraphicsWindow.DrawText(5,260,"Turn left = Left Arrow")

GraphicsWindow.DrawText(5,280,"Turn right = Right Arrow")

GraphicsWindow.DrawText(5,320,"To start over = Back Space")

GraphicsWindow.DrawText(5,340,"End program = Esc")

'draw box around Maze-View window on the right

GraphicsWindow.PenColor = "White"

GraphicsWindow.PenWidth = 4

GraphicsWindow.DrawRectangle(200,0,600,600)

'Map data

MapWidth = 9

MapHeight = 11

StartX = 4

StartY = 10

StartFacing = 1

Array.SetValue("mapdata",1,"000111000000")

Array.SetValue("mapdata",2,"000101000000")

Array.SetValue("mapdata",3,"000101111111")

Array.SetValue("mapdata",4,"000101000001")

Array.SetValue("mapdata",5,"000101111101")

Array.SetValue("mapdata",6,"000100000001")

Array.SetValue("mapdata",7,"011101111111")

Array.SetValue("mapdata",8,"010001000000")

Array.SetValue("mapdata",9,"011101000000")

Array.SetValue("mapdata",10,"00010100000")

Array.SetValue("mapdata",11,"00011100000")

'Setup variables

CurrentX = StartX

CurrentY = StartY

Facing = StartFacing '1 = north/up, 2 = east/right, 3 = south/down, 4 = west/left

Main = "True"

'Start main program

While (Main)

DrawWalls()

DisplayCurrentXY() 'show coordinates in information frame.

loop = "True"

keyisupdated = "False"

WaitForKeyDownAndProcess()

EndWhile

Program.End()

Sub WaitForKeyDownAndProcess

While (loop)

If (keyisupdated = "True") Then

If (key = "Up") Then

'test if wall is blocking forward movement

If NoForward = "True" Then

HitWall()

keyisupdated = "False"

Else

loop = "False"

'find facing and update current position based on forward movement.

If Facing = 1 Then

CurrentYCurrentY = CurrentY - 2

ElseIf Facing = 2 Then

CurrentXCurrentX = CurrentX + 2

ElseIf Facing = 3 Then

CurrentYCurrentY = CurrentY + 2

ElseIf Facing = 4 Then

CurrentXCurrentX = CurrentX - 2

EndIf

EndIf

EndIf

'[TODO] code for key = BackSpace (restart position at beginging of maze)

If key = "Left" Then

NoForward = "False"

loop = "False"

FacingFacing = Facing - 1

If Facing < 1 Then

Facing = 4

Endif

EndIf

If key = "Right" Then

NoForward = "False"

loop = "False"

FacingFacing = Facing + 1

If Facing > 4 Then

Facing = 1

EndIf

EndIf

If key = "Down" Then

loop = "False"

'Make sure no wall behind you and then move back one.

If Facing = 1 and Text.GetSubText(Array.GetValue("mapdata",CurrentY+1),CurrentX,1) = 0 Then

CurrentYCurrentY = CurrentY + 2

ElseIf Facing = 2 and Text.GetSubText(Array.GetValue("mapdata",CurrentY),CurrentX-1,1) = 0 Then

CurrentXCurrentX = CurrentX - 2

ElseIf Facing = 3 and Text.GetSubText(Array.GetValue("mapdata",CurrentY-1),CurrentX,1) = 0 Then

CurrentYCurrentY = CurrentY - 2

ElseIf Facing = 4 and Text.GetSubText(Array.GetValue("mapdata",CurrentY),CurrentX+1,1) = 0 Then

CurrentXCurrentX = CurrentX + 2

Else

HitWall()

EndIf

keyisupdated = "False"

EndIf

If key = "Back" Then

loop = "False"

keyisupdated = "False"

RestartMazeQuestion()

EndIf

If (key = "Escape") Then

Main = "False"

loop = "False"

EndIf

EndIf

EndWhile

keyisupdated = "False"

Sound.PlayClickAndWait()

EndSub

Sub DrawWalls

EraseMazeWalls()

'determine walls

For fm = 0 to 4

WallSection1 = 0

WallSection2 = 0

WallSection3 = 0

' facing north/south

If Facing = 1 Or Facing = 3 Then

If Facing = 1 then

wd = 1

Else

wd = -1

EndIf

If Text.GetSubText(Array.GetValue("mapdata",CurrentY-(fm*2*wd)),CurrentX - wd,1) = 1 Then

WallSection1 = 1

ElseIf Text.GetSubText(Array.GetValue("mapdata",CurrentY-(fm*2*wd + wd)),CurrentX - (2*wd),1) = 1 Then

WallSection1 = 2

EndIf

If Text.GetSubText(Array.GetValue("mapdata",CurrentY-(fm*2*wd + wd)),CurrentX,1) = 1 Then

WallSection2 = 1

EndIf

If Text.GetSubText(Array.GetValue("mapdata",CurrentY-(fm*2*wd)),CurrentX + wd,1) = 1 Then

WallSection3 = 1

ElseIf Text.GetSubText(Array.GetValue("mapdata",CurrentY-(fm*2*wd + (1*wd))),CurrentX + (2*wd),1) = 1 Then

WallSection3 = 2

EndIf

EndIf

' facing east/west

If Facing = 2 Or Facing = 4 Then

If Facing = 2 then

wd = 1

Else

wd = -1

EndIf

If Text.GetSubText(Array.GetValue("mapdata",CurrentY-(1*wd)),CurrentX +(fm*2*wd),1) = 1 Then

WallSection1 = 1

ElseIf Text.GetSubText(Array.GetValue("mapdata",CurrentY-(2*wd)),CurrentX + (fm*2*wd+(1*wd)),1) = 1 Then

WallSection1 = 2

EndIf

If Text.GetSubText(Array.GetValue("mapdata",CurrentY),CurrentX +(fm*2*wd+(1*wd)),1) = 1 Then

WallSection2 = 1

EndIf

If Text.GetSubText(Array.GetValue("mapdata",CurrentY+(1*wd)),CurrentX +(fm*2*wd),1) = 1 Then

WallSection3 = 1

ElseIf Text.GetSubText(Array.GetValue("mapdata",CurrentY+(2*wd)),CurrentX +(fm*2*wd+(1*wd)),1) = 1 Then

WallSection3 = 2

EndIf

EndIf

'draw the walls

GraphicsWindow.BrushColor = "White"

If fm = 0 Then

' immediate

If WallSection1 = 1 Then

GraphicsWindow.DrawLine(200,0,240,40)

GraphicsWindow.DrawLine(240,40,240,560)

GraphicsWindow.DrawLine(240,560,200,600)

EndIf

If WallSection1 = 2 Then

GraphicsWindow.DrawLine(200,40,240,40)

GraphicsWindow.DrawLine(240,40,240,560)

GraphicsWindow.DrawLine(240,560,200,560)

EndIf

If WallSection2 = 1 Then

GraphicsWindow.DrawLine(240,40,240,560)

GraphicsWindow.DrawLine(240,560,760,560)

GraphicsWindow.DrawLine(760,560,760,40)

GraphicsWindow.DrawLine(760,40,240,40)

fm = 4 'end wall drawing because you can't see any further

NoForward = "true"

EndIf

If WallSection3 = 1 Then

GraphicsWindow.DrawLine(800,0,760,40)

GraphicsWindow.DrawLine(760,40,760,560)

GraphicsWindow.DrawLine(760,560,800,600)

EndIf

If WallSection3 = 2 Then

GraphicsWindow.DrawLine(800,40,760,40)

GraphicsWindow.DrawLine(760,40,760,560)

GraphicsWindow.DrawLine(760,560,800,560)

EndIf

Else

' greater than immediate

WallSize = 80

WallPositionLeftX = 240

WallPositionRightX = 760

WallPositionTopY = 40

WallPositionBottomY =560

If fm > 1 Then

For count = 1 To fm-1

WallPositionLeftXWallPositionLeftX = WallPositionLeftX + WallSize

WallPositionRightXWallPositionRightX = WallPositionRightX - WallSize

WallPositionTopYWallPositionTopY = WallPositionTopY + WallSize

WallPositionBottomYWallPositionBottomY = WallPositionBottomY - WallSize

WallSizeWallSize = WallSize - Math.Round(WallSize / 4)

EndFor

EndIf

If WallSection1 = 1 Then

GraphicsWindow.DrawLine(WallPositionLeftX,WallPositionTopY,WallPositionLeftX + WallSize,WallPositionTopY + WallSize)

GraphicsWindow.DrawLine(WallPositionLeftX + WallSize,WallPositionTopY + WallSize,WallPositionLeftX + WallSize,WallPositionBottomY - WallSize)

GraphicsWindow.DrawLine(WallpositionLeftX + WallSize,WallPositionBottomY - WallSize,WallPositionLeftX,WallPositionBottomY)

GraphicsWindow.DrawLine(WallPositionLeftX,WallPositionBottomY,WallPositionLeftX,WallPositionTopY)

EndIf

If WallSection1 = 2 Then

GraphicsWindow.DrawLine(WallPositionLeftX,WallPositionTopY + WallSize,WallPositionLeftX + WallSize,WallPositionTopY + WallSize)

GraphicsWindow.DrawLine(WallPositionLeftX + WallSize,WallPositionTopY + WallSize,WallPositionLeftX + WallSize,WallPositionBottomY - WallSize)

GraphicsWindow.DrawLine(WallpositionLeftX + WallSize,WallPositionBottomY - WallSize,WallPositionLeftX,WallPositionBottomY - WallSize)

GraphicsWindow.DrawLine(WallPositionLeftX,WallPositionBottomY - WallSize,WallPositionLeftX,WallPositionTopY + WallSize)

EndIf

If WallSection2 = 1 Then

GraphicsWindow.DrawLine(WallPositionLeftX + WallSize,WallPositionTopY + WallSize,WallPositionRightX - WallSize,WallPositionTopY + WallSize)

GraphicsWindow.DrawLine(WallPositionRightX - WallSize,WallPositionTopY + WallSize,WallPositionRightX - WallSize,WallPositionBottomY - WallSize)

GraphicsWindow.DrawLine(WallPositionRightX - WallSize,WallPositionBottomY - WallSize,WallpositionLeftX + WallSize,WallPositionBottomY - WallSize)

GraphicsWindow.DrawLine(WallpositionLeftX + WallSize,WallPositionBottomY - WallSize,WallPositionLeftX + WallSize,WallPositionTopY + WallSize)

fm = 4 'end wall drawing because you can't see any further

EndIf

If WallSection3 = 1 Then

GraphicsWindow.DrawLine(WallPositionRightX,WallPositionTopY,WallPositionRightX - WallSize,WallPositionTopY + WallSize)

GraphicsWindow.DrawLine(WallPositionRightX - WallSize,WallPositionTopY + WallSize,WallPositionRightX - WallSize,WallPositionBottomY - WallSize)

GraphicsWindow.DrawLine(WallPositionRightX - WallSize,WallPositionBottomY - WallSize,WallPositionRightX,WallPositionBottomY)

GraphicsWindow.DrawLine(WallPositionRightX,WallPositionBottomY,WallPositionRightX,WallPositionTopY)

EndIf

If WallSection3 = 2 Then

GraphicsWindow.DrawLine(WallPositionRightX,WallPositionTopY + WallSize,WallPositionRightX - WallSize,WallPositionTopY + WallSize)

GraphicsWindow.DrawLine(WallPositionRightX - WallSize,WallPositionTopY + WallSize,WallPositionRightX - WallSize,WallPositionBottomY - WallSize)

GraphicsWindow.DrawLine(WallPositionRightX - WallSize,WallPositionBottomY - WallSize,WallPositionRightX,WallPositionBottomY - WallSize)

GraphicsWindow.DrawLine(WallPositionRightX,WallPositionBottomY - WallSize,WallPositionRightX,WallPositionTopY + WallSize)

EndIf

EndIf

EndFor

EndSub

Sub HitWall

'play sound to indicate hit wall

Sound.PlayAndWait("C:\WINDOWS\Media\Windows XP Battery Low.wav")

'[TODO]'s

'maybe put "OUCH" in maze view

'put message in information frame that you ran into a wall

'(IDEA: when secret walls are implemented, make some sound like magic or "swush" like sound when walking through secret wall)

'Note: be sure to clear both messages once a succesful Forward, left, right, or back move has been made.

EndSub

Sub ReadKey

key = GraphicsWindow.LastKey

keyisupdated = "True"

EndSub

Sub EraseMazeWalls

'erase walls from maze-view window

GraphicsWindow.BrushColor = "Black"

GraphicsWindow.PenWidth = 2

GraphicsWindow.FillRectangle(202,2,596,596)

'draw box around Maze-View window on the right

GraphicsWindow.PenColor = "White"

GraphicsWindow.PenWidth = 4

GraphicsWindow.DrawRectangle(200,0,600,600)

EndSub

Sub DisplayCurrentXY

'erase old coordinates

GraphicsWindow.BrushColor = "Gainsboro"

GraphicsWindow.FillRectangle(48,95,110,45)

'display new coordinates

GraphicsWindow.BrushColor = "Black"

CoordinatesText = "X = " + CurrentX + " Y = " + CurrentY

DirectionText = "Facing: "

If Facing = 1 Then

DirectionTextDirectionText = DirectionText + "North"

ElseIf Facing = 2 Then

DirectionTextDirectionText = DirectionText + "East"

ElseIf Facing = 3 Then

DirectionTextDirectionText = DirectionText + "South"

Else

DirectionTextDirectionText = DirectionText + "West"

EndIf

GraphicsWindow.DrawText(48,95,CoordinatesText)

GraphicsWindow.DrawText(48,110,DirectionText)

EndSub

Sub RestartMazeQuestion

RestartMazeQuestionAnswered = "False"

GraphicsWindow.BrushColor = "Black"

GraphicsWindow.DrawText(5,400,"You pressed the Backspace key.")

GraphicsWindow.DrawText(5,415,"Do you really wish to restart")

GraphicsWindow.DrawText(5,430,"the maze?")

While (RestartMazeQuestionAnswered = "False")

If text.ConvertToLowerCase(key) = "y" Then

CurrentX = StartX

CurrentY = StartY

Facing = StartFacing

RestartMazeQuestionAnswered = "True"

ElseIf text.ConvertToLowerCase(key) = "n" Then

RestartMazeQuestionAnswered = "True"

EndIf

EndWhile

'erase Restart Maze message

GraphicsWindow.BrushColor = "Gainsboro"

GraphicsWindow.FillRectangle(5,400,195,595)

EndSub

Answer 80

You're welcome on the Tetris game.

Funny about the randomness.   The code is just using the built-in random number function.   But we can probably make it work a little more like what you expect.  Perhaps we can ensure that the next shape is different than the current shape.

high score is a good idea.

sound won't really do the right thing.   currently, the sound system is only to play wave files, and it does it in the background.   There's indeterminate amount of delay between the code that invokes a sound and when you actually hear the sound.

As I was playing the game myself, and my son came and asked me to help him with his homework, I realized another feature I left out -- the Pause button.  :)

So when I have time, I may go and and add those features there.   Or perhaps, someone else can. :)

Answer 81

The game was QIX

Answer 82

Hi B0ff1n,

I too have been modifying the paddle game to create a simple version of Breakout (will be posting soon) you may want to combine your improvements with my code.

Anyway, I noticed when running your code, that the ball sinks halfway down into the paddle. Looking at the values used a correction should be made when testing for the ball hitting the paddle. The co-ordinates of the ball are those of the top-left corner of the imaginary enclosing square. This means that you have to allow for the diameter of the ball and not the radius as you would if you were taking the centre of the ball as your reference.

If you change your test for collision to "If (y >= gh-8)" then the ball will change direction when it touches the paddle. It actually looks better though with "If (y >= gh-6)" as this gives a more positive contact.



Answer 83

'BrickWall

'A development of the paddle game sample.

'Revove all the bricks to complete the game.

' Game over if you miss the ball.

'You are penalised -1 each time no bricks are hit.

'The movement of the ball is influenced by where it hits the paddle.

'Do not let the bricks reach the bottom of the screen.

GameStart:

paddle = GraphicsWindow.AddRectangle(120, 12)

ball = GraphicsWindow.AddEllipse(16, 16)

bricksLeft = 48

brickStartY = 35

hitCount = 0

GraphicsWindow.FontSize = 14

GraphicsWindow.MouseMove = OnMouseMove

For idx = 0 To 15

Array.SetValue("GreenBricks", idx, 1)

Array.SetValue("YellowBricks", idx, 1)

Array.SetValue("RedBricks", idx, 1)

Endfor

DrawBricks()

score = 0

PrintScore()

gw = GraphicsWindow.Width

gh = GraphicsWindow.Height

y = gh - 28

GraphicsWindow.MoveShape(ball, x, y)

deltaX = 1

deltaY = -2

Sound.PlayBellRingAndWait()

RunLoop:

xx = x + deltaX

yy = y + deltaY

gw = GraphicsWindow.Width

gh = GraphicsWindow.Height

If (x >= gw - 16 Or x <= 0) Then

deltaX = -deltaX

EndIf

If (y <= 0) Then

deltaY = -deltaY

EndIf

padX = GraphicsWindow.GetLeftOfShape(paddle)

If ((y >= gh - 28 + 2) And x >= padX And x <= padX + 120) Then

y = gh - 28 + 2

'Sound.PlayClick()

hitCounthitCount = hitCount + 1

If Math.Remainder(hitCount, 3) = 0 Then 'Move bricks downwards

For idx = 0 To 15

RemoveGreenBrick()

RemoveYellowBrick()

RemoveRedBrick()

Endfor

brickStartYbrickStartY = brickStartY + 20

DrawBricks()

EndIf

TestRed:

For idx = 0 To 15

If Array.GetValue("RedBricks", idx) = 1 Then

If brickStartY > gh - 160 Then

Goto EndGame

EndIf

EndIf

EndFor

TestYellow:

For idx = 0 To 15

If Array.GetValue("YellowBricks", idx) = 1 Then

If brickStartY > gh - 100 Then

Goto EndGame

EndIf

EndIf

EndFor

TestGreen:

For idx = 0 To 15

If Array.GetValue("GreenBricks", idx) = 1 Then

If brickStartY > gh - 40 Then

Goto EndGame

EndIf

EndIf

EndFor

EndTest:

deltaXdeltaX = deltaX - 2 + (x - padX) / 30  ' Add some skill

If score = oldScore Then  'No bricks hit

scorescore = score - 1

EndIf

oldScore = score

PrintScore()

deltaY = -deltaY  'Change the ball direction

EndIf

GraphicsWindow.MoveShape(ball, x, y)

Program.Delay(5)

' Green Bricks

If y > brickStartY - 16 And y < brickStartY + 20 Then  ' y position of brick - diameter of ball

idx = (x+8) / 40  ' Radius of ball / length of brick

idx = Math.Floor(idx) ' take integer part

If Array.GetValue("GreenBricks", idx) = 1 Then

Array.SetValue("GreenBricks", idx, 0)

RemoveGreenBrick()

Sound.PlayChime()

bricksLeftbricksLeft = bricksLeft - 1

deltaY = -deltaY  'Change ball direction

scorescore = score + 15

PrintScore()

CheckEnd()

EndIf

EndIf

' Yellow Bricks

If y > brickStartY + 44 And y < brickStartY + 80 Then  ' y position of brick - diameter of ball = 19

idx = (x+8) / 40  ' Radius of ball / length of brick

idx = Math.Floor(idx) ' take integer part

If Array.GetValue("YellowBricks", idx) = 1 Then

Array.SetValue("YellowBricks", idx, 0)

RemoveYellowBrick()

Sound.PlayChime()

bricksLeftbricksLeft = bricksLeft - 1

deltaY = -deltaY  'Change ball direction

scorescore = score + 10

PrintScore()

CheckEnd()

EndIf

EndIf

' Red Bricks

If y > brickStartY + 104 And y < brickStartY + 140 Then  ' y position of brick - diameter of ball = 19

idx = (x+8) / 40  ' Radius of ball / length of brick

idx = Math.Floor(idx) ' take integer part

If Array.GetValue("RedBricks", idx) = 1 Then

Array.SetValue("RedBricks", idx, 0)

RemoveRedBrick()

Sound.PlayChime()

bricksLeftbricksLeft = bricksLeft - 1

deltaY = -deltaY  'Change ball direction

scorescore = score + 5

PrintScore()

CheckEnd()

EndIf

EndIf

If (y < gh) Then  'Ball not reached bottom of window

Goto RunLoop

EndIf

EndGame:

GraphicsWindow.ShowMessage("Your score is: " + score, "BrickWall")

Program.End()

Sub OnMouseMove

paddleX = GraphicsWindow.MouseX

GraphicsWindow.MoveShape(paddle, paddleX - 60, GraphicsWindow.Height - 12)

EndSub

Sub PrintScore

' Clear the score first and then draw the real score text

GraphicsWindow.BrushColor = "White"

GraphicsWindow.FillRectangle(10, 10, 200, 20)

GraphicsWindow.BrushColor = "Black"

GraphicsWindow.DrawText(10, 10, "Score: " + score)

EndSub

Sub DrawBricks

For idx = 0 To 15 ' Draw bricks

'Program.Delay(100)

If Array.GetValue("GreenBricks", idx) = 1 Then

GraphicsWindow.PenColor = "Black"

GraphicsWindow.BrushColor = "Green"

Else

GraphicsWindow.PenColor = "White"

GraphicsWindow.BrushColor = "White"

EndIf

GraphicsWindow.FillRectangle(idx * 40, brickStartY, 40, 20)

GraphicsWindow.DrawRectangle(idx * 40, brickStartY, 40, 20)

GraphicsWindow.BrushColor = "Yellow"

If Array.GetValue("YellowBricks", idx) = 1 Then

GraphicsWindow.PenColor = "Black"

GraphicsWindow.BrushColor = "Yellow"

Else

GraphicsWindow.PenColor = "White"

GraphicsWindow.BrushColor = "White"

EndIf

GraphicsWindow.FillRectangle(idx * 40, brickStartY + 60, 40, 20)

GraphicsWindow.DrawRectangle(idx * 40, brickStartY + 60, 40, 20)

GraphicsWindow.BrushColor = "Red"

If Array.GetValue("RedBricks", idx) = 1 Then

GraphicsWindow.PenColor = "Black"

GraphicsWindow.BrushColor = "Red"

Else

GraphicsWindow.PenColor = "White"

GraphicsWindow.BrushColor = "White"

EndIf

GraphicsWindow.FillRectangle(idx * 40, brickStartY + 120, 40, 20)

GraphicsWindow.DrawRectangle(idx * 40, brickStartY + 120, 40, 20)

endfor

EndSub

Sub RemoveGreenBrick

GraphicsWindow.PenColor = "White"

GraphicsWindow.BrushColor = "White"

GraphicsWindow.FillRectangle(idx * 40, brickStartY, 40, 20)

GraphicsWindow.DrawRectangle(idx * 40, brickStartY, 40, 20)

EndSub

Sub RemoveYellowBrick

GraphicsWindow.PenColor = "White"

GraphicsWindow.BrushColor = "White"

GraphicsWindow.FillRectangle(idx * 40, brickStartY + 60, 40, 20)

GraphicsWindow.DrawRectangle(idx * 40, brickStartY + 60, 40, 20)

EndSub

Sub RemoveRedBrick

GraphicsWindow.PenColor = "White"

GraphicsWindow.BrushColor = "White"

GraphicsWindow.FillRectangle(idx * 40, brickStartY + 120, 40, 20)

GraphicsWindow.DrawRectangle(idx * 40, brickStartY + 120, 40, 20)

EndSub

Sub CheckEnd

If bricksLeft = 0 Then

GraphicsWindow.ShowMessage("Well Done. Wall destroyed. Your score is: " + score, "BrickWall")

'Goto GameStart

Program.End()

'Goto EndGame

EndIf

EndSub

 I developed this program from the paddle example. There is plenty of scope for improvement. For example, the click sound has been commented out. If left in a burst of noise is generated when the bricks move downwards. This needs fixing. There is plenty of code duplication for the different colours of bricks which could be streamlined.
There is no provision for a high score table (this could make use of a file to remember high scores between sessions).
The ball sometimes gets stuck going up and down on the left edge of the window.
The noise made when a brick is hit gets a bit annoying but it needs something. The click sound is better but then it seems wrong to use it for the paddle as well.
When a brick is removed, the brick to its left loses the black line on its right-hand edge.
The bricks are moved down the screen as the game progresses. The time taken to erase them and redraw them in the new position is visible as a slight pause. I'm sure this could be re-written to speed this up.
I urge beginners to have a play with this and then see what they can do to alter/improve on it. That is a useful learning exercise.
Unfortunately, the forum code submission insists on converting x to xx and y to yy after the RunLoop: label. Please edit these back before running.

Answer 84

SmallBasic is brilliant. I will save the details for another forum topic, but I will say now that it solves all of the problems I have been having keeping my Intro to Programming students interested in the subject. Bravo!



With that said, I offer up this little chestnut. It’s the example I use for one of our first projects. Shape iteration is based on multiples of shape sides. This ensures that the "facets" of the resulting shape line up. Side count is limited to ten. After that the shapes start looking like circles. And I could decide between different colors for each shape or holding the color for the entire design; so I didn’t.



Keep up the good work guys.

'Small Basic "SpiralGraph"

'Author: Matthew L. Parets

top:

sides = Math.GetRandomNumber(7) + 3

intrMult = Math.GetRandomNumber(5)

sidLen = 720 / sides

colorDepth = Math.GetRandomNumber(2)

Turtle.Speed = 10

if colorDepth = 1 then

GraphicsWindowGraphicsWindow.PenColor = GraphicsWindow.GetRandomColor()

EndIf

For j=1 To sides * intrMult

if colorDepth = 2 then

GraphicsWindowGraphicsWindow.PenColor = GraphicsWindow.GetRandomColor()

EndIf

For i=1 To sides

Turtle.Move(sidLen)

Turtle.Turn(360/sides)

EndFor

Turtle.Turn(360/(sides*intrMult))

EndFor

Program.Delay(4000)

GraphicsWindow.Clear()

Goto top

Answer 85

Monty Hall Paradox in Small Basic (more on the paradox at Wikipedia).

losses = 0

wins = 0

For n = 0 To 10000

win = Math.GetRandomNumber(3)

For i = 1 To 3

If win = i Then

TextWindow.Write("1" + "    ")

Else

TextWindow.Write("0" + "    ")

EndIf

EndFor

shot = Math.GetRandomNumber(3)

TextWindow.Write("shot = " + shot + "    ")

If win = shot Then

losseslosses = losses + 1

TextWindow.WriteLine("Loss")

Else

winswins = wins + 1

TextWindow.WriteLine("Win")

EndIf

EndFor

TextWindow.WriteLine("Losses = " + losses)

TextWindow.WriteLine("Wins = " + wins)

Answer 86

Today I offer up my latest opus. While being a hoot to write, this little app does show how environments like SmallBasic tend to encourage spaghetti code. But like it said, it was fun to write.

This program does show off a problem with the turtle graphics system. The longer the program is up, the slower it runs. After about 20 mins the pauses between movements is so long that the turtle appears to stutter.

'Snaking:random curving paths for our turtle friend

'author: Matthew L. Parets

'Initalization

'************************************************************************************

Turtle.Speed = 10

red = Math.GetRandomNumber(256) - 1

blue = Math.GetRandomNumber(256) - 1

green = Math.GetRandomNumber(256) - 1

GraphicsWindow.PenColor = GraphicsWindow.GetColorFromRGB(red,green,blue)

turnIntr = Math.GetRandomNumber(45) + 5

turnCnt = 0

direction = ((Math.GetRandomNumber(90)/10) - 5)

Turtle.Turn(Math.GetRandomNumber(360) - 1)

'Main Loop

top: '*******************************************************************************

red = red + (Math.GetRandomNumber(3) - 2)

blue = blue + (Math.GetRandomNumber(3) - 2)

green = green + (Math.GetRandomNumber(3) - 2)

GraphicsWindow.PenColor = GraphicsWindow.GetColorFromRGB(red,green,blue)

Turtle.Move(2)

turnCnt = turnCnt + 1

If turnCnt >= turnIntr Then

direction = ((Math.GetRandomNumber(90)/10) - 5)

if direction = 0 then

maxArc = 100

else

maxArc = 135 / math.Abs(direction)

EndIf

turnIntr = Math.GetRandomNumber(maxArc)

turnCnt = 0

EndIf

Turtle.Turn(direction)

'Range Checking

'*****************************************************************************************

If Turtle.X > GraphicsWindow.Width Then

Turtle.X = GraphicsWindow.Width

If Turtle.Angle > 90 Then

Turtle.Angle = 180

Else

Turtle.Angle = 0

EndIf

direction = 0

turnCnt = turnIntr

EndIf

If Turtle.X < 0 Then

Turtle.X = 0

If Turtle.Angle > 270 Then

Turtle.Angle = 0

Else

Turtle.Angle = 180

EndIf

direction = 0

turnCnt = turnIntr

EndIf

If Turtle.Y > GraphicsWindow.Height Then

Turtle.Y = GraphicsWindow.Height

If Turtle.Angle > 180 Then

Turtle.Angle = 270

Else

Turtle.Angle = 90

EndIf

direction = 0

turnCnt = turnIntr

EndIf

If Turtle.Y < 0 Then

Turtle.Y = 0

If Turtle.Angle > 0 And Turtle.Angle < 90 then

Turtle.Angle = 90

Else

Turtle.Angle = 270

EndIf

direction = 0

turnCnt = turnIntr

EndIf

Goto top

Answer 87

I have updated my BrickWall example to cover the breaking changes in v0.3. If you want it it is here
http://smallbasic.com/program/?QRQ360.

Answer 88

For my next offering, I give you this recreation of an early PC app. The default text is a minor nod to my wife on Valentines weekend. While creating it, I stumbled across a little inconstancy in the graphics rendering system. The anti-aliasing for the text and the shapes leaves artifacts behind when you try to clear the text or shapes by redrawing the shape in the background color.



The code can be directly imported with the import ID: HZN400





'Blimp - A remake of an early PC basic app.

'author: Matthew L. Parets

'Initial Default Values

'************************************************************************************

offset = 75

textoffset = 175

blmWid = 500

blmHei = 250

steps = 8

gap = 10

centerX = GraphicsWindow.Width / 2

centerY = GraphicsWindow.Height / 2

bgColor = "lightblue"

msg = "Sara and Matt...Forever!...XOXOXOXOXOXOXOXOXOXOXOXOXOXO"

'Draw the blimp

'************************************************************************************

GraphicsWindow.BackgroundColor = bgColor

GraphicsWindow.BrushColor = "blue"

GraphicsWindow.PenColor = "black"

ewid = blmWid

ehei = blmHei

For i = 1 To steps

GraphicsWindow.FillEllipse(centerX - (ewid/2),centerY - (ehei/2) - offset,ewid,ehei)

GraphicsWindow.DrawEllipse(centerX - (ewid/2),centerY - (ehei/2) - offset,ewid,ehei)

hg = ehei

ehei = ehei - gap

gap = gap + (gap * 0.35)

If Math.Remainder(i,2) = 0 Then

GraphicsWindow.BrushColor = "blue"

GraphicsWindow.PenColor = "black"

Else

GraphicsWindow.BrushColor = "yellow"

GraphicsWindow.PenColor = "black"

EndIf

EndFor

'Draw the gandola

'************************************************************************************

GraphicsWindow.BrushColor = "brown"

GraphicsWindow.FillRectangle(centerX - 75,centerY + (blmHei/2) - offset - 5,150,20)

GraphicsWindow.DrawRectangle(centerX - 75,centerY + (blmHei/2) - offset - 5,150,20)

GraphicsWindow.DrawLine(centerX + 75, centerY + (blmHei/2) - offset + 5,centerX + 85, centerY + (blmHei/2) - offset + 5)

GraphicsWindow.BrushColor = "lightblue"

GraphicsWindow.FillRectangle(centerX - 73,centerY + (blmHei/2) - offset - 0,15,10)

GraphicsWindow.DrawRectangle(centerX - 73,centerY + (blmHei/2) - offset - 0,15,10)

GraphicsWindow.FillRectangle(centerX - 47,centerY + (blmHei/2) - offset - 0,30,10)

GraphicsWindow.DrawRectangle(centerX - 47,centerY + (blmHei/2) - offset - 0,30,10)

GraphicsWindow.FillRectangle(centerX - 4,centerY + (blmHei/2) - offset - 0,30,10)

GraphicsWindow.DrawRectangle(centerX - 4,centerY + (blmHei/2) - offset - 0,30,10)

GraphicsWindow.FillRectangle(centerX + 38,centerY + (blmHei/2) - offset - 0,30,10)

GraphicsWindow.DrawRectangle(centerX + 38,centerY + (blmHei/2) - offset - 0,30,10)

'Final Setup

'************************************************************************************

GraphicsWindow.FontName = "Courier New"

GraphicsWindow.FontSize = 36

sep = ".............."

disp = sep + msg + sep

i = 1

'Main control loop

While "true"

i = i + 1

If i >= Text.GetLength(disp) - Text.GetLength(sep) Then

i = 1

EndIf

prt = Text.GetSubText(disp,i,text.GetLength(sep))

textcolor = "black"

DispText()

Program.Delay(100)

textcolor = "yellow"

DispText()

Spin()

EndWhile

'Displaying marquee text on blimp

'************************************************************************************

Sub DispText

GraphicsWindow.BrushColor = textcolor

letpos = 24

For j=0 To 6

chr = Text.GetSubText(prt,j,1)

fntSiz = 21 + (j * 3)

GraphicsWindow.FontSize = fntSiz

GraphicsWindow.DrawText(centerX - textoffset+(letpos),centerY - offset - ((24 + (j * 3))/2),chr)

letpos = letpos + (fntsiz * 0.75)

EndFor

For j=7 To 1 Step -1

chr = Text.GetSubText(prt,(Text.GetLength(prt)-j),1)

fntSiz = 21 + ((j - 1) * 3)

GraphicsWindow.FontSize = fntsiz

GraphicsWindow.DrawText(centerX - textoffset+(letpos),centerY - offset - ((24 + ((j - 1) * 3))/2),chr)

letpos = letpos + (fntsiz * 0.75)

EndFor

EndSub

'Move the propeller

'************************************************************************************

Sub Spin

GraphicsWindow.PenWidth = 0.5

If spinSwitch = 0 Then

spinSwitch = 1

GraphicsWindow.BrushColor = bgColor

GraphicsWindow.PenColor = bgColor

'(centerX + 85), (centerY + (blmHei/2) - offset + 5)

GraphicsWindow.FillTriangle((centerX + 85),(centerY + (blmHei/2) - offset + 5),(centerX + 85)-4,(centerY + (blmHei/2) - offset + 5)-9,(centerX + 85)+2,(centerY + (blmHei/2) - offset + 5)-9)

GraphicsWindow.DrawTriangle((centerX + 85),(centerY + (blmHei/2) - offset + 5),(centerX + 85)-4,(centerY + (blmHei/2) - offset + 5)-9,(centerX + 85)+2,(centerY + (blmHei/2) - offset + 5)-9)

GraphicsWindow.FillTriangle((centerX + 85),(centerY + (blmHei/2) - offset + 5),(centerX + 85)-2,(centerY + (blmHei/2) - offset + 5)+9,(centerX + 85)+4,(centerY + (blmHei/2) - offset + 5)+9)

GraphicsWindow.DrawTriangle((centerX + 85),(centerY + (blmHei/2) - offset + 5),(centerX + 85)-2,(centerY + (blmHei/2) - offset + 5)+9,(centerX + 85)+4,(centerY + (blmHei/2) - offset + 5)+9)

GraphicsWindow.BrushColor = "darkgray"

GraphicsWindow.PenColor = "black"

GraphicsWindow.FillTriangle((centerX + 85),(centerY + (blmHei/2) - offset + 5),(centerX + 85)-2,(centerY + (blmHei/2) - offset + 5)-9,(centerX + 85)+4,(centerY + (blmHei/2) - offset + 5)-9)

GraphicsWindow.DrawTriangle((centerX + 85),(centerY + (blmHei/2) - offset + 5),(centerX + 85)-2,(centerY + (blmHei/2) - offset + 5)-9,(centerX + 85)+4,(centerY + (blmHei/2) - offset + 5)-9)

GraphicsWindow.FillTriangle((centerX + 85),(centerY + (blmHei/2) - offset + 5),(centerX + 85)-4,(centerY + (blmHei/2) - offset + 5)+9,(centerX + 85)+2,(centerY + (blmHei/2) - offset + 5)+9)

GraphicsWindow.DrawTriangle((centerX + 85),(centerY + (blmHei/2) - offset + 5),(centerX + 85)-4,(centerY + (blmHei/2) - offset + 5)+9,(centerX + 85)+2,(centerY + (blmHei/2) - offset + 5)+9)

Else

spinSwitch = 0

GraphicsWindow.BrushColor = bgColor

GraphicsWindow.PenColor = bgColor

GraphicsWindow.FillTriangle((centerX + 85),(centerY + (blmHei/2) - offset + 5),(centerX + 85)-2,(centerY + (blmHei/2) - offset + 5)-9,(centerX + 85)+4,(centerY + (blmHei/2) - offset + 5)-9)

GraphicsWindow.DrawTriangle((centerX + 85),(centerY + (blmHei/2) - offset + 5),(centerX + 85)-2,(centerY + (blmHei/2) - offset + 5)-9,(centerX + 85)+4,(centerY + (blmHei/2) - offset + 5)-9)

GraphicsWindow.FillTriangle((centerX + 85),(centerY + (blmHei/2) - offset + 5),(centerX + 85)-4,(centerY + (blmHei/2) - offset + 5)+9,(centerX + 85)+2,(centerY + (blmHei/2) - offset + 5)+9)

GraphicsWindow.DrawTriangle((centerX + 85),(centerY + (blmHei/2) - offset + 5),(centerX + 85)-4,(centerY + (blmHei/2) - offset + 5)+9,(centerX + 85)+2,(centerY + (blmHei/2) - offset + 5)+9)

GraphicsWindow.BrushColor = "darkgray"

GraphicsWindow.PenColor = "black"

GraphicsWindow.FillTriangle((centerX + 85),(centerY + (blmHei/2) - offset + 5),(centerX + 85)-4,(centerY + (blmHei/2) - offset + 5)-9,(centerX + 85)+2,(centerY + (blmHei/2) - offset + 5)-9)

GraphicsWindow.DrawTriangle((centerX + 85),(centerY + (blmHei/2) - offset + 5),(centerX + 85)-4,(centerY + (blmHei/2) - offset + 5)-9,(centerX + 85)+2,(centerY + (blmHei/2) - offset + 5)-9)

GraphicsWindow.FillTriangle((centerX + 85),(centerY + (blmHei/2) - offset + 5),(centerX + 85)-2,(centerY + (blmHei/2) - offset + 5)+9,(centerX + 85)+4,(centerY + (blmHei/2) - offset + 5)+9)

GraphicsWindow.DrawTriangle((centerX + 85),(centerY + (blmHei/2) - offset + 5),(centerX + 85)-2,(centerY + (blmHei/2) - offset + 5)+9,(centerX + 85)+4,(centerY + (blmHei/2) - offset + 5)+9)

EndIf

EndSub





Next weeks submission will be my first use of the animation system for some drifting landmarks.



Just out of curiosity, I did a net search and found the original source at http://cd.textfiles.com/hof91/GRAPHIC3/. There is something magical about the internet.

Answer 89

I made a calculator in small basic

The import code is DJD934

TextWindow.Title = "Calculator" If (Clock.Hour < 12) Then   TextWindow.Write("Good morning, would you like to do a sum? (y/n) ")   answ = TextWindow.Read() EndIf If (Clock.Hour > 12) Then   TextWindow.Write("Good afternoon, would you like to do a sum? (y/n) ")   answ = TextWindow.Read() EndIf If (Text.StartsWith(Text.ConvertToLowerCase(answ),"y")) Then start: TextWindow.Write("Enter the first number: ") num1 = TextWindow.ReadNumber() TextWindow.Write("Enter the second number: ") num2 = TextWindow.ReadNumber() TextWindow.WriteLine("1 = Addition") TextWindow.WriteLine("2 = Subtraction") TextWindow.WriteLine("3 = Division") TextWindow.WriteLine("4 = Multiplication") TextWindow.Write("What calculation would you like to do: ") calc = TextWindow.ReadNumber() If (calc = 1) Then   num3 = num1 + num2   TextWindow.WriteLine(num1+ "+" +num2+ "=" +num3) EndIf If (calc = 2) Then   num3 = num1 - num2   TextWindow.WriteLine(num1+ "-" +num2+ "=" +num3) EndIf If (calc = 3) Then   num3 = num1 / num2   TextWindow.WriteLine(num1+ "/" +num2+ "=" +num3) EndIf If (calc = 4) Then   num3 = num1 * num2   TextWindow.WriteLine(num1+ "*" +num2+ "=" +num3) EndIf TextWindow.Write("Would you like to do another sum? (y/n) ") e = TextWindow.Read() If (Text.StartsWith(Text.ConvertToLowerCase(e),"y")) Then Goto start EndIf EndIf TextWindow.WriteLine("Goodbye")

Answer 90

I have made a dictionary app that can save the definition to a text file name with the word that has been looked up. The import code is: CJJ955 and the web address is http://smallbasic.com/program/?CJJ955 you'll have to uncomment the line it has automatically commented for the save function.

Answer 91

Here's a Hex Dump program so you can see how all of those bytes in your programs look!

Import code is:  RBV160

'HexDump

'HexDump
Revision 1
'Added scroll capability because a larger file would exceed the buffer
'capacity in the textwindow

'Get file path and read data to string
TextWindow.Write("Enter full path of file to dump: ")
Filepath=textwindow.Read()
Data=File.ReadContents(Filepath)
TotalFileLength=text.GetLength(Data)
TextWindow.WriteLine("File length is "+TotalFileLength+" characters")

'Make Data copy without line feeds, carriage returns and bells for text side printing
For Position=0 to TotalFileLength-1
  if Text.GetSubText(Data,Position,1)=Text.GetCharacter(10) or text.getsubtext(Data,Position,1)=text.getcharacter(13)  or text.getsubtext(Data,Position,1)=text.getcharacter(7)then
        DataCopy=Text.Append(DataCopy,Text.GetCharacter(46))  'Replaces with "."
    else
        DataCopy=Text.Append(DataCopy,Text.GetSubText(Data,Position,1))
    endif
endfor

For FilePosition=0 to TotalFileLength-1 Step 16
   If (TotalFileLength-1)-FilePosition > 15 then
      LineLength=15  'Actually 16 because 0 is a position
  Else
     LineLength=TotalFileLength-FilePosition-1
  endif
      TextWindow.WriteLine("")  'Every other line on the screen is blank
      Separator=0
  For z = FilePosition To FilePosition+LineLength
     Separator=Separator+1
     If Separator=9 Then
     TextWindow.Write("- ")
     endif
  charactercode=text.GetCharacterCode(Text.GetSubText(Data,z,1))
  'Gets rid of FFFD character code
    If charactercode = 65533 then
       charactercode=0
    endif
  'Start breaking characters into hex
  UpperHalf=math.Floor(Charactercode/16)

  UpperHalfCopy=UpperHalf
  'Does upper half byte
  ConvertHexHigher()

  'Does lower half byte
  UpperDecimal=UpperHalfCopy*16
  LowerHalf=charactercode-UpperDecimal
  ConvertHexLower()

  'Write full byte + space
  TextWindow.Write(text.Append(UpperHalf ,LowerHalf+" "))
endfor

'Separates the Hex side from the Decimal
spaces="    "
  If Separator < 9 then
  spaces=spaces + "  "  'Adds 2 spaces for missing separator
  endif

For padding =0 to 16-LineLength
  spaces=spaces+"   "
endfor
TextWindow.Writeline(spaces+text.GetSubText(DataCopy,FilePosition,LineLength+1))
Buffercount=Buffercount+1
If Buffercount=150 Then
  TextWindow.WriteLine("Review Buffer.  Hit Enter to Continue")
  TextWindow.Read()
  Buffercount=0
endif
endfor
TextWindow.WriteLine("")
TextWindow.writeline("Text Window will close by pressing Enter")
TextWindow.Read()
Program.End()

Sub ConvertHexHigher  'Converts upper half byte to hex format
If UpperHalf=10 Then
  UpperHalf="A"
ElseIf UpperHalf=11 then
  UppereHalf="B"
elseif UpperHalf=12 then
  UpperHalf="C"
elseif UpperHalf=13 then
  UpperHalf="D"
Elseif  UpperHalf=14 then
  UpperHalf="E"
elseif UpperHalf=15 then
  UpperHalf="F"
  EndIf
EndSub

Sub ConvertHexLower  'Converts lower half byte to hex format
If LowerHalf=10 Then
  LowerHalf="A"
 ElseIf LowerHalf=11 then
  LowerHalf="B"
elseif LowerHalf=12 then
  LowerHalf="C"
elseif LowerHalf=13 then
  LowerHalf="D"
Elseif LowerHalf=14 then
  LowerHalf="E"
elseif LowerHalf=15 then
  LowerHalf="F"
EndIf
EndSub

Answer 92

Here's a nice app to convert between USD, EUR and GBP (Based on Exchange rates of 18/2/09). Was going to add variable exchange rates and user=inputs, but i was too busy at the time

start:

TextWindow.WriteLine("Exchange rates are based on 20/2/09")

TextWindow.WriteLine("1. Convert from GBP to USD")

TextWindow.WriteLine("2. Convert from USD to GBP")

TextWindow.WriteLine("3. Convert from GBP to EUR")

TextWindow.WriteLine("4. Convert from EUR to GBP")

TextWindow.WriteLine("5. Convert from EUR to USD")

TextWindow.WriteLine("6. Convert from USD to EUR")

TextWindow.WriteLine("7. Exit")

TextWindow.Write("Choose your selection: ")

input = TextWindow.ReadNumber()

If (input = 1) Then

goto i1

EndIf

If (input = 2) Then

goto i2

EndIf

If (input = 3) Then

Goto i3

EndIf

If (input = 4) Then

Goto i4

EndIf

If (input = 5) Then

Goto i5

EndIf

If (input = 6) Then

Goto i6

EndIf

If (input = 7) Then

Goto i7

Else

TextWindow.WriteLine("Invalid Entry - Try again!")

Program.Delay(1000)

TextWindow.Clear()

Goto start

EndIf

i1:

Program.Delay(1000)

TextWindow.Clear()

TextWindow.Write("Enter amount in GBP: ")

gbpi1 = TextWindow.ReadNumber()

usdo1 = gbpi1*1.4349

TextWindow.WriteLine(gbpi1 + " GBP = " + usdo1 + " USD")

Program.Delay(5000)

TextWindow.Clear()

Goto start

i2:

Program.Delay(1000)

TextWindow.Clear()

TextWindow.Write("Enter amount in USD: ")

usdi2 = TextWindow.ReadNumber()

gbpo2 = usdi2*0.6969

TextWindow.WriteLine(usdi2 + " USD = " + gbpo2 + " GBP")

Program.Delay(5000)

TextWindow.Clear()

Goto start

i3:

Program.Delay(1000)

TextWindow.Clear()

TextWindow.Write("Enter amount in GBP: ")

gbpi3 = TextWindow.ReadNumber()

euro3 = gbpi3*1.1335

TextWindow.WriteLine(gbpi3 + " GBP = " + euro3 + " EUR")

Program.Delay(5000)

TextWindow.Clear()

Goto start

i4:

Program.Delay(1000)

TextWindow.Clear()

TextWindow.Write("Enter amount in EUR: ")

euri4 = TextWindow.ReadNumber()

gbpo4 = gbpi3*0.8867

TextWindow.WriteLine(euri4 + " EUR = " + gbpo4 + " GBP")

Program.Delay(5000)

TextWindow.Clear()

Goto start

i5:

Program.Delay(1000)

TextWindow.Clear()

TextWindow.Write("Enter amount in EUR: ")

euri5 = TextWindow.ReadNumber()

usdo5 = euri5*1.2690

TextWindow.WriteLine(euri5 + " EUR = " + usdo5 + " USD")

Program.Delay(5000)

TextWindow.Clear()

Goto start

i6:

Program.Delay(1000)

TextWindow.Clear()

TextWindow.Write("Enter amount in USD: ")

usdi6 = TextWindow.ReadNumber()

euro6 = usdi6*0.7870

TextWindow.WriteLine(usdi6 + " USD = " + euro6 + " EUR")

Program.Delay(5000)

TextWindow.Clear()

Goto start

i7:

Program.Delay(1000)

TextWindow.Clear()

TextWindow.WriteLine("Thank you for using this application")

TextWindow.WriteLine(" ")

TextWindow.WriteLine("(C)2009, Shmuxel (www.shmuxel.info)")

TextWindow.WriteLine(" ")

TextWindow.WriteLine("This Application was written on Microsoft Small Basic")

Program.Delay(5000)

Program.End()

Answer 93

I have re-written my Brick Wall program using Shapes for the bricks instead of drawing them.
Despite what Vijaye said about shapes being more "heavy/expensive" ("Adding a Shape Without it Showing in the Top Left Corner" thread) the speed of the code has improved, probably due to reduced complexity at the source level. I have also taken the opportunity to add a background image and do some tweaks to the software.
The shapes all get added at 0,0. I decided to use this as a feature instead of regarding it as a problem. The bricks are animated to their starting positions which I think gives quite a pleasing effect.

Import ref: HBB072

Answer 94

good job!!

---

moonhyuk choi

Answer 95

Thanks moonhyuk,
    I now offer up a piece of "op art" in the spirit of Small Basic, in that it serves no purpose but it's just fun. Import "Sticks" from FWM281.

Answer 96

1	music player!
2	Sound.PlayAndWait("C:\Documents and Settings\Jordan\Desktop\New Folder\Windows XP Startup.wav")
3	GraphicsWindow.ShowMessage("Thank you For lisening to my small basic media player","Thank You")
4	GraphicsWindow.Hide()
5	Sound.PlayAndWait("C:\Documents and Settings\Jordan\Desktop\New Folder\200265__Donkey_.mp3")
6	GraphicsWindow.ShowMessage("now for the next song","2")
7	GraphicsWindow.Hide()
8	Sound.PlayAndWait("C:\Documents and Settings\Jordan\Desktop\New Folder\Oh_No_Full_Length.mp3")
9	GraphicsWindow.ShowMessage("now for the next song","3")
10	GraphicsWindow.Hide()
11	Program.Delay(10)
12	Sound.PlayAndWait("C:\Documents and Settings\Jordan\Desktop\New Folder\alchemy[1].mp3")
13	GraphicsWindow.ShowMessage("now for the next song","4")
14	GraphicsWindow.Hide()
15	Sound.PlayAndWait("C:\Documents and Settings\Jordan\Desktop\New Folder\gamestartup01.mp3")
16	GraphicsWindow.ShowMessage("now for the next song","5")
17	GraphicsWindow.Hide()
18	Sound.PlayAndWait("C:\Documents and Settings\Jordan\Desktop\New Folder\windowsv.wav")
19	GraphicsWindow.ShowMessage("now for the next song","6")
20	GraphicsWindow.Hide()
21	Sound.PlayAndWait("135468_rickpwnerolledRemix.mp3")
22	GraphicsWindow.ShowMessage("Thanks agian for lisening and have a nice rest of your day","THANKs agian")
23	GraphicsWindow.ShowMessage("oh and last thing if you use my program add your name to the give credit list","one last thing" )
24	GraphicsWindow.ShowMessage("this program gives credit to jfmherokiller","credit given list")
25	GraphicsWindow.Hide()

this is a music player i wipped up i might not work but i also might i dont know if it will.

Answer 97

 Desktop Wallpaper Change from web page contents

Main()

Program.End()

Sub Main

PageContents=Network.GetWebPageContents("http://www.fotocommunity.de/pc/pc/channel/2/extra/new/display")

TmpDir=File.GetTemporaryFilePath()

File.WriteContents(TmpDir,PageContents)

File.AppendContents(TmpDir,"Ronely")

i=0

While("True")

Text=File.ReadLine(TmpDir,i)

i=i+1

SubText=Text.IsSubText(Text,"http://cdn.fotocommunity.com/thumbs/")

if SubText="true" Then

Len=Text.GetLength(Text)

Goto Next

Endif

Endwhile

Next:

For i=0 To Len-1 Step 1

CmpSubText = Text.GetSubText(Text, i, 1)

If CmpSubText = "d" then

CmpSubText = Text.GetSubText(Text, i, 2)

if CmpSubText = "di" then

CmpSubText = Text.GetSubText(Text, i, 3)

if CmpSubText = "dis" then

ImgName = Text.GetSubText(Text, i+8 , 8)

Goto Finish

Endif

Endif

Endif

EndFor

Finish:

desktop.SetWallPaper("http://cdn.fotocommunity.com/photos/"+ImgName+".jpg")

Endsub

Sorry for my english

Answer 98

A simple yet difficult "lights out" style game where you try to turn all of the squares black. When you press ENTER on a square, you change its color, as well as the colors of the squares on its sides. Try it out, you'll see what I mean...

'The point of the game is to turn all of the squares black

'Move with arrow keys,

'Change select square with Enter

GraphicsWindow.Width = 400

GraphicsWindow.Height = 400

GraphicsWindow.BackgroundColor = "DarkGray"

GraphicsWindow.Title = "Turn em Off"

GraphicsWindow.KeyDown = OnKeyDown

GraphicsWindow.Clear()

curx = 10

cury = 10

newx = 10

newy = 10

'Randomize and draw squars

For i=0 To 5

For j=0 To 5

x = Math.GetRandomNumber(2)

If (x = 2) Then

curcolor = "Black"

Else

curcolor = "Yellow"

EndIf

GraphicsWindow.BrushColor = curcolor

GraphicsWindow.FillRectangle(j*65+10,i*65+10,50,50)

EndFor

EndFor

DrawCur()

'Draw currently selected square by drawing larger red square then a smaller square inside

Sub DrawCur

curcolor = GraphicsWindow.GetPixel(curx+25,cury+25)

GraphicsWindow.BrushColor = "Red"

GraphicsWindow.FillRectangle(curx,cury,50,50)

GraphicsWindow.BrushColor = curcolor

GraphicsWindow.FillRectangle(curx+2,cury+2,46,46)

EndSub

Sub OnKeyDown

lkey = GraphicsWindow.LastKey

'Pre-set new cursor position

If (lkey = "Right") And (curx < 300)  Then

newx = curx + 65

newy = cury

EndIf

If (lkey = "Left") And (curx > 10) Then

newx = curx - 65

newy = cury

EndIf

If (lkey = "Down") And (cury < 300) Then

newx = curx

newy = cury + 65

EndIf

If (lkey = "Up") And (cury > 10) Then

newx = curx

newy = cury - 65

EndIf

'Draw square in currunt square w/o red borders and move

GraphicsWindow.BrushColor = curcolor

GraphicsWindow.FillRectangle(curx,cury,50,50)

curx = newx

cury = newy

If (lkey = "Return") Then

'Change current color

tempcolor = curcolor

ChangeColor()

GraphicsWindow.FillRectangle(curx,cury,50,50)

'Change top color

If (cury > 10) Then

tempcolor = GraphicsWindow.GetPixel(curx+25,cury-40)

ChangeColor()

GraphicsWindow.FillRectangle(curx,cury-65,50,50)

EndIf

'Change left color

If (curx > 10) Then

tempcolor = GraphicsWindow.GetPixel(curx-40,cury+25)

ChangeColor()

GraphicsWindow.FillRectangle(curx-65,cury,50,50)

EndIf

'Change right color

If (curx < 300) Then

tempcolor = GraphicsWindow.GetPixel(curx+90,cury+25)

ChangeColor()

GraphicsWindow.FillRectangle(curx+65,cury,50,50)

EndIf

'Change bottom color

If (cury < 300) Then

tempcolor = GraphicsWindow.GetPixel(curx+25,cury+90)

ChangeColor()

GraphicsWindow.FillRectangle(curx,cury+65,50,50)

EndIf

CheckWin()

EndIf

'Redraw currently selected square

DrawCur()

EndSub

'Change color from black to yellow and otherwise

Sub ChangeColor

If (tempcolor = "#FFFF00") Then 'Yellow

tempcolor = "Black"

Else

tempcolor = "Yellow"

EndIf

GraphicsWindow.BrushColor = tempcolor

EndSub

'Check all spaces for any yellow.  If not, you win and quit

Sub CheckWin

flagw = 0

For i=0 To 5

For j=0 To 5

If (GraphicsWindow.GetPixel(j*65+35,i*65+35) = "#FFFF00") Then

flagw = 1

EndIf

EndFor

EndFor

If (flagw = 0) Then

GraphicsWindow.ShowMessage("YOU WIN!","WINNER")

Program.End()

EndIf

EndSub

Good luck, it IS possible to beat.  Oh, and thanks for small basic!

Answer 99

"Lights Out" is our sample of the week:  http://blogs.msdn.com/smallbasic

Answer 100

I know you have already chosen your program for the blog but heres mine anyway, its just a simple etch a scetch although dose draw at a bit of an angle =D

'My first SB app, not my first VB one though ;)
'Learnt all of this syntax from all of you =D thankyou!
'By Oliver Caldwell, 15, VB and SB rule!
'And this runs off my memory stick...code in school =)

posx = GraphicsWindow.Width / 2
posy = GraphicsWindow.Height / 2
Switch1 = False
GraphicsWindow.Show()
GraphicsWindow.Title = "Etch a scetch!"
GraphicsWindow.Width = 1000
GraphicsWindow.Height = 700
GraphicsWindow.Left = 20
GraphicsWindow.Top = 20
GraphicsWindow.BackgroundColor = "Red"
GraphicsWindow.BrushColor = "Gray"
GraphicsWindow.FillRectangle(20, 20, 960, 660)
GraphicsWindow.BrushColor = "White"
GraphicsWindow.FillEllipse(10, 650, 100, 100)
GraphicsWindow.FillEllipse(890, 650, 100, 100)
GraphicsWindow.BrushColor = "Black"
GraphicsWindow.MouseDown = MouseDown
GraphicsWindow.MouseUp = MouseUp
GraphicsWindow.MouseMove = OnMouseMove

 Sub MouseDown
  Switch1 = "True"
 EndSub

 Sub MouseUp
  Switch1 = "False"
 EndSub

 Sub OnMouseMove
  If Mouse.MouseX > posx And Switch1 = "True" Then
    posx = posx + 1
    GraphicsWindow.FillRectangle(posx, posy, 1, 1)
  ElseIf Mouse.MouseX < posx And Switch1 = "True" Then
    posx = posx - 1
    GraphicsWindow.FillRectangle(posx, posy, 1, 1)
  EndIf
  If Mouse.MouseY > posy And Switch1 = "True" Then
    posy = posy + 1
    GraphicsWindow.FillRectangle(posx, posy, 1, 1)
  ElseIf Mouse.MouseY < posy And Switch1 = "True" Then
    posy = posy - 1
    GraphicsWindow.FillRectangle(posx, posy, 1, 1)
  Endif
 EndSub

Heres a screen shot:

Have fun ;) Wolfy87oc.

Answer 101

I've written an extension that makes the serial port usable in Small Basic.  It can be downloaded at http://code.msdn.microsoft.com/sbserial.

In the spirit of Small Basic, the extension purposefully makes assumptions about data bits, parity and stop bits.  Flow control defaults to None, but hardware flow control can be activated if needed.  There is no error handling, but (some) parameters passed to the extension are checked for validity and ignored if invalid.  If the extension fails to find the comm port specified in OpenPort, the highest numbered port available is opened.

Example SB code to use with a serial loopback cable: SNL137

' Example code for use with the SmallBasicSerialPort extension and a loopback
' serial cable.
' Replace "COM8", 75000 with settings appropriate for your system.
' Nino Carrillo 2009

CommPort.OpenPort("COM8",75000) 'Open COM8 at 75000 baud
CommPort.TXString("Hello World") 'Send a string to the port
CommPort.TXByte(10) 'Send linefeed
CommPort.TXByte(13) 'Send carriage return
Program.Delay(500) 'wait for buffers to fill
TextWindow.Write(CommPort.RXAll()) 'read the entire contents of the receive buffer and display
CommPort.TXString("A") 'send the letter A
Program.Delay(500)
TextWindow.Write("The value of the received byte is: " + CommPort.RXByte())
CommPort.TXByte(10) 'Send linefeed
CommPort.TXByte(13) 'Send carriage return
Program.Delay(500)
TextWindow.Write(CommPort.RXAll())
CommPort.TXString("A")
TextWindow.Write("The character received is: "+ CommPort.RXChar())
CommPort.TXByte(10) 'Send linefeed
CommPort.TXByte(13) 'Send carriage return
Program.Delay(500)
TextWindow.Write(CommPort.RXAll())
CommPort.ClosePort()
TextWindow.Write("List of ports available: " + CommPort.AvailablePorts())

Answer 102

This is Login/Laod program, save program coming soon. This is just a small EX:

T = 5
F = File.GetTemporaryFilePath()
TextWindow.WriteLine("Welcome to the land of Ncioah")
TextWindow.WriteLine("Are you a new or old user?")
R = TextWindow.Read()
If(R = "new")Then
  TextWindow.Hide()
  TextWindow.Show()
  TextWindow.WriteLine("Signup Sheet")
  TextWindow.Write("Username:")
  Y = TextWindow.Read()
  TextWindow.WriteLine("Password:")
  X = TextWindow.Read()
  File.WriteContents(F, Y + " " + X)
  C =  File.ReadContents(F)
  Textwindow.WriteLine("Please login")
  Goto start
  EndIf
If(R = "old")Then
  Start:
      If(T = "0")Then
      Program.End()
    EndIf
  TextWindow.WriteLine("Username")
  RR = TextWindow.Read()
  TextWindow.WriteLine("Password")
  RRR = TextWindow.Read()
  RRRR = File.ReadContents(F)
  If(Text.IsSubText(RRRR, RR + " " + RRR))Then
    TextWindow.WriteLine("You have succesfully logged in")
  Else
    T = T-1
    TextWindow.WriteLine("Login Failed " + T + " tries left")
    Goto Start
  EndIf
EndIf

Try it and tell me what you think. This can be used for like mario style games. Or maybe you suddenly have to stop pong but you were doing so good. This will help that.





Answer 103

Here is my Color Script. The turtle paints a pretty picture in my opinion! Enjoy!

GraphicsWindow.KeyDown = K
GraphicsWindow.Show()
GraphicsWindow.PenColor = "black"
GraphicsWindow.BackgroundColor = "blue"
Turtle.Speed =  10
angle = 12343
Squiral()

Sub Squiral
  side = 0
  For i = 1 To 360
    Turtle.Move(side)
    Turtle.Turn(angle)
    side = side + 1

  EndFor
EndSub

Program.Delay(10)

Sub K
  If(GraphicsWindow.LastKey = "F1")Then
    Program.End()
  EndIf
  EndSub


If you tamper around with the angle you find that the figure changes drastically. It is sure to come up with many more shapes and excitment!!!    By: Jacob

Answer 104

This is V1.0 of a Paint program I am working on. This program uses the GraphicsWindow as the workspace, and the TextWindow as the command reader. Type in commands in the textwindow to change the tools in the GraphicsWindow, most of the commands are listed in the Help section. Select the graphicsWindow and press H for most of the commands.

GraphicsWindow.Title = "Paint V1.0"

TextWindow.Title = "Command reader for Paint V1.0"

OH = GraphicsWindow.Height

OW = GraphicsWindow.Width

GraphicsWindow.Height = OH

GraphicsWindow.Width = OW

GraphicsWindow.MouseMove = OnMouseMove

GraphicsWindow.MouseDown = OnMouseDown

GraphicsWindow.KeyDown = K

GraphicsWindow.BrushColor = "red"

GraphicsWindow.DrawBoundText(10,10,100,"Press H for help")

GraphicsWindow.DrawBoundText(10,30,200,"Click to draw")

GraphicsWindow.DrawBoundText(10,50,200,"Type commands in the Text Window")

GraphicsWindow.DrawBoundText(10,80,300,"Paint your masterpeice!")

While(1=1)

TextWindow.WriteLine("type commands")

P  = TextWindow.Read()

C = Text.ConvertToLowerCase(P)

 Read()

 EndWhile



Sub K

If(GraphicsWindow.LastKey = "H")Then

Help()

Endif

  Endsub





Sub OnMouseDown

prevX = GraphicsWindow.MouseX

prevY = GraphicsWindow.MouseY

EndSub



Sub OnMouseMove

x = GraphicsWindow.MouseX

y = GraphicsWindow.MouseY

If (Mouse.IsLeftButtonDown) Then

  GraphicsWindow.DrawLine(prevX, prevY, x, y)

EndIf

prevX = x

prevY = y

EndSub





Sub Read

  If(C = "color")Then

    Color()

  EndIf

  If(C = "bg color")Then

  Bgcolr()

EndIf

If(C = "pensize")Then

Pen()

EndIf

If(C = "clear")Then

Clear()

EndIf

If(C = "window size")Then

GWS()

EndIf

If(C = "clear tewindow")Then

ClearT()

EndIf

If(C = "eraser")Then

Eraser()

EndIf

If(C = "rbg color")Then

RBG()

EndIf

If(C = "window.size = desktop")Then

Desktop()

EndIf

If(C = "window.size = half")Then

Half()

EndIf

If(C = "window.size = orignal")Then

Original()

EndIf

If(C = "rp color")Then

RPC()

EndIf

If(C = "text.color")Then

TC()

EndIf

If(C = "new")Then

New()

EndIf

If(C = "commands")Then

Commands()

EndIf

EndSub



Sub Color

  TextWindow.WriteLine("Type color")

  L = TextWindow.Read()

  GraphicsWindow.PenColor = L

  EndSub





  Sub Bgcolr

    TextWindow.WriteLine("Type color")

    W = TextWindow.Read()

    GraphicsWindow.BackgroundColor = W

  EndSub





  Sub Pen

    TextWindow.WriteLine("Type size")

    Size = TextWindow.ReadNumber()

    GraphicsWindow.PenWidth = Size

    EndSub





      Sub Clear

        GraphicsWindow.Clear()

      EndSub





      Sub GWS

        TextWindow.WriteLine("Type Height")

        HE = TextWindow.ReadNumber()

        TextWindow.WriteLine("Type Width")

        WI = TextWindow.ReadNumber()

        GraphicsWindow.Height = HE

        GraphicsWindow.Width = WI

      EndSub





      Sub Help

        GraphicsWindow.ShowMessage("Instructions", "HELP")

GraphicsWindow.ShowMessage("Click to draw", "HELP")

GraphicsWindow.ShowMessage("Use the Text Window to type commands", "HELP")

GraphicsWindow.ShowMessage("Type color to access the colors function", "HELP")

GraphicsWindow.ShowMessage("Then type the color you want to change it to", "HELP")

GraphicsWindow.ShowMessage("Type bg color to access the background colors", "HELP")

GraphicsWindow.ShowMessage("Type window size to resize the Graphics window", "HELP")

GraphicsWindow.ShowMessage("Type clear to clear the screen", "HELP")

GraphicsWindow.ShowMessage("Type clear textwindow to clear the textwindow", "HELP")

GraphicsWindow.ShowMessage("Type window.size = desktop to make a full screen window", "HELP")

GraphicsWindow.ShowMessage("Type window.size = half for a half screen window", "HELP")

GraphicsWindow.ShowMessage("Type rbg color for a random background color", "HELP")

GraphicsWindow.ShowMessage("Type rp color for a random pencolor", "HELP")

EndSub





Sub ClearT

  TextWindow.Clear()

EndSub





Sub Eraser

  GraphicsWindow.PenColor = GraphicsWindow.BackgroundColor

EndSub





Sub RBG

  GraphicsWindow.BackgroundColor = GraphicsWindow.GetRandomColor()

  EndSub





Sub Desktop

  GraphicsWindow.Height = Desktop.Height - 65

  GraphicsWindow.Width = Desktop.Width - 10

EndSub





Sub Half

  GraphicsWindow.Height = Desktop.Height-200

  GraphicsWindow.Width = Desktop.Width-200

  EndSub





  Sub Original

    GraphicsWindow.Width = OW

    GraphicsWindow.Height = OH

  EndSub





  Sub RPC

    GraphicsWindow.PenColor = GraphicsWindow.GetRandomColor()

  EndSub



  Sub TC

    TextWindow.WriteLine("Type color")

    Forec = TextWindow.Read()

    TextWindow.ForegroundColor = Forec

  EndSub





  Sub New

    GraphicsWindow.Clear()

    TextWindow.Clear()

  EndSub





  Sub Commands

    GraphicsWindow.Clear()

    GraphicsWindow.BrushColor = "black"

    GraphicsWindow.DrawBoundText(10,10,100,"Soon to come")

    'I will add this in the next version'

    'it will be a list of all the commands and sub commands in the system'

    EndSub







Please post requests for new functions and Ideas so that I can keep improving this program, my next V1.2 will be posted probably in a week or two. I am working on V1.2 and I have added a turtle function. You can either type in the co's X and Y for it to move to that position or type which direction and color and how far. I haven't made it so you can do angles yet though.

The Hacker

Answer 105

A Chess Game in Small Basic (no, there's no AI !)

The moves are checked to see if they are valid. You need two players to play the game.

The game is in French (though it's only welcome & error messages that are in French). Echecs are not discovered by the program, the play stops when one of the king are taken by another piece.

If you discover bug, I'm ready to fix theses, but I think everything should be good.
[EDIT] Edited today to support Roques. My program doesn't check if the king is in echec at any position of the roque's move.

You can download the game (.exe), the source code and the images at this location :
http://cid-201f3835d49587fe.skydrive.live.com/self.aspx/Public/Small%20Basic/ChessGame.zip

For information, there's 550 lines of code. I used my extension for the UI.

Fremy

---

Fremy - Developer in VB.NET, C# and JScript ... - Feel free to try my extension

Answer 106

Here is V1.1 of my paint program, it now has 435 lines of code. The turtle function has been added and if you type commands.list in the command window it will list all the commands in the system V1.1 and all the sub commands will be added in V1.2. Try it out!

'SKC161'
'435 lines!'
GraphicsWindow.Title = "Paint V1.0"
TextWindow.Title = "Command reader for Paint V1.0"
OH = GraphicsWindow.Height
OW = GraphicsWindow.Width
GraphicsWindow.Height = OH
GraphicsWindow.Width = OW
GraphicsWindow.MouseMove = OnMouseMove
GraphicsWindow.MouseDown = OnMouseDown
GraphicsWindow.KeyDown = K
GraphicsWindow.BrushColor = "red"
GraphicsWindow.DrawBoundText(10,10,100,"Press H for help")
GraphicsWindow.DrawBoundText(10,30,200,"Click to draw")
GraphicsWindow.DrawBoundText(10,50,200,"Type commands.list in the Text Window for more help")
GraphicsWindow.DrawBoundText(10,80,300,"Paint your masterpeice!")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("What's your name?")
RNT = TextWindow.Read()
GraphicsWindow.Title = RNT + "'s masterpeice! V1.1"
TextWindow.ForegroundColor = "gray"
While(1=1)
TextWindow.WriteLine("type commands")
P  = TextWindow.Read()
C = Text.ConvertToLowerCase(P)
 Read()
 EndWhile

Sub K
If(GraphicsWindow.LastKey = "H")Then
Help()
Endif
  Endsub


Sub OnMouseDown
prevX = GraphicsWindow.MouseX
prevY = GraphicsWindow.MouseY
EndSub

Sub OnMouseMove
x = GraphicsWindow.MouseX
y = GraphicsWindow.MouseY
If (Mouse.IsLeftButtonDown) Then
  GraphicsWindow.DrawLine(prevX, prevY, x, y)
EndIf
prevX = x
prevY = y
EndSub


Sub Read
  If(C = "pen.color")Then
    Color()
  EndIf
  If(C = "paint.bgcolor")Then
  Bgcolr()
EndIf
If(C = "pen.size")Then
Pen()
EndIf
If(C = "paint.clear")Then
Clear()
EndIf
If(C = "paint.window.size")Then
GWS()
EndIf
If(C = "text.clear")Then
ClearT()
EndIf
If(C = "paint.eraser")Then
Eraser()
EndIf
If(C = "paint.rbgcolor")Then
RBG()
EndIf
If(C = "window.size = desktop")Then
Desktop()
EndIf
If(C = "window.size = half")Then
Half()
EndIf
If(C = "window.size = orignal")Then
Original()
EndIf
If(C = "paint.rpcolor")Then
RPC()
EndIf
If(C = "text.color")Then
TC()
EndIf
If(C = "project.new")Then
New()
EndIf
If(C = "commands.list")Then
Commands()
EndIf
If(C = "turtle.moveto")Then
TurtleM()
EndIf
If(C = "turtle.move")Then
Turtle()
EndIf
If(C = "flickr.random")THen
Flickr()
Endif
If(C = "text.bgcolor")Then
TBGC()
EndIf
If(C = "text.name")THen
TWN()
EndIf
If(C = "project.name")Then
PaintN()
EndIf
If(C = "paint.pen")Then
PPEN()
EndIf
EndSub


Sub Color
  TextWindow.WriteLine("Type color")
  L = TextWindow.Read()
  GraphicsWindow.PenColor = L
  EndSub


  Sub Bgcolr
    TextWindow.WriteLine("Type color")
    W = TextWindow.Read()
    GraphicsWindow.BackgroundColor = W
  EndSub


  Sub Pen
    TextWindow.WriteLine("Type size")
    Size = TextWindow.ReadNumber()
    GraphicsWindow.PenWidth = Size
    EndSub


      Sub Clear
        GraphicsWindow.Clear()
      EndSub


      Sub GWS
        TextWindow.WriteLine("Type Height")
        HE = TextWindow.ReadNumber()
        TextWindow.WriteLine("Type Width")
        WI = TextWindow.ReadNumber()
        GraphicsWindow.Height = HE
        GraphicsWindow.Width = WI
      EndSub


      Sub Help
        GraphicsWindow.ShowMessage("Instructions", "HELP")
GraphicsWindow.ShowMessage("Click to draw", "HELP")
GraphicsWindow.ShowMessage("Use the Text Window to type commands", "HELP")
GraphicsWindow.ShowMessage("Type color to access the colors function", "HELP")
GraphicsWindow.ShowMessage("Then type the color you want to change it to", "HELP")
GraphicsWindow.ShowMessage("Type bg color to access the background colors", "HELP")
GraphicsWindow.ShowMessage("Type window size to resize the Graphics window", "HELP")
GraphicsWindow.ShowMessage("Type clear to clear the screen", "HELP")
GraphicsWindow.ShowMessage("Type clear textwindow to clear the textwindow", "HELP")
GraphicsWindow.ShowMessage("Type window.size = desktop to make a full screen window", "HELP")
GraphicsWindow.ShowMessage("Type window.size = half for a half screen window", "HELP")
GraphicsWindow.ShowMessage("Type rbg color for a random background color", "HELP")
GraphicsWindow.ShowMessage("Type rp color for a random pencolor", "HELP")
EndSub


Sub ClearT
  TextWindow.Clear()
EndSub


Sub Eraser
  GraphicsWindow.PenColor = GraphicsWindow.BackgroundColor
EndSub


Sub RBG
  GraphicsWindow.BackgroundColor = GraphicsWindow.GetRandomColor()
  EndSub


Sub Desktop
  GraphicsWindow.Height = Desktop.Height - 65
  GraphicsWindow.Width = Desktop.Width - 10
EndSub


Sub Half
  GraphicsWindow.Height = Desktop.Height-200
  GraphicsWindow.Width = Desktop.Width-200
  EndSub


  Sub Original
    GraphicsWindow.Width = OW
    GraphicsWindow.Height = OH
  EndSub


  Sub RPC
    GraphicsWindow.PenColor = GraphicsWindow.GetRandomColor()
  EndSub

  Sub TC
    TextWindow.WriteLine("Type text foreground color")
    Forec = TextWindow.Read()
    TextWindow.ForegroundColor = Forec
  EndSub


  Sub New
    GraphicsWindow.Clear()
    TextWindow.Clear()
  EndSub


  Sub Commands
  TextWindow.Clear()
TextWindow.ForegroundColor = "yellow"
TextWindow.WriteLine("Here is a list of all the commands")
TextWindow.WriteLine("Commands will be listed in red")
TextWindow.WriteLine("Sub commands will be liste in blue under there parent command(Will be added in later version)")
TextWindow.WriteLine("Summarys of commands and Sub commands will be listed under there parent in gray")
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("pen.color")
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("will let you choose the color of the pen/pencil")
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Pen.Size")
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("Will let you choose the size of the pen/pencil")
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Paint.bgcolor")
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("Will let you choose the background color of the graphicswindow")
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Paint.Clear")
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("Will clear the project screen")
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Paint.Window.Size")
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("Will let you choose the size of the project window")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine(" ")
TextWindow.WriteLine("Text.Clear")
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("Will clear the command screen")
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Paint.Eraser")
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("Will change the pen to an eraser")
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Paint.Pen")
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("Will change the pen from eraser back to pen")
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Paint.RBGColor")
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("Will change the project screens background color to a random color")
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Window.Size")
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("Will let you change the size of the project window")
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Window.Size = Desktop")
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("Will make the project window full screen")
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Window.Size = Half")
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("Will change the project window to half screen")
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Paint.RPColor")
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("Will change the pen to a random color")
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Text.Color")
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("This will let you change the color of the text in the command screen")
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Project.New")
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("This will clear both the command screen and the project screen")
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Commands.List")
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("This will list all the commands and sub commands in the system")
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Turtle.Move")
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("This will let you draw lines with the turtle function")
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Turtle.MoveTo")
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("Will let you draw lines with the turtle using the X and Y axis")
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Flickr.Random")
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("Will choose a random picture from Flickr and set it for the background")
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Text.BGColor")
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("Will let you choose the background color for the command screen")
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Text.Name")
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("Will let you choose the name of the command screen, the text on the top bar of the command screen")
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Project.Name")
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("This will let you change the name of the project screen, the text on the top bar of the project screen")
  EndSub


  Sub TurtleM

  TextWindow.WriteLine("Pen up or Pen down?")
  RRR = TextWindow.Read()
  If(RRR = "up")Then
    Turtle.PenUp()
TextWindow.WriteLine("Turtle.MoveTo X co's?")
R = TextWindow.ReadNumber()
TextWindow.WriteLine("Turtle.MoveTo Y co's")
RR = TextWindow.ReadNumber()
Turtle.MoveTo(R,RR)
ElseIf(RRR = "down")Then
  TextWindow.WriteLine("What color?")
  RRRR = TextWindow.Read()
  GraphicsWindow.PenColor = RRRR
  Turtle.PenDown()
  TextWindow.WriteLine("Turtle.MoveTo X co's?")
R = TextWindow.ReadNumber()
TextWindow.WriteLine("Turtle.MoveTo Y co's")
RR = TextWindow.ReadNumber()
Turtle.MoveTo(R,RR)
EndIf
EndSub


Sub Turtle
TextWindow.WriteLine("Which direction")
RD = TextWindow.Read()
TextWindow.WriteLine("How many degrees?")
RTD = TextWindow.ReadNumber()
TextWindow.WriteLine("Pen up or Pen down?")
RUD = TextWindow.Read()
TextWindow.WriteLine("How far?")
RDD = TextWindow.ReadNumber()
TextWindow.WriteLine("What color?")
RC = TextWindow.Read()
GraphicsWindow.PenColor = RC
If(RUD = "up")Then
  Turtle.PenUp()
ElseIf(RUD = "down")Then
  Turtle.PenDown()
  EndIf
If(RD = "right")Then
  Turtle.TurnRight()
  Turtle.Move(RDD)
ElseIf(RD = "left")Then
  Turtle.TurnLeft()
  Turtle.Move(RDD)
EndIf
If(RD = "angle")Then
  Turtle.Turn(RTD)
  Turtle.Move(RDD)
  EndIf
EndSub


Sub Flickr
  TextWindow.WriteLine("Subject one?")
  RSO = TextWindow.Read()
  TextWindow.WriteLine("Subject two")
  RST = TextWindow.Read()
  Pic = Flickr.GetRandomPicture(RSO + RST)
  GraphicsWindow.DrawResizedImage(Pic,0,0,GraphicsWindow.Width,GraphicsWindow.Height)
EndSub


Sub TBGC
  TextWindow.WriteLine("Type text background color")
  RTBGC = TextWindow.Read()
  TextWindow.BackgroundColor = RTBGC
  TextWindow.Clear()
  EndSub


  Sub TWN
    TextWindow.WriteLine("New Name?")
    RNN = TextWindow.Read()
    TextWindow.Title = RNN
  Endsub


  Sub PaintN
    TextWindow.WriteLine("New project name?")
    RNPN = TextWindow.Read()
    GraphicsWindow.Title = RNPN
  EndSub


  Sub PPEN
    GraphicsWindow.PenColor = "black"
    EndSub


Answer 107

Looks great, the hacker.

It would be even better if you can use buttons in the master window to handle the GUI.
You should then restrict the zone where we can paint, though...

---

Fremy - Developer in VB.NET, C# and JScript ... - Feel free to try my extension

Answer 108

I am actually working on a version with buttons and the textwindow. So that the buttons will control the main commands like color, eraser e.t.c. Thanks for the idea.

I have finished a few buttons and the painting box for V1.3, but ran into some difficultys with the turtle functions. So it might be a little longer then expected but it'll be worth the wait!

Answer 109

Here is V1.3(Added buttons). Features have been added that have not been listed yet, but don't worry they will be. I am still having problems with the turtle functions. I can't get it to stop drawing once it leaves the square. But if you have any function requests or ideas please contribute them. If you find any bugs please tell me as well.

'Epic Paint'
'V1.3(beta)'
'802 lines!'
'WDL232'
Size = 1
L = GraphicsWindow.PenColor
GraphicsWindow.Title = "Paint V1.3"
TextWindow.Title = "Command reader for Paint V1.3"
'Sets the first buttons X and Y co's'
ButtonY = GraphicsWindow.Height-20
ButtonX = GraphicsWindow.Width-625
'Sets the height and width of all the buttons'
ButtonHe = 10
ButtonWi = 10
'Sets the second buttons X and Y co's'
Button2Y = GraphicsWindow.Height-20
Button2X = GraphicsWindow.Width-614
GreenY = GraphicsWindow.Height-20
GreenX = GraphicsWindow.Width-602
ToolsX = 10
ToolsY = 200
EraserX = 15
EraserY = 205
EraserWi = 40
EraserHe = 15
PenX = 65
PenY = 205
GraphicsWindow.BrushColor = "black"
GraphicsWindow.DrawRectangle(PenX,PenY,EraserWi,EraserHe)
GraphicsWindow.DrawBoundText(PenX+5,PenY,EraserWi,"Pen")
GraphicsWindow.DrawBoundText(EraserX,EraserY,EraserWi,"Eraser")
GraphicsWindow.DrawRectangle(EraserX,EraserY,40,15)
BoxX = 120
BoxY = 10
BoxHe = 400
BoxWi = 500
GraphicsWindow.DrawRectangle(ToolsX,ToolsY,100,200)
GraphicsWindow.BrushColor = "green"
GraphicsWindow.FillRectangle(GreenX,GreenY,ButtonWi,ButtonHe)
GraphicsWindow.DrawRectangle(BoxX,BoxY,BoxWi,BoxHe)
'Draws the first button'
GraphicsWindow.BrushColor = "blue"
GraphicsWindow.FillRectangle(Button2X,Button2Y,ButtonWi,ButtonHe)
'Draws the second button'
GraphicsWindow.BrushColor = "red"
GraphicsWindow.FillRectangle(ButtonX,ButtonY,ButtonWi,ButtonHe)
GraphicsWindow.BrushColor = "blue"
GraphicsWindow.DrawBoundText(GraphicsWindow.Width-GraphicsWindow.Width+10,GraphicsWindow.Height-40,100,"Pen.Size = " + Size)
GraphicsWindow.BrushColor = L
GraphicsWindow.DrawBoundText(GraphicsWindow.Width-GraphicsWindow.Width+10,GraphicsWindow.Height-50,300, "Pen.Color = " + L)
GraphicsWindow.DrawBoundText(GraphicsWindow.Width-GraphicsWindow.Width+10,GraphicsWindow.Height-60,300, "Turtle.Color = " + L)
OH = GraphicsWindow.Height
OW = GraphicsWindow.Width
GraphicsWindow.Height = OH
GraphicsWindow.Width = OW
GraphicsWindow.MouseMove = OnMouseMove
GraphicsWindow.MouseDown = OnMouseDown
GraphicsWindow.KeyDown = K
'Draws a few help commands'
GraphicsWindow.BrushColor = "red"
GraphicsWindow.DrawBoundText(10,10,100,"1, Press H for help")
GraphicsWindow.DrawBoundText(10,50,100,"2, Click to draw")
GraphicsWindow.DrawBoundText(10,80,100,"3, Type commands.list in the Text Window for more help")
GraphicsWindow.DrawBoundText(10,160,100,"4, Paint your masterpeice")
'Changes the title of the project windows to "Your name here"(s) masterpeice'
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("What's your name?")
RNT = TextWindow.Read()
GraphicsWindow.Title = RNT + "'s masterpeice! V1.1"
TextWindow.Title = RNT + "'s masterpeice
TextWindow.ForegroundColor = "gray"
'Generates a forever going While loop that reads the users commands'
While(1=1)
  'Plays a clicking sound'
  Sound.PlayClick()
TextWindow.WriteLine("type commands")
P  = TextWindow.Read()
C = Text.ConvertToLowerCase(P)
 Read()
EndWhile


Sub K
  If(GraphicsWindow.LastKey = "H")Then
    Sound.PlayClick()
Help()
Endif
  Endsub


Sub OnMouseDown
  Sound.PlayClick()
  'Gets the X and Y co's for where the mouse clicked'
prevX = GraphicsWindow.MouseX
prevY = GraphicsWindow.MouseY
'Checks if they clicked inside the first button'
If(prevX > ButtonX And prevX < (ButtonX + ButtonWi)) And (prevY > ButtonY And prevY < (ButtonY + ButtonHe))Then
  GraphicsWindow.PenColor = "red"
  GraphicsWindow.BrushColor = "white"
  GraphicsWindow.FillRectangle(GraphicsWindow.Width-GraphicsWindow.Width+10,GraphicsWindow.Height-50,300,12)
  L = GraphicsWindow.PenColor
  GraphicsWindow.BrushColor = L
GraphicsWindow.DrawBoundText(GraphicsWindow.Width-GraphicsWindow.Width+10,GraphicsWindow.Height-50,300, "Pen.Color = " + L)
'Checks if they clicked inside the second button'
ElseIf(prevX > Button2X And prevX < (Button2X + ButtonWi)) And (prevY > Button2Y And prevY < (Button2Y + ButtonHe))Then
  GraphicsWindow.PenColor = "blue"
  GraphicsWindow.BrushColor = "white"
  GraphicsWindow.FillRectangle(GraphicsWindow.Width-GraphicsWindow.Width+10,GraphicsWindow.Height-50,300,12)
  L = GraphicsWindow.PenColor
  GraphicsWindow.BrushColor = L
GraphicsWindow.DrawBoundText(GraphicsWindow.Width-GraphicsWindow.Width+10,GraphicsWindow.Height-50,300, "Pen.Color = " + L)
ElseIf(prevX > GreenX And prevX < (GreenX + ButtonWi)) And (prevY > GreenY And prevY < (GreenY + ButtonHe))Then
  GraphicsWindow.PenColor = "green"
  GraphicsWindow.BrushColor = "white"
  GraphicsWindow.FillRectangle(GraphicsWindow.Width-GraphicsWindow.Width+10,GraphicsWindow.Height-50,300,12)
  L = GraphicsWindow.PenColor
  GraphicsWindow.BrushColor = L
GraphicsWindow.DrawBoundText(GraphicsWindow.Width-GraphicsWindow.Width+10,GraphicsWindow.Height-50,300, "Pen.Color = " + L)
ElseIf(prevX > EraserX And prevX < (EraserX + EraserWi)) And (prevY > EraserY And prevY < (EraserY + EraserHe))Then
  GraphicsWindow.PenColor = GraphicsWindow.BackgroundColor
  GraphicsWindow.BrushColor = "white"
  GraphicsWindow.FillRectangle(GraphicsWindow.Width-GraphicsWindow.Width+10,GraphicsWindow.Height-50,300,12)
  GraphicsWindow.BrushColor = "black"
GraphicsWindow.DrawBoundText(GraphicsWindow.Width-GraphicsWindow.Width+10,GraphicsWindow.Height-50,300, "Pen.Color = Eraser")
ElseIf(prevX > PenX And prevX < (PenX + EraserWi)) And (prevY > PenY And prevY < (PenY + EraserHe))Then
  GraphicsWindow.PenColor = "black"
  GraphicsWindow.BrushColor = "white"
  GraphicsWindow.FillRectangle(GraphicsWindow.Width-GraphicsWindow.Width+10,GraphicsWindow.Height-50,300,12)
GraphicsWindow.BrushColor = "black"
GraphicsWindow.DrawBoundText(GraphicsWindow.Width-GraphicsWindow.Width+10,GraphicsWindow.Height-50,300, "Pen.Color = Black")

EndIf
If(prevX > BoxX And prevX < (BoxX + BoxWi)) And (prevY > BoxY And prevY < (BoxY + BoxHe))Then
 If(Mouse.IsRightButtonDown = "true")Then
  GraphicsWindow.DrawRectangle(GraphicsWindow.MouseX,GraphicsWindow.MouseY,50,50)
  EndIf
  EndIf
EndSub


Sub OnMouseMove
  If(prevX > BoxX And prevX < (BoxX + BoxWi)) And (prevY > BoxY And prevY < (BoxY + BoxHe))Then
  'Gets the X and Y co's of the mouse whenever it moves forever'
x = GraphicsWindow.MouseX
y = GraphicsWindow.MouseY
'Checks if the left is down and draws the line'
If (Mouse.IsLeftButtonDown) Then
  GraphicsWindow.DrawLine(prevX, prevY, x, y)
  EndIf
  EndIf
prevX = x
prevY = y
EndSub


Sub Read
  'Checks if the command inputed by the user is valid'
  If(C = "pen.color")Then
    Sound.PlayClick()
    Color()
  EndIf
  If(C = "paint.bgcolor")Then
    Sound.PlayClick()
  Bgcolr()
EndIf
If(C = "pen.size")Then
  Sound.PlayClick()
Pen()
EndIf
If(C = "paint.clear")Then
  Sound.PlayClick()
Clear()
EndIf
If(C = "paint.window.size")Then
  Sound.PlayClick()
GWS()
EndIf
If(C = "text.clear")Then
  Sound.PlayClick()
ClearT()
EndIf
If(C = "paint.eraser")Then
  Sound.PlayClick()
Eraser()
EndIf
If(C = "paint.rbgcolor")Then
  Sound.PlayClick()
RBG()
EndIf
If(C = "window.size = desktop")Then
  Sound.PlayClick()
Desktop()
EndIf
If(C = "window.size = half")Then
  Sound.PlayClick()
Half()
EndIf
If(C = "window.size = orignal")Then
  Sound.PlayClick()
Original()
EndIf
If(C = "paint.rpcolor")Then
RPC()
EndIf
If(C = "text.color")Then
TC()
EndIf
If(C = "project.new")Then
  Sound.PlayClick()
New()
EndIf
If(C = "commands.list")Then
  Sound.PlayClick()
Commands()
EndIf
If(C = "turtle.moveto")Then
  Sound.PlayClick()
TurtleM()
EndIf
If(C = "turtle.move")Then
  Sound.PlayClick()
Turtle()
EndIf
If(C = "flickr.random")THen
  Sound.PlayClick()
Flickr()
Endif
If(C = "text.bgcolor")Then
  Sound.PlayClick()
TBGC()
EndIf
If(C = "text.name")THen
  Sound.PlayClick()
TWN()
EndIf
If(C = "project.name")Then
  Sound.PlayClick()
PaintN()
EndIf
If(C = "paint.pen")Then
  Sound.PlayClick()
PPEN()
EndIf
If(C = "turtle.hide")Then
  Sound.PlayClick()
TurtleH()
EndIf
If(C = "turtle.draw.rect")Then
Turtlerect()
EndIf
If(C = "turtle.draw.star")Then
Star()
EndIf
EndSub


Sub Color
  'Changes the pen color to whatever color you can think of'
  TextWindow.WriteLine("Type color")
  L = TextWindow.Read()
GraphicsWindow.PenColor = L
    GraphicsWindow.BrushColor = "white"
    GraphicsWindow.FillRectangle(GraphicsWindow.Width-GraphicsWindow.Width+10,GraphicsWindow.Height-50,300,12)
    GraphicsWindow.BrushColor = L
GraphicsWindow.DrawBoundText(GraphicsWindow.Width-GraphicsWindow.Width+10,GraphicsWindow.Height-50,300, "Pen.Color = " + L)

  EndSub


  Sub Bgcolr
    'Changes the background color to whatever color you can think of'
    TextWindow.WriteLine("Type color")
    W = TextWindow.Read()
    GraphicsWindow.BackgroundColor = W
  EndSub


  Sub Pen
    Pen:
    'Changes the pen size to whatever number you wish below 6'
    TextWindow.WriteLine("Type size")
    Size = TextWindow.ReadNumber()
    If(Size < 6)Then
      GraphicsWindow.PenWidth = Size
      GraphicsWindow.BrushColor = "white"
    GraphicsWindow.FillRectangle(GraphicsWindow.Width-GraphicsWindow.Width+10,GraphicsWindow.Height-40,110,15)
     GraphicsWindow.BrushColor = "blue"
    GraphicsWindow.DrawBoundText(GraphicsWindow.Width-GraphicsWindow.Width+10,GraphicsWindow.Height-40,100,"Pen.Size = " + Size)
    ElseIf(Size >= 6)Then
      TextWindow.WriteLine("Invalid size")
      Goto Pen
    EndIf
    EndSub


      Sub Clear
        GraphicsWindow.Clear()
      EndSub


      Sub GWS
        TextWindow.WriteLine("Type Height")
        HE = TextWindow.ReadNumber()
        Sound.PlayClick()
        TextWindow.WriteLine("Type Width")
        WI = TextWindow.ReadNumber()
        GraphicsWindow.Height = HE
        GraphicsWindow.Width = WI
      EndSub


      Sub Help
        GraphicsWindow.ShowMessage("Instructions", "HELP")
GraphicsWindow.ShowMessage("Click to draw", "HELP")
GraphicsWindow.ShowMessage("Use the Text Window to type commands", "HELP")
GraphicsWindow.ShowMessage("Type color to access the colors function", "HELP")
GraphicsWindow.ShowMessage("Then type the color you want to change it to", "HELP")
GraphicsWindow.ShowMessage("Type bg color to access the background colors", "HELP")
GraphicsWindow.ShowMessage("Type window size to resize the Graphics window", "HELP")
GraphicsWindow.ShowMessage("Type clear to clear the screen", "HELP")
GraphicsWindow.ShowMessage("Type clear textwindow to clear the textwindow", "HELP")
GraphicsWindow.ShowMessage("Type window.size = desktop to make a full screen window", "HELP")
GraphicsWindow.ShowMessage("Type window.size = half for a half screen window", "HELP")
GraphicsWindow.ShowMessage("Type rbg color for a random background color", "HELP")
GraphicsWindow.ShowMessage("Type rp color for a random pencolor", "HELP")
EndSub


Sub ClearT
  TextWindow.Clear()
EndSub


Sub Eraser
  GraphicsWindow.PenColor = GraphicsWindow.BackgroundColor
EndSub


Sub RBG
  GraphicsWindow.BackgroundColor = GraphicsWindow.GetRandomColor()
  EndSub


Sub Desktop
  GraphicsWindow.Height = Desktop.Height - 65
  GraphicsWindow.Width = Desktop.Width - 10
EndSub


Sub Half
  GraphicsWindow.Height = Desktop.Height-200
  GraphicsWindow.Width = Desktop.Width-200
  EndSub


  Sub Original
    GraphicsWindow.Width = OW
    GraphicsWindow.Height = OH
  EndSub


  Sub RPC
    GraphicsWindow.PenColor = GraphicsWindow.GetRandomColor()
    L = GraphicsWindow.PenColor
    GraphicsWindow.BrushColor = "white"
    GraphicsWindow.FillRectangle(GraphicsWindow.Width-GraphicsWindow.Width+10,GraphicsWindow.Height-50,300,12)
    GraphicsWindow.BrushColor = L
GraphicsWindow.DrawBoundText(GraphicsWindow.Width-GraphicsWindow.Width+10,GraphicsWindow.Height-50,300, "Pen.Color = " + L)
  EndSub

  Sub TC
    TextWindow.WriteLine("Type text foreground color")
    Forec = TextWindow.Read()
    TextWindow.ForegroundColor = Forec
  EndSub


  Sub New
    'Epic Paint'
'V1.3(beta)'
'700 lines!'
Size = 1
L = GraphicsWindow.PenColor
GraphicsWindow.Title = "Paint V1.3"
TextWindow.Title = "Command reader for Paint V1.3"
'Sets the first buttons X and Y co's'
ButtonY = GraphicsWindow.Height-20
ButtonX = GraphicsWindow.Width-625
'Sets the height and width of all the buttons'
ButtonHe = 10
ButtonWi = 10
'Sets the second buttons X and Y co's'
Button2Y = GraphicsWindow.Height-20
Button2X = GraphicsWindow.Width-614
GreenY = GraphicsWindow.Height-20
GreenX = GraphicsWindow.Width-602
ToolsX = 10
ToolsY = 200
EraserX = 15
EraserY = 205
EraserWi = 40
EraserHe = 15
GraphicsWindow.BrushColor = "black"
GraphicsWindow.DrawBoundText(EraserX,EraserY,EraserWi,"Eraser")
GraphicsWindow.DrawRectangle(EraserX,EraserY,40,15)
BoxX = 120
BoxY = 10
BoxHe = 400
BoxWi = 500
GraphicsWindow.DrawRectangle(ToolsX,ToolsY,100,200)
GraphicsWindow.BrushColor = "green"
GraphicsWindow.FillRectangle(GreenX,GreenY,ButtonWi,ButtonHe)
GraphicsWindow.DrawRectangle(BoxX,BoxY,BoxWi,BoxHe)
'Draws the first button'
GraphicsWindow.BrushColor = "blue"
GraphicsWindow.FillRectangle(Button2X,Button2Y,ButtonWi,ButtonHe)
'Draws the second button'
GraphicsWindow.BrushColor = "red"
GraphicsWindow.FillRectangle(ButtonX,ButtonY,ButtonWi,ButtonHe)
GraphicsWindow.BrushColor = "blue"
GraphicsWindow.DrawBoundText(GraphicsWindow.Width-GraphicsWindow.Width+10,GraphicsWindow.Height-40,100,"Pen.Size = " + Size)
GraphicsWindow.BrushColor = "white"
    GraphicsWindow.FillRectangle(GraphicsWindow.Width-GraphicsWindow.Width+10,GraphicsWindow.Height-50,300,12)
GraphicsWindow.BrushColor = L
GraphicsWindow.DrawBoundText(GraphicsWindow.Width-GraphicsWindow.Width+10,GraphicsWindow.Height-50,300, "Pen.Color = " + L)
OH = GraphicsWindow.Height
OW = GraphicsWindow.Width
GraphicsWindow.Height = OH
GraphicsWindow.Width = OW
GraphicsWindow.MouseMove = OnMouseMove
GraphicsWindow.MouseDown = OnMouseDown
GraphicsWindow.KeyDown = K
'Draws a few help commands'
GraphicsWindow.BrushColor = "red"
GraphicsWindow.DrawBoundText(10,10,100,"1, Press H for help")
GraphicsWindow.DrawBoundText(10,50,100,"2, Click to draw")
GraphicsWindow.DrawBoundText(10,80,100,"3, Type commands.list in the Text Window for more help")
GraphicsWindow.DrawBoundText(10,160,100,"4, Paint your masterpeice")
'Changes the title of the project windows to "Your name here"(s) masterpeice'
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("What's your name?")
RNT = TextWindow.Read()
GraphicsWindow.Title = RNT + "'s masterpeice! V1.1"
TextWindow.Title = RNT + "'s masterpeice
TextWindow.ForegroundColor = "gray"
'Generates a forever going While loop that reads the users commands'
  EndSub


  Sub Commands
  TextWindow.Clear()
TextWindow.ForegroundColor = "yellow"
TextWindow.WriteLine("Here is a list of all the commands")
Sound.PlayClick()
TextWindow.WriteLine("Commands will be listed in red")
Sound.PlayClick()
TextWindow.WriteLine("Sub commands will be liste in blue under there parent command(Will be added in later version)")
Sound.PlayClick()
TextWindow.WriteLine("Summarys of commands and Sub commands will be listed under there parent in gray")
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
Sound.PlayClick()
TextWindow.WriteLine("pen.color")
Sound.PlayClick()
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("will let you choose the color of the pen/pencil")
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
Sound.PlayClick()
TextWindow.WriteLine("Pen.Size")
Sound.PlayClick()
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("Will let you choose the size of the pen/pencil")
Sound.PlayClick()
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Paint.bgcolor")
Sound.PlayClick()
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("Will let you choose the background color of the graphicswindow")
Sound.PlayClick()
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Paint.Clear")
Sound.PlayClick()
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("Will clear the project screen")
Sound.PlayClick()
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Paint.Window.Size")
Sound.PlayClick()
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("Will let you choose the size of the project window")
Sound.PlayClick()
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine(" ")
TextWindow.WriteLine("Text.Clear")
Sound.PlayClick()
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("Will clear the command screen")
Sound.PlayClick()
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Paint.Eraser")
Sound.PlayClick()
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("Will change the pen to an eraser")
Sound.PlayClick()
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Paint.Pen")
Sound.PlayClick()
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("Will change the pen from eraser back to pen")
Sound.PlayClick()
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Paint.RBGColor")
Sound.PlayClick()
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("Will change the project screens background color to a random color")
Sound.PlayClick()
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Window.Size")
Sound.PlayClick()
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("Will let you change the size of the project window")
Sound.PlayClick()
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Window.Size = Desktop")
Sound.PlayClick()
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("Will make the project window full screen")
Sound.PlayClick()
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Window.Size = Half")
Sound.PlayClick()
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("Will change the project window to half screen")
Sound.PlayClick()
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Paint.RPColor")
Sound.PlayClick()
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("Will change the pen to a random color")
Sound.PlayClick()
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Text.Color")
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("This will let you change the color of the text in the command screen")
Sound.PlayClick()
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Project.New")
Sound.PlayClick()
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("This will clear both the command screen and the project screen")
Sound.PlayClick()
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Commands.List")
Sound.PlayClick()
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("This will list all the commands and sub commands in the system")
Sound.PlayClick()
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Turtle.Move")
Sound.PlayClick()
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("This will let you draw lines with the turtle function")
Sound.PlayClick()
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Turtle.MoveTo")
Sound.PlayClick()
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("Will let you draw lines with the turtle using the X and Y axis")
Sound.PlayClick()
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Flickr.Random")
Sound.PlayClick()
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("Will choose a random picture from Flickr and set it for the background")
Sound.PlayClick()
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Text.BGColor")
Sound.PlayClick()
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("Will let you choose the background color for the command screen")
Sound.PlayClick()
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Text.Name")
Sound.PlayClick()
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("Will let you choose the name of the command screen, the text on the top bar of the command screen")
Sound.PlayClick()
TextWindow.WriteLine(" ")
TextWindow.ForegroundColor = "red"
TextWindow.WriteLine("Project.Name")
Sound.PlayClick()
TextWindow.ForegroundColor = "gray"
TextWindow.WriteLine("This will let you change the name of the project screen, the text on the top bar of the project screen")
  EndSub


  Sub TurtleM
  TextWindow.WriteLine("Pen up or Pen down?")
  RRR = TextWindow.Read()
  Sound.PlayClick()
  If(RRR = "up")Then
    Turtle.PenUp()
    Sound.PlayClick()
TextWindow.WriteLine("Turtle.MoveTo X co's?")
R = TextWindow.ReadNumber()
Sound.PlayClick()
TextWindow.WriteLine("Turtle.MoveTo Y co's")
RR = TextWindow.ReadNumber()
Turtle.MoveTo(R,RR)
ElseIf(RRR = "down")Then
  Sound.PlayClick()
  TextWindow.WriteLine("What color?")
  L = TextWindow.Read()
  GraphicsWindow.PenColor = L
  Turtle.PenDown()
  Sound.PlayClick()
  TextWindow.WriteLine("Turtle.MoveTo X co's?")
  R = TextWindow.ReadNumber()
  Sound.PlayClick()
TextWindow.WriteLine("Turtle.MoveTo Y co's")
RR = TextWindow.ReadNumber()
Turtle.MoveTo(R,RR)
EndIf
GraphicsWindow.PenColor = L
    GraphicsWindow.BrushColor = "white"
    GraphicsWindow.FillRectangle(GraphicsWindow.Width-GraphicsWindow.Width+10,GraphicsWindow.Height-50,300,12)
    GraphicsWindow.BrushColor = L
GraphicsWindow.DrawBoundText(GraphicsWindow.Width-GraphicsWindow.Width+10,GraphicsWindow.Height-50,300, "Pen.Color = " + L)
EndSub


Sub Turtle
  Loop = 0
TextWindow.WriteLine("Which direction")
RD = TextWindow.Read()
Sound.PlayClick()
TextWindow.WriteLine("How many degrees?")
RTD = TextWindow.ReadNumber()
Sound.PlayClick()
TextWindow.WriteLine("Pen up or Pen down?")
RUD = TextWindow.Read()
Sound.PlayClick()
TextWindow.WriteLine("How far?")
RDD = TextWindow.ReadNumber()
Sound.PlayClick()
TextWindow.WriteLine("What color?")
L = TextWindow.Read()
GraphicsWindow.PenColor = L
Sound.PlayClick()
TextWindow.WriteLine("Loop how many times?")
Looptime = TextWindow.ReadNumber()
While(Loop<Looptime)
  Loop = Loop + 1
If(RUD = "up")Then
  Turtle.PenUp()
ElseIf(RUD = "down")Then
  Turtle.PenDown()
  EndIf
If(RD = "right")Then
  Turtle.TurnRight()
  Turtle.Move(RDD)
ElseIf(RD = "left")Then
  Turtle.TurnLeft()
  Turtle.Move(RDD)
EndIf
If(RD = "angle")Then
  Turtle.Turn(RTD)
  Turtle.Move(RDD)
  EndIf
EndWhile
GraphicsWindow.PenColor = L
    GraphicsWindow.BrushColor = "white"
    GraphicsWindow.FillRectangle(GraphicsWindow.Width-GraphicsWindow.Width+10,GraphicsWindow.Height-50,300,12)
    GraphicsWindow.BrushColor = L
GraphicsWindow.DrawBoundText(GraphicsWindow.Width-GraphicsWindow.Width+10,GraphicsWindow.Height-50,300, "Pen.Color = " + L)
EndSub


Sub Flickr
  TextWindow.WriteLine("Subject one?")
  RSO = TextWindow.Read()
  Sound.PlayClick()
  TextWindow.WriteLine("Subject two")
  RST = TextWindow.Read()
  Pic = Flickr.GetRandomPicture(RSO + RST)
  GraphicsWindow.DrawResizedImage(Pic,0,0,GraphicsWindow.Width,GraphicsWindow.Height)
EndSub


Sub TBGC
  TextWindow.WriteLine("Type text background color")
  RTBGC = TextWindow.Read()
  TextWindow.BackgroundColor = RTBGC
  TextWindow.Clear()
  EndSub


  Sub TWN
    TextWindow.WriteLine("New Name?")
    RNN = TextWindow.Read()
    TextWindow.Title = RNN
  Endsub


  Sub PaintN
    TextWindow.WriteLine("New project name?")
    RNPN = TextWindow.Read()
    GraphicsWindow.Title = RNPN
  EndSub


  Sub PPEN
    GraphicsWindow.PenColor = "black"
    GraphicsWindow.BrushColor = L
GraphicsWindow.DrawBoundText(GraphicsWindow.Width-GraphicsWindow.Width+10,GraphicsWindow.Height-50,300, "Pen.Color = Black")
  EndSub


  Sub TurtleH
    Turtle.Hide()
  EndSub


  Sub Turtlerect
  TextWindow.WriteLine("X co's")
  RectX = TextWindow.ReadNumber()
  TextWindow.WriteLine("Y co's?")
  RectY = TextWindow.ReadNumber()
  TextWindow.WriteLine("Height?")
  RectHe = TextWindow.ReadNumber()
  TextWindow.WriteLine("Width")
  RectWi = TextWindow.ReadNumber()
  TextWindow.WriteLine("Color")
  L = TextWindow.Read()
  GraphicsWindow.PenColor = L
  Turtle.PenUp()
 Turtle.MoveTo(RectX,RectY)
  Turtle.PenDown()
  Turtle.Move(RectHe)
  Turtle.TurnRight()
  Turtle.Move(RectWi)
  Turtle.TurnRight()
  Turtle.Move(RectHe)
  Turtle.TurnRight()
  Turtle.Move(RectWi)
  GraphicsWindow.PenColor = L
    GraphicsWindow.BrushColor = "white"
    GraphicsWindow.FillRectangle(GraphicsWindow.Width-GraphicsWindow.Width+10,GraphicsWindow.Height-50,300,12)
    GraphicsWindow.BrushColor = L
GraphicsWindow.DrawBoundText(GraphicsWindow.Width-GraphicsWindow.Width+10,GraphicsWindow.Height-50,300, "Pen.Color = " + L)
EndSub


Sub Star
  TextWindow.Write("Enter the number of points (odd numbers only):")
  points = TextWindow.ReadNumber()
  If Math.Remainder(points,2) = 1 then
    angle = 180-(360/points/2)
    TextWindow.Write("Enter the color:")
    GraphicsWindow.PenColor = TextWindow.Read()
    TextWindow.Write("Enter the X coordinate of the stars center:")
    x = TextWindow.ReadNumber()
    TextWindow.Write("Enter the Y coordinate of the stars center:")
    y = TextWindow.ReadNumber()
    Turtle.PenUp()
    Turtle.MoveTo(x,y)
    Turtle.PenDown()
    Turtle.Speed = 10
    side = 0
    For i = 1 To 100
      Turtle.Move(side)
      Turtle.Turn(angle)
      side = side + 1
    EndFor
    Turtle.Speed = 1
  Else
    TextWindow.Write("Invalid Number")
  EndIf
  GraphicsWindow.PenColor = L
    GraphicsWindow.BrushColor = "white"
    GraphicsWindow.FillRectangle(GraphicsWindow.Width-GraphicsWindow.Width+10,GraphicsWindow.Height-50,300,12)
    GraphicsWindow.BrushColor = L
GraphicsWindow.DrawBoundText(GraphicsWindow.Width-GraphicsWindow.Width+10,GraphicsWindow.Height-50,300, "Pen.Color = " + L)
EndSub

Answer 110

A paint program created in small basic using Fremy's extention.

'_____________________
'Paint program V1
'Author Dratii
'Made with Fremy's extention
'_____________________

'Variables
set = 0
Erase = 0
Pen = "black"

Helptext = "Welcome."
Helptext2 = "The buttons are for using the functions."
Helptext3 = "For some functions pressing the button again will disable the function."
Helptext4 = "The lables above the buttons show the current colour, size, and tool."
Helptext5 = "The 'Eraser' button removes parts of the drawing."
Helptext6 = "The 'Clear' button clears the drawing area."
Helptext7 = "The 'Line' button draw straight lines."
Helptext8 = "The 'Colour' button changes the pen colour."
Helptext9 = "And the '+ and -' buttons change the pensize."

GraphicsWindow.MouseDown = OnMouseDown
GraphicsWindow.BackgroundColor = "White"
GraphicsWindow.PenWidth = 1
GraphicsWindow.Width = 715
GraphicsWindow.Height = 530
GraphicsWindow.MouseMove = OnMouseMove
GraphicsWindow.Title = "Paint Program"
GraphicsWindow.CanResize = "no"
Pen = "black"
Pwidth = 3
buttons() 'creates the buttons


'Colour function
Sub Clicker
  Pen = Dialogs.AskForColor()
  If(Pen<>"")then
    Erase = 0
    GraphicsWindow.PenColor = Pen
    GraphicsWindow.BrushColor = Pen
    Pen2 = Pen

    If(Currenttool = "Eraser")then
      'Redraws the lable
      Pen2 = Pen
          Controls.Remove(Currenttool)
  GraphicsWindow.BrushColor = "red"
Currenttool = Controls.AddLabel(120, 25, "Pen")
Controls.Move(Currenttool, 237, 470)
GraphicsWindow.BrushColor = "black"
GraphicsWindow.BrushColor = Pen
Pen2 = Pen
endif
endif
 'Redraws the lable
Controls.Remove(CurrentColour)
CurrentColour = Controls.AddRectangle(10, 10)
Controls.Move(CurrentColour, 74, 478)
endsub

'Help Function
Sub Clicker2
  GraphicsWindow.ShowMessage(Helptext, "Help")
  GraphicsWindow.ShowMessage(Helptext2, "Help")
  GraphicsWindow.ShowMessage(Helptext3, "Help")
  GraphicsWindow.ShowMessage(Helptext4, "Help")
  GraphicsWindow.ShowMessage(Helptext5, "Help")
  GraphicsWindow.ShowMessage(Helptext6, "Help")
  GraphicsWindow.ShowMessage(Helptext7, "Help")
  GraphicsWindow.ShowMessage(Helptext8, "Help")
  GraphicsWindow.ShowMessage(Helptext9, "Help")

endsub

'Eraser Function
Sub Clicker8
  If(Erase = 0)Then
    GraphicsWindow.PenColor = "white"
    Pen2 = Pen
    Pen = "white"

'Redraws the lable
    Controls.Remove(Currenttool)
GraphicsWindow.BrushColor = "red"
Currenttool = Controls.AddLabel(120, 25, "Eraser")
Controls.Move(Currenttool, 237, 470)
GraphicsWindow.BrushColor = "black"

Erase = 1
set = 0
  Else
  Erase = 0
  GraphicsWindow.PenColor = Pen2
  Pen = Pen2

  'Redraws the lable
      Controls.Remove(Currenttool)
  GraphicsWindow.BrushColor = "red"
Currenttool = Controls.AddLabel(120, 25, "Pen")
Controls.Move(Currenttool, 237, 470)
GraphicsWindow.BrushColor = "black"
  endif

endsub

'Clear Function
Sub Clicker9
GraphicsWindow.BrushColor = "white"
GraphicsWindow.FillRectangle(0, 0, 725, 600)
endsub

'Size Functions
Sub Clicker10
If(Pwidth < 10)then
  Pwidth = Pwidth + 1
endif
Repen()
endsub

Sub Clicker11
If(Pwidth > 1)then
  Pwidth = Pwidth - 1
endif
Repen()
endsub

'Line Function
Sub Clicker12
If(set = 1)or(set = 2)then
  set = 0

  'Redraws the lable
        Controls.Remove(Currenttool)
  GraphicsWindow.BrushColor = "red"
Currenttool = Controls.AddLabel(120, 25, "Pen")
Controls.Move(Currenttool, 237, 470)
GraphicsWindow.BrushColor = "black"
Erase = 0
else
  set = 1
  Pen = Pen2
  GraphicsWindow.PenColor = Pen

'Redraws the lable
      Controls.Remove(Currenttool)
  GraphicsWindow.BrushColor = "red"
Currenttool = Controls.AddLabel(120, 25, "Line")
Controls.Move(Currenttool, 237, 470)
GraphicsWindow.BrushColor = Pen
Erase = 0
  EndIf

endsub



sub Repen
  GraphicsWindow.PenWidth = Pwidth

'Redraws the lable
  Controls.Remove(CurrentSize)
GraphicsWindow.BrushColor = "red"
CurrentSize = Controls.AddLabel(30, 25, Pwidth)
Controls.Move(CurrentSize, 170, 470)
GraphicsWindow.BrushColor = Pen

endsub


Sub buttons
Controls.LoadTheme("XPBlue")
GraphicsWindow.PenWidth = 1
GraphicsWindow.BrushColor="#E6F5FD"
GraphicsWindow.PenColor="#B2DFF8"
Rect1 = Controls.AddRectangle(800, 80)
Controls.Move(Rect1, 0, 460)
GraphicsWindow.PenWidth = Pwidth
GraphicsWindow.PenColor=Pen
GraphicsWindow.PenColor = "black"
GraphicsWindow.BrushColor = "black"

'Lables

Lable = Controls.AddLabel(120, 25, "Colour")
Controls.Move(Lable, 20, 470)
CurrentColour = Controls.AddRectangle(10, 10)
Controls.Move(CurrentColour, 74, 478)

Lable2 = Controls.AddLabel(120, 25, "Pen Size")
Controls.Move(Lable2, 110, 470)
GraphicsWindow.BrushColor = "red"
CurrentSize = Controls.AddLabel(30, 25, "3")
Controls.Move(CurrentSize, 170, 470)
GraphicsWindow.BrushColor = "black"

Lable3 = Controls.AddLabel(120, 25, "Tool")
Controls.Move(Lable3, 200, 470)
GraphicsWindow.BrushColor = "red"
Currenttool = Controls.AddLabel(120, 25, "Pen")
Controls.Move(Currenttool, 237, 470)
GraphicsWindow.BrushColor = "black"

'buttons
Button = Controls.AddButton(80, 25, "Colour")
Controls.Move(Button, 420, 500)
Controls.RegisterMouseDownEvent(Button, "Clicker")


Button8 = Controls.AddButton(80, 25, "Eraser")
Controls.Move(Button8, 20, 500)
Controls.RegisterMouseDownEvent(Button8, "Clicker8")

Button9 = Controls.AddButton(80, 25, "Clear")
Controls.Move(Button9, 120, 500)
Controls.RegisterMouseDownEvent(Button9, "Clicker9")

Button10 = Controls.AddButton(80, 25, "+")
Controls.Move(Button10, 520, 500)
Controls.RegisterMouseDownEvent(Button10, "Clicker10")

Button11 = Controls.AddButton(80, 25, "-")
Controls.Move(Button11, 620, 500)
Controls.RegisterMouseDownEvent(Button11, "Clicker11")

Button12 = Controls.AddButton(80, 25, "Line")
Controls.Move(Button12, 320, 500)
Controls.RegisterMouseDownEvent(Button12, "Clicker12")

Button2 = Controls.AddButton(80, 25, "Help")
Controls.Move(Button2, 220, 500)
Controls.RegisterMouseDownEvent(Button2, "Clicker2")



endsub
Sub Line
    If(set = 2)then
    GraphicsWindow.PenColor = Pen
    GraphicsWindow.BrushColor = Pen
  GraphicsWindow.DrawLine(NewX, NewY, oldX, oldY)
  set = 1
  endif
  oldX = GraphicsWindow.MouseX
  oldY = GraphicsWindow.MouseY
If(set = 1)then
Mousedown2()
endif
endsub

'The pen
Sub Mousedown2
  NewX= GraphicsWindow.MouseX
  NewY = GraphicsWindow.MouseY
  GraphicsWindow.SetPixel(NewX, NewY, Pen)
  set = 2
  endsub

Sub OnMouseDown


If(set <> 0)then
  Line()
endif

  oldX = GraphicsWindow.MouseX
  oldY = GraphicsWindow.MouseY

EndSub

Sub OnMouseMove
  x = GraphicsWindow.MouseX
  y = GraphicsWindow.MouseY

  If (Mouse.IsLeftButtonDown)And(set = 0) then
    GraphicsWindow.DrawLine(oldX, oldY, x, y)
        endif
  If(Mouse.IsLeftButtonDown)And(set = 0)And(Pwidth > 3) then
    GraphicsWindow.SetPixel(x, y, Pen)
    GraphicsWindow.SetPixel(x +1, y +1, Pen)
    GraphicsWindow.SetPixel(x -1, y -1, Pen)
    GraphicsWindow.SetPixel(x +2, y +2, Pen)

  GraphicsWindow.DrawLine(oldX + 2, oldY + 2, x + 2, y + 2)


  endif


  oldX = x
  oldY = y

EndSub

Answer 111

A paint program created in small basic using Fremy's extention.

Looks very great ! The UI is beautiful to see.



Maybe you can use Controls.SetText instead of removing old labels and adding new ones, but for the rest, it seems great. Idem for the color preview (you can use Controls.SetBackground). Hum, just another small remark. The first time I clicked on the 'Line' button, I didn't find how to get the 'Pen' mode ack. Maybe you should use Controls.SetText too to change the caption of the button in 'Pen' when the mode is 'Line', and 'Line' when the mode is 'Pen'.

Now, if you want some challenge to make the program even better, you could add the possibilities to draw rectangle or circles ;)

Behalve the few remarks, it is good written. You take advantage of subs and made good use of comments. It's pleasant to look at your code. Keep programming like that.

---

Fremy - Developer in VB.NET, C# and JScript ... - Feel free to try my extension

Answer 112

Fun little ball bounce program.


'Define a circle, it's size, position and speed
circleRadius = 50
xPosition = circleRadius
yPosition = circleRadius
xSpeed = 50
ySpeed = 0

'Set up a timer to tick once for every frame of animation
Timer.Interval = 33   '33 = 30 frames per second
Timer.Tick = onTimerTick

'Set up events so you can drag the ball around
GraphicsWindow.MouseMove = onMouseMove
GraphicsWindow.MouseDown = onMouseDown

'Put a suiting title on the window
GraphicsWindow.Title = "Ball Bounce Example - Drag and Release to 'Throw' the ball"


'--------------------------------------------------------------------------------------------------------------
'onTimerTick   - This is what happens every frame
'--------------------------------------------------------------------------------------------------------------
Sub onTimerTick

  'Call the subroutine that updates the ball for this frame
  Update()

  'Now Draw the frame
  Redraw()

EndSub

'--------------------------------------------------------------------------------------------------------------
'Update   - Updates everything to the next frame of animation
'--------------------------------------------------------------------------------------------------------------
Sub Update

  'Move the position of the ball by it's speed
  '-------------------------------------------------
  xPosition = xPosition + xSpeed
  yPosition = yPosition + ySpeed


  'Check for a bounce against any of the 4 sides of the window
  '-----------------------------------------------------------------------

  'first figure out where the sides are
  rightSide = GraphicsWindow.Width - circleRadius
  leftSide = circleRadius
  bottomSide = GraphicsWindow.Height - circleRadius
  topSide = circleRadius

  'then bounce if we need to
  If xPosition > rightSide then     'right side
    xPosition = rightSide - circleRadius
    xSpeed = -xSpeed
  EndIf
  If xPosition < leftSide then    'left side
    xPosition = leftSide
    xSpeed = -xSpeed
  EndIf
  If yPosition > bottomSide then    'bottom
    yPosition = bottomSide
    ySpeed = -ySpeed
  EndIf
  If yPosition < topSide then    'top
    yPosition = topSide
    ySpeed = -ySpeed
  EndIf


  'Gravity  (increases the speed in the down direction to make it fall)
  '-------------------------------------------------------------------------------
  ySpeed = ySpeed + 2


  'Friction (make the overall speed 95% of it's current speed)
  '---------------------------------------------------------------------
  xSpeed = xSpeed * .95
  ySpeed = ySpeed * .95


  'Hooking - Advanced Friction (when the ball has so little energy it gets "caught" and can no longer move)
  '-----------------------------------------------------------------------------------------------------------------------------
  If Math.Abs(xSpeed) < .1 then     'Math.Abs() is a simple math function to make negative numbers positive
    xSpeed = 0                                'we're checking to see if the movement ( backwards (negative) or forward (positive) )
  EndIf                                         'is less than .1.  If it is, just stop the movement all together.
  If Math.Abs(ySpeed) < .1 then
    ySpeed = 0
  EndIf



EndSub



'--------------------------------------------------------------------------------------------------------------
'Redraw     - Clears the GraphicsWindow and Draws the Ball
'--------------------------------------------------------------------------------------------------------------
Sub Redraw

  GraphicsWindow.Clear()

  'Draw the ball - centering it on the xPosition/yPosition
  circleSize = circleRadius * 2
  GraphicsWindow.DrawEllipse(xPosition-circleRadius, yPosition-circleRadius, circleSize, circleSize)

EndSub



'--------------------------------------------------------------------------------------------------------------
'onMouseDown    - The mouse button was pressed
'--------------------------------------------------------------------------------------------------------------
Sub onMouseDown

  'save the position of the mouse in variables
  xOld = GraphicsWindow.MouseX
  yOld = GraphicsWindow.MouseY

  'move the ball to where the mouse is
  xPosition = xOld
  yPosition = yOld

EndSub



'--------------------------------------------------------------------------------------------------------------
'onMouseMove    - The mouse was moved
'--------------------------------------------------------------------------------------------------------------
Sub onMouseMove

  'see if the button is down.  If it is, then we're dragging the ball
  If Mouse.IsLeftButtonDown Then

    'save the position of the mouse in variables
    x = GraphicsWindow.MouseX
    y = GraphicsWindow.MouseY

    'find out how far the mouse moved since the last time we we're here
    'this will be the new speed of the ball
    xSpeed = x - xOld
    ySpeed = y - yOld

    'move the ball to where the mouse is
    xPosition = x
    yPosition = y

    'this mouse position is old, save where it is so we can figure out
    'the speed next time we're here
    xOld = x
    yOld = y

  EndIf

EndSub




---

Toefist Productions LLC, Minnetonka, MN

Answer 113

Hello TheToefistJU,

I like your use of physics to make a realistic animation. I feel you could improve on it though if you used Shapes rather than GraphicsWindow.DrawEllipse(). With Shapes you can Move or Animate to a new position without having to erase the old position. This would allow you to add a background that wouldn't get corrupted when the ball moved over it.

 I have made slight modifications to your program to illustrate what I mean. I have added a Shapes ball that is Moved to the new position. I have left the original but removed the GraphicsWindow.Clear(). This leaves a trail of the ball position. Notice how the solid ball does not erase the trail as it moves over it.
 By the way; if you use Import and Publish (especially for larger files) it helps to follow a thread without a lot of scrolling.

 Import HNQ963

Answer 114

By the way; if you use Import and Publish (especially for larger files) it helps to follow a thread without a lot of scrolling.

Pictures are nice too.

Answer 115

Surprised someone has not already posted this but how about some classic Snake action?

Code can be imported using the ID WMX007 or seen here: http://smallbasic.com/program/?WMX007

Instructions: Avoid the walls and yourself while eating as many food items as possible and growing in length. Movement is controlled using the left and right arrow keys. Turns are relative to your current direction.

I've tried to keep the code quite clean and flexible, but the game could be improved with the addition of multiple concurrent food items or maybe even walls! Comments welcome.

With regard to Small Basic itself, I'd welcome the ability to set the location of a shape when creating it, unless I am just being blind and missed it! My implementation sometimes flickers snake segments or food items in the top, left corner as they are created before being moved to their correct location.

    As an off-topic aside I definitely think the publish button should have a confirmation dialogue box - somethings just shouldn't be published!

Thanks for the consideration, hope it's mildly enjoyable!

Jason.

Answer 116

OK, so I realise now that Snake is already a featured example for Small Basic (though unfortunately the featured code doesn't work correctly in v0.4 and I was unable to determine why) - that's what happens when you don't check the second page of the blog!

So instead, sticking with the theme of classic games, for your consideration: Asteroids.

Code can be imported using the ID QFL408 or seen here: http://smallbasic.com/program/?QFL408

Instructions: Destroy all the asteroids, by shooting them, avoiding getting hit yourself. Left and right arrows keys to rotate, forward and backwards arrow keys to adjust ship speed. Space bar to fire. P key to pause/resume.

I'm sure the game could benefit from the addition of de-facto standard three lives, some more interesting graphics and maybe even aliens.

As before, comments welcome!

Again, thanks for the consideration and I hope you enjoy!

Jason.

Answer 117

Very impressive Asteroids game Jason Jacques. Great job!

Answer 118

Nice game, Jason.   Asteroids is the sample of this week!

http://blogs.msdn.com/smallbasic

Answer 119

I've modified Jason's Asteroids to include images.  The new variant can be downloaded as: QFL408-0

Answer 120

Hi Im new to small basic but have been programming in VB.net for a while I have created a paint like program that can draw staright lines There are four colours to choose from. If you want the code type SBV954 into import. (Could someon tell me how to upload a photo because I would like to include a screen shot thank you)

Answer 121

Posting a screen shot

You must upload your image to a third party site (Flicker, your own personal website or some other site), then edit the HTML of your post to include the picture.

<img alt="" src="http://farm4.static.flickr.com/3044/3102500861_398a6a988f.jpg?v=0" />

Answer 122

Excellent game - nice work Jason!

I altered it slightly to handle the auto-repeat and auto-delay introduced by my OS for key presses that gives some jerky rotations.  Also each 'fire' requires a separate press of the space bar with these mods.

QFL408-3

Answer 123

For the game, maybe we need a maxUserSpeed, because we can go faster than the light, currently :)
It's fun, but only because you can shot all asteroids but one, go the the ligth speed, and wait until the asteroid hit you.

Also, it would be great to have a point lost each time we fire. So, it would be more time-rapporting to shot with precision than with mass.

---

Fremy - Developer in VB.NET, C# and JScript ... - Feel free to try my extension

Answer 124

It's great to see how into my game everyone is and I'm glad it hasn't been too difficult for you to achieve your modifications - feel free to keep hacking at it!

I did notice the issue with the maximum speed, but I was never very good at asteroids so always took it slow - seems not everyone feels the same way! I've updated litdev's modifications with a maximum speed parameter (maxSpeed, found in the player setting sections) and added inertia as would have been found in the original game - you can disable it by setting it to zero if you'd rather not slow down.

During development I actually considered taking a point off for each shot, but dismissed it. However, your point about accuracy is well heeded (I like to spin and fire every second or so...) so I've updated the code appropriately. I've also done some general tidying of the code for example removing the now superfluous player and rock colours.

Get the new code using the ID QFL408-4 or view online here: http://smallbasic.com/program/?QFL408-4

Thanks for your input.

Jason.

Answer 125

QFL408-4 is now promoted to ASTEROIDS.  You can import this version using the id: ASTEROIDS

Answer 126

QuickBasic had Gorillas and now Small Basic does too!





Image, Sound, Exe and Source files can be downloaded here
http://code.msdn.microsoft.com/SmallBasicGorillas

Answer 127

I made a 21/Black Jack in the textwindow. I'm going to make it in the graphics window soon and will also add betting. I am also working on five card draw and texas hold'em.

Import Code: NFB246

There might still be a few bugs, so let me know if you find one.

Answer 128

I'm sorry, but I just had to correct your instructions. If you wish to use it, import NFB246-0.
In the version of the game that I know you can only have a maximum of five cards. you would also need to check for this.

Answer 129

I have made a minesweeper game in Small Basic.

It is very basic. (Pun not intended)

Basically all it is missing out on is fancy graphics and the auto thingy. (will explain later)

The import code is: WGT176

It works the same as the windows minesweeper.

Except, when it is a blank square it doesn't auto click all the squares around it.

I wasn't sure how to add that feature due to the restrictions in sub routines.

If anyone could point me into the right direction or anything for that, that would be nice.

It also allows you to change the color schemes and enter cheats. (For debugging purposes)

Feedback would be nice~

-Simon
